RH5
8.1 Construction Drawing List
SERVICE MANUAL
8.1−4
DA3SEC−85−460−A0
= MEMO =
8.2 List of Software Settings
SERVICE MANUAL
RH5
8.2−1
DA3SEC−85−470−B0
8.2 List of Software Settings
DA3SEC−85−470−B0
Sentence No.
Real ROM
address
Description Default
0FFF80
(068000)
7FF80 Machine model SW (1)
0: RHP, RHPII, RHIII, RH5
2: RHUP
4: RHXP (7.5/10)
5: RHXP (5/7.5/10)
0
0FFF82
(068002)
7FF82 Machine model SW (2)
0: Standard single PCB flow model (M)
1: Standard double/large single PCB flow model (L)
2: Large double PCB flow model (LL)
0
0FFF84
(068004)
7FF84 No. of max. cassettes (For two separate feeder carriage, total of ZL and
ZR cassettes.)
RHXP: 2C (44) RHP: 3C (60) RHP, RHPII: 50 (80)
RHUP: 38 (56) RHII: 3E (62) RH5: 28 (3E/50)
0FFF86
(068006)
7FF86 No. of loading available cassettes on ZL−axis (Not used for one feeder
type)
RHXP: 16 (22) RHP: 1E (30) RHII: 00 (0)
RHUP: 1C (28) RHP, RHPII: 28 (40)RH5: 00
00
0FFF88
(068008)
7FF88 No. of loading available cassettes on ZR−axis (Not used for one feeder
type)
RHXP: 16 (22) RHP: 1E (30) RHII: 00 (0)
RHUP: 1C (28) RHP, RHPII: 28 (40)RH5: 00
00
0FFF8A
(06800A)
7FF8A Z axis 2−separate feeder carriage option SW
0: One feeder type
1: Two separate feeder carriage
0
0FFF8C
(06800C)
7FF8C Display text setting
0: Japanese
1: English
J−0
E−1
0FFF90
(068010)
7FF90 Printer connection option SW
0: Not connected
1: Connected
1
0FFF92
(068012)
7FF92 FDD connection option SW
0: Not connected
1: Connected
1
0FFF96
(068016)
7FF96 Host remote command (C) option SW
0: Not connected
1: Connected
1
0FFF98
(068018)
7FF98 Host real−time command (R) option SW
0: Not connected
1: Connected
1
0FFF9A
(06801A)
7FF9A Automatic width adjustment (APC) board connection option SW
0: Not connected
1: Connected
3: New automatic width adjustment (RHPII, RHII, RH5)
0
0FFF9C
(06801C)
7FF9C Rear component exhaust display LED unit connection option SW (Only
available for two separate feeder carriage system)
0: Not connected
1: Connected
0
RH5
8.2 List of Software Settings
SERVICE MANUAL
8.2−2
DA3SEC−85−470−B0
Real
ROM
address
Description Default
0FFF9E
(06801E)
7FF9E High−speed insertion tact
0: Normal
1: High−speed 1 (0.36 sec)
2: High−speed 2 (0.29 sec)
2
0FFFA0
(068020)
7FFA0 Self−correction (RCG) board connection option SW *1
0: Not connected
1: Connected
1
0FFFA2
(068022)
7FFA2 Pulse motor (PMC) board connection option SW *1
0: Not connected
1: Connected
0
0FFFA4
(068024)
7FFA4 Number of cameras *1 1
0FFFA5
(068025)
7FFA5 Camera installation position
0: camera not connected or pulse motor used
1: Fixed camera on insertion position side
2: Fixed camera on recognition position side
1
0FFFA6
(068026)
7FFA6 Bad mark sensor connection option SW
0: Not connected
1: Connected
0
0FFFA8
(068028)
7FFA8 Board edge positioning unit connection option SW
0: Pin positioning
1: Pin/edge positioning
0
OFFFAA
(06802A)
7FFAA Skip recovery option SW
0: Not available
1: Available
0
0FFFAC
(06802C)
7FFAC Auto recovery option SW
0: Not available
1: Available
2: Available (Outputs R3NG command to host)
1
0FFFAE
(06802C)
7FFAE Skip + auto recovery option SW
0: Not available
1: Available
0
0FFFB0
(068030)
7FFB0 4−direction component invert device connection option SW
(Component invert command and polar coordinate pattern cannot be
used if this SW is not ON.)
0: Not connected
1: Connected
0
OFFFB8
(068038)
7FFB8 Inch pitch SW
0: mm pitch model
1: inch pitch model
Pitch
mm Inch
2.5
5.0
7.5
10.0
2.5 mm
5.0 mm
7.5 mm
10.0 mm
2.54 mm
5.08 mm
7.62 mm
10.16 mm
0
