RH5
4.1 Inspection Check List
SERVICE MANUAL
4.1−4
DA3SEC−80−020−B0
4.1.3 Insertion Head Unit
Roll pin
Guide chuck
Insertion pusher
Insertion pusher rubber
Groove
Inspection
Period Inspection item
x Make sure that guide chuck open/close movement is smooth.
x Make sure that dust does not build up in the guide chuck groove.
D
a
il
y
x Make sure that the insertion pusher fixing roll pin is not bent or damaged.
Daily
x Make sure that the insertion pusher rubber is not worn or damaged.
x Make sure that the vertical sliding section of the insertion pusher moves
smoothly.
Oiling
Part
number
Oiling point Oil type
Oil
volume
Period Lubrication method
[1] Sliding unit
Machine
oil
Moder−
ate
amount
Weekly
x Remove all dirt adhering on the
surface completely and apply a
thin coat of grease.
Sensor
x
Make
sure
that
lubricant
does
not
Insertion
pusher
Daily
x
M
a
k
e sure t
h
at
l
u
b
r
i
cant
d
oes not
come in contact.
4.1 Inspection Check List
SERVICE MANUAL
RH5
4.1−5
DA3SEC−80−020−B0
4.1.4 Insertion Drive Unit
[1] Cam
[2] Cam follower
[2] Cam follower
[1] Cam
[1] Cam
Reduction
gear
Oil
Oiling
Part
number
Oiling point Oil type
Oil
volume
Period Lubrication method
[1] Cam
Moder
x Remove all dirt adhering on the
surface
and
apply
a
[2] Cam follower
Grease
Moder−
ate
Weekly
sur
f
ace comp
e
e
yan
d
app
l
ya
thin coat of grease.
[3]
Lever pivot
bearing
amount
y
x Grease gun
RH5
4.1 Inspection Check List
SERVICE MANUAL
4.1−6
DA3SEC−80−020−B0
4.1.5 Transfer Chuck
(2) Pin pivot 2
[1] Pin pivot 1
Transfer chuck
rubber
Transfer chuck
claw
Inspection
Period Inspection item
x Make sure that the transfer chuck opens/closes smoothly.
Daily
x Make sure that the transfer chuck claw is not worn or damaged.
D
a
il
y
x Make sure that the transfer chuck rubber is not worn or damaged.
x Make sure to remove dust adhering on the surface. (tooth brush)
Oiling
Part
number
Oiling point Oil type
Oil
volume
Period Lubrication method
[1] Pin pivot [1] Grease
Moder−
ate
amount
Weekly
x Remove all dirt adhering on the
surface completely and apply a
thin coat of grease.
(2) Pin pivot (2)
Machine
oil
1−2
drops
2 weeks
x Apply 1 or 2 drops to pin pivot.
