RH5 8.2 List of Software Settings SERVICE MANUAL 8.2−6 DA3SEC−85−470−B0 Real ROM address Description Default 0F AD36 (003B66) 0F AD37 (003B67) 0F AD38 (003B68) 0F AD39 (003B69) 7AD36 7AD37 7AD38 7AD39 Distance from head …
8.2 List of Software Settings
SERVICE MANUAL
RH5
8.2−5
DA3SEC−85−470−B0
Real
ROM
address
Description Default
0FFFEC
(06806C)
7FFEC Transfer complete (R1RD) command output to host SW
0: Does not output R1LD
1: Outputs R1LD
1
0FAD14
(003B44)
0FAD15
(003B45)
7AD14
7AD15
Camera axis maximum speed (PTP) Low
Camera axis maximum speed (PTP) High
40
01
0FAD16
(003B46)
0FAD17
(003B47)
7AD16
7AD17
Camera axis maximum speed (JOG) Low
Camera axis maximum speed (JOG) High
16
00
0FAD18
(003B48)
0FAD19
(003B49)
7AD18
7AD19
Camera axis acceleration (ORG) Low
Camera axis acceleration (ORG) High
0A
00
0FAD1A
(003B4A)
7AD1A Camera axis acceleration (PTP) 40
0FAD1B
(003B4B)
7AD1B Camera axis maximum speed (ORG) 20
0FAD22
(003B52)
0FAD23
(003B53)
0FAD24
(003B54)
0FAD25
(003B55)
7AD22
7AD23
7AD24
7AD25
ZL axis standby coordinate position
30−feeder *
2
= 1637.000 mm (88H, FAH, 18H, 00H)
40−feeder *
2
= 2685.000 mm (48H, F8H, 28H, 00H)
RHII = 2689.000 mm (E8H, 07H, 29H, 00H)
E8
07
29
00
0FAD26
(003B56)
0FAD27
(003B57)
0FAD28
(003B57)
0FAD29
(003B59)
7AD26
7AD27
7AD28
7AD29
ZR axis standby coordinate position
30−feeder *
2
= 0.000 mm (00H, 00H, 00H, 00H)
40−feeder *
2
= 0.000 mm (00H, 00H, 00H, 00H)
00
00
00
00
0FAD2E
(003B5E)
0FAD2F
(003B5F)
0FAD30
(003B60)
0FAD31
(003B61)
7AD2E
7AD2F
7AD30
7AD31
Distance from head to camera origin (X direction)
Current model: 380.000 mm (60H, CCH, 05H, 00H)
Standard model: 380.000 mm (60H, CCH, 05H, 00H)
Large model: 558.000 mm (B0H, 83H, 08H, 00H)
60
CC
05
00
0FAD32
(003B62)
0FAD33
(002B63)
0FAD34
(003B64)
0FAD35
(003B65)
7AD32
7AD33
7AD34
7AD35
Distance from head to light source (2) (X direction)
Current model: 086.000 mm (F0H, 4FH, 01H, 00H)
Standard model: 086.000 mm (F0H, 4FH, 01H, 00H)
Large model: 086.000 mm (F0H, 4FH, 01H, 00H)
RHII: −90.000 mm (70H, A0H, FEH, FFH)
70
A0
FE
FF
RH5
8.2 List of Software Settings
SERVICE MANUAL
8.2−6
DA3SEC−85−470−B0
Real
ROM
address
Description Default
0FAD36
(003B66)
0FAD37
(003B67)
0FAD38
(003B68)
0FAD39
(003B69)
7AD36
7AD37
7AD38
7AD39
Distance from head to machine origin (X direction)
Current model: 102.000 mm (70H, 8EH, 01H, 00H)
Standard model: 102.000 mm (70H, 8EH, 01H, 00H)
Large model: 102.000 mm (70H, 8EH, 01H, 00H)
RHII: 0.000 mm (00H, 00H, 00H, 00H)
00
00
00
00
0FAD3A
(003B6A)
0FAD3B
(003B6B)
0FAD3C
(003B6C)
0FAD3D
(003B6D)
7AD3A
7AD3B
7AD3C
7AD3D
Distance from head to machine origin (Y direction)
Current model: 390.000 mm (70H, F3H, 05H, 00H)
Standard model: 259.000 mm (B8H, F3H, 03H, 00H)
Large model: 390.000 mm (70H, F3H, 05H, 00H)
RHII: 235.000 mm (F8H, 95H, 03H, 00H)
F8
95
03
00
0FAD3E
(003B6E)
0FAD3F
(003B6F)
0FAD40
(003B70)
0FAD41
(003b71)
7AD3E
7AD3F
7AD40
7AD41
XY table moving coordinate (X direction) when recognizing guide pin
Current model, board transfer: right to left
X = −290.000 mm (30H, 93H, FBH, FFH)
Current model, board transfer: left to right (reverse)
X = − 056.000 mm (40H, 25H, FFH, FFH)
Standard model, board transfer: right to left
X = − 290.000 mm (30H, 93H, FBH, FFH)
Standard model, board transfer: right to left (reverse)
X = − 056.000 mm (30H, 25H, FBH, FFH)
Large model, board transfer: right to left
X = − 29.000 mm (30H, 93H, FBH, FFH)
Large model, board transfer: left to right (reverse)
X = − 056.000 mm (40H, 25H, FFH, FFH)
High speed model, board transfer: right to left
X = − 245.000 mm (F8H, 42H, FCH, FFH)
30
93
FB
FF
0FAD42
(003B72)
0FAD43
(003B73)
0FAD44
(003B74)
0FAD45
(003B75)
7AD42
7AD43
7AD44
7AD45
XY table moving coordinate (Y direction) when recognizing guide pin
Current model, board flow: right to left
Y = −360.000 mm (C0H, 81H, FAH, FFH)
Current model, board flow: left to right (reverse)
Y = −360.000 mm (C0H, 81H, FAH, FFH)
Standard model, board flow: right to left
Y = −230.000 mm (90H, 7DH, FCH, FFH)
Standard model, board flow: left to right (reverse)
Y = −230.000 mm (90H, 7DH, FCH, FFH)
Large model, board flow: right to left
Y = − 360.000 mm (C0H, 81H, FAH, FFH)
Large model, board flow: left to right (reverse)
Y = −360.000 mm (C0H, 81H, FAH, FFH)
90
7D
FC
FF
0FAD46
(003B76)
0FAD47
(003B77)
7AD46
7AD47
Sets the number of times to use compulsory refueling function. 64
00
0FAD46
(003B76)
0FAD47
(003B77)
7AD46
7AD47
Determines the number of compulsory refueling. 01
00
8.2 List of Software Settings
SERVICE MANUAL
RH5
8.2−7
DA3SEC−85−470−B0
=REFERENCE=
* Machine setting can be done with the following data settings:
x Machine not having the recognition unit:
Self−correction board connection option SW: 0
Pulse motor board connection option SW: 0
Number of cameras: 0
Camera installation position: 0
x Machine having the recognition unit with fixed camera:
(1) Camera is fixed at insertion position (single board flow)
Self−correction board connection option SW: 1
Pulse motor board connection option SW: 0
Number of cameras: 1
Camera installation position: 1
(2) Camera is fixed at recognition position (double board flow)
Self−correction board connection option SW: 1
Pulse motor board connection option SW: 0
Number of cameras: 1
Camera installation position: 2
