RH5
7.2 AC Servomotor Adjustment
SERVICE MANUAL
7.2−2
DA3SEC−84−300−A0
7.2.2 AC Motor Power ON
(1) Turn ON the main power supply.
=CHECK=
In this state, keep hands on the EMERGENCY STOP at all times. If the cam shaft starts to move,
shut OFF power immediately.
(2) Switch to the semi−auto mode and check the motor excites.
=CHECK=
If the motor does not excite in the semi−auto mode, check the motor driver alarm.
(3) In the semi−auto mode, when wanting to rotate the motor by operating the cam shaft from the
sub−control panel, check the cam shaft turns in the normal direction and stops roughly after 1
revolution.
=CHECK=
x If the cam shaft turns in reverse, check Cn−02 bit of the motor driver to set to “0“.
x If the cam shaft does not turn at all, check the motor driver alarm display.
x Check the cam shaft’s relation with the X−Y table while turning.
(4) Working from the sub−control panel, check shifting across all 4 speeds.
7.2.3 Manual Mode Movement Check
(1) Set the machine to the manual mode. While turning the hand wheel to move the cam shaft, check
the hand wheel turns smoothly and without sticking.
=CHECK=
x If the hand wheel sticks or is hand to turn, check Cn−01 bit of the motor driver.
7.2 AC Servomotor Adjustment
SERVICE MANUAL
RH5
7.2−3
DA3SEC−84−300−A0
7.2.4 Semi−auto Mode Movement Check
(1) Adjust origin stop timing
In the semi−auto mode, turn the cam shaft 1 turn. Check the digital sequence timer stops at the
origin (358q −10q). If it does not stop at its origin. adjust the timer.
High speed (
0.29
) CS12 (Basic setting: 310q)
Medium speed (
0.36
) CS11 (Basic setting: 310q)
Low speed (
0.45/0.6
) CS10 (Basic setting: 325q)
RH5
7.2 AC Servomotor Adjustment
SERVICE MANUAL
7.2−4
DA3SEC−84−300−A0
AC Motor Driver Setting T able (RH5 (M) <NM−8224A>)
=REFERENCE=
x Values ( ) are required to fine adjust.
x Adjust Cn−17 if the motor oscillates after the table has stopped.
x Use the motor driver as follows:
X axis: SGDA−02ASY25, Y axis: SGDA−04ASY25, Z axis (40/62−feeder):
SGDA−08ASY120, Z axis (80−feeder): CACR−DR15BA13SY8, Cam shaft:
SGDB−20ADS
x Adjust the offset of Cn−00−003 via the digital operator. (Refer to ‘7.3’.)
x Values marked with an asterisk show new parameters corresponding to the positioning delay error.
x After setting Cn−01 and Cn−0A, turn OFF the power to the machine.
X/Y/Z axis (40/62−feeder)
Parameter
N
Name Default
No.
X axis Y axis Z axis
Cn−00−003 Offset
Cn−01 Memory switch 1 FFDCBA9876543210
0001000000000000
Cn−02 Memory switch 2 0000000000000000
Cn−03 Speed command gain 1300 1200 1400
Cn−04 Speed loop gain (200) (200) (200)
Cn−05 Consult speed loop integrated *50 *50 *50
Cn−06 Emergency stop torque 300 300 316
Cn−07 Soft start time (acceleration) 0 0 0
Cn−08 Normal rotation torque limit 300 300 316
Cn−09 Reverse rotation torque limit 300 300 316
Cn−0A Encoder pulse dividing ratio 1000 1000 500
Cn−0B Rotation detection level 20 20 20
Cn−0C Mode switch (torque command) 200 200 200
Cn−0D Mode switch (speed command) * 100 * 100 * 100
Cn−0E Mode switch (acceleration command) 0 0 0
Cn−0F Zero clamp level 10 10 10
Cn−10 JOG speed 500 500 500
Cn−11 Encoder pulse count 2048 2048 2048
Cn−12 Delay time from brake command to SV OFF 0 0 0
Cn−13 Torque command gain 30 30 30
Cn−14 Speed control at torque control I 4500 4500 4500
Cn−15 Speed level at which output brake
command
100 100 100
