SERVICE MANUAL RH5 6.0−1 6 ダミー (Section のレベル 1) 6.0 ダミー (Section のレベル 2)
Lamp connector
Inverter board
M3 flat head machine screw
Lamp replacement lid
RH5
5.38 Backlight Replacement on Main Control Panel
SERVICE MANUAL
5.38−4
DA3SEC−83−9W0−A0
7. Insert the lamp connector into the inverter
board firmly.
8. Reattach the lamp replacement lid into
position with the screws.
M3 flat head machine screw (x 3)
SERVICE MANUAL
RH5
6.0−1
6ダミー(Sectionのレベル1)
6.0ダミー(Sectionのレベル2)
RH5
SERVICE MANUAL
6.0−2
DA3SEC−89−000−A0
DA3SEC−89−000−A0
Sentence No.
6. MAINTENANCE PRECISION
CHECK
This chapter summarizes the methods of confirmation, adjustment and replacement
during installation or inspection.
x To avoid personal injury, correct procedure for performing maintenance must
be observed.
x Be sure to read “Safety Precautions” in this manual carefully.
x Refer to Operation, Programming or Reference Manuals on how to operate the
RH5.
x Tools and jigs mentioned in this chapter do not come with the RH5. Prepare
them in advance.
