8.11 Differences in Specifications between RHIII and RH5

SERVICE MANUAL

RH5

8.11−1

DA3SEC−85−X10−A0

8.11 Differences in Specifications between RHIII and

RH5

DA3SEC−85−X10−A0

Sentence No.

Item RHIII RH5

Remarks

Loader unit

(PCB transfer and

pneumatic system)

Loading time

M: 3.5 s

LL: 4.5 s

Stoppers added and changed

M: 2.5 s

LL: 4.5 s

Loader unit

(PCB transfer and

pneumatic system)

Cylinder changed

Cylinder strength enforced

Unloader unit

(PCB transfer and

pneumatic system)

Loading time

M: 3.5 s

LL: 4.5 s

Stoppers added and changed

M: 2.5 s

LL: 4.5 s

Unloader unit

(PCB transfer and

pneumatic system)

Cylinder changed

Cylinder strength enforced

Piping unit

(PCB transfer and

pneumatic system)

35 mm s

Solenoid valve response improved

15 mm sec

(Changed to VQZ)

Main drive

(Motor)

2.0 kw

AC servomotor capacity increased

3.0 kw

(Reduction ratio changed)

Guide pin select unit

(Structure

improved)

Guide pin select unit:

swivel system

Guide pin unit:

Swivel mechanism abolished o

Lock system

Upper drive unit

(Structure

improved)

Cam timing

sequence timing

Mechanical valve timing

Altered

2.6

Upper drive unit

(Lock stabilized)

Lock cylinder stroke & support pin

changed

(for easy adjustment)

2.9

Upper drive unit

(Maintainability

improved)

Grease nipples added to the lever

bearings

Lower drive unit

(Lock stabilized)

Cam timing

sequence timing

Altered

2.6

Lower drive unit

(Lock stabilized)

Lock cylinder stroke & support pin

changed

(for easy adjustment)

2.9

Lower drive unit

(Maintainability

improved)

Grease nipples added to the lever

bearings

Parts feeder unit

(Feed position

stabilized)

Feed position structure improved

(Feed stabilized)

Parts feeder unit

(Feed position

stabilized)

Stopper added for preventing feed

pusher overrun

RH5

8.11 Differences in Specifications between RHIII and RH5

SERVICE MANUAL

8.11−2

DA3SEC−85−X10−A0

Item

RHIII RH5

Remarks

Cutter unit

(Structure

improved)

Cutter cylinder changed Cutter cylinder changed

(Capacity increased)

Cutter unit

(V−cut stabilized)

Cutter cam action altered

Cutter unit

(Tape waste drop

function improved)

Cut waste chute

Integrated type

Cut waste chute

Separate type (for easy adjustment)

4.1.8

Cutter unit

(Tape waste drop

function improved)

Catching tape waste when cut

waste pusher is ON prevented

Cutter unit

(Longer

life/improved

durability)

Shape and material of lead cutter

changed

Material of tape cutter changed

Vertical connecting

unit

(Longer

life/improved

durability)

Bearing changed

(3−point support)

Bearing changed

(2−point support)

Main body unit No. of adjust bolts changed

Z axis 62 −feeder: 8

Z axis 80 −feeder: 10

No. of adjust bolts changed

Z axis 62 −feeder: 9

Z axis 80 −feeder: 11

Anvil swivel unit Thickness of anvil swivel plate

changed

Thickness of anvil swivel plate

changed

(Strength enhanced)

Guide chuck unit

(Insertion rate

stabilized)

Length of guide chuck slit changed

1.0 mm

Length of guide chuck slit changed

1.5 mm

Insertion chuck unit

(Insertion rate

stabilized)

Insertion chuck claw changed Insertion chuck claw changed

for stabilizing high −speed insertion

of large components (H=18, L=21)

Insertion chuck unit

(Insertion rate

stabilized)

Insertion chuck unit swivel stopper

changed

for stabilizing high −speed insertion

of large components (H=18, L=21)

Parts feeder unit

(Insertion rate

stabilized)

Spacer (2 mm) added

for stabilizing high −speed insertion

of large components (H=18, L=21)

Parts cassette unit

(Insertion rate

stabilized)

Feed of winding components

stabilized

Parts cassette length changed

Corner radius removed
