RH5

1.3 On Safety

SERVICE MANUAL

1.3−2

DA3SEC−81−080−B0

1.3.3 How to Deal with the Operation Troubles

Any troubles occurred during machine operation may cause various hazardous conditions besides

troubles on normal operations.

This is because the necessity of manual operation may arise when dealing with the troubles.

It is requested that this type of repair/adjustment be done only by the trained, skilled personnel who are

conversant in the possible accidents that may occur in each point as well as the whole of the installation.

1.4 Lubrication Oil

SERVICE MANUAL

RH5

1.4−1

DA3SEC−81−070−B0

1.4 Lubrication Oil

DA3SEC−81−070−B0

Sentence No.

1.4.1 Recommended Lubricants

Machine Oil

Sliding unit

N Shell: Tonna oil T68

N Mobil: Bactra No. 2

N Esso: Febis K68

=REFERENCE=

Use ISO #68 or equivalent for machine oil.

Grease

Sliding unit, ball screws, etc.

N Panasonic:MP Grease N990PANA−022

This grease is available as maintenance part.

1kg−can: Product code N990PANA−023

100g−tube:Product code N990PANA−022

N Shell: Alvania Grease 2

N Mobil: Mobilux 2

N Esso: Beacon 2 or Lithtan 2

N Kyodo: Maltemp LRL

Grease (S)

Chain unit

N Shell: Alvania EP Grease R0

N Mobil: Mobilux EP0

N Esso: Pen.O.Red EP Grease or Lithtan EP0

Antirust lubricant

Name: Reverse 3

Order: Contact Panasonic Factory Solutions

RH5

1.4 Lubrication Oil

SERVICE MANUAL

1.4−2

DA3SEC−81−070−B0

1.4.2 Grease Gun Unit

The drawing below shows the configuration of the grease gun unit. (1046601000)

This unit enables you to inject grease approx. 0.5cc per shot.

1. Attachment N2 type

Part No.: N938YYYY−009

Model: Nozzle N2

2. Attachment L type

Part No.: N938YYYY−007

Model: Nozzle L

3. Attachment P type

Part No.: N938YYYY−006

Model: Nozzle P

4. Attachment N1 type

Part No.: N938YYYY−008

Model: Nozzle N1

5. Attachment J type

Part No.: N938YYYY−010

Model: Nipple J

6. Grease pump type

Part No.: N977NAKH−018

Model: NAK HGP NZ1

7. Attachment H type

Part No.: N938YYYY−004

Model: Nozzle H

8. Attachment NL type

Part No.: N938YYYY−011

Model: Nipple NL
