7.2 AC Servomotor Adjustment
SERVICE MANUAL
RH5
7.2−19
DA3SEC−84−300−A0
User Constant Cn−01 (Memory Switch) List
Selected
item
Bit No. De−
fault
Description Reference
Sequence input 0 0 Turns ON/OFF servo via external input (SV−ON) 0
1 Normally being ON.
1
SR
BY
l
0 Uses external input (SEN). 0
SR BY only
1 Regards the AC motor as high speed automatically inside
the servo pack regardless of whether SEN signal is input
or not.
2 0 Disables driving in normal rotation via P−OT signal. 0
1 Enables driving in normal rotation normally.
3 0 Disables driving in reverse rotation via N−OT signal. 0
1 Enables driving in reverse rotation normally.
Input signal 4 0 Uses IN−A input. 0
1 Regards IN−A as “0” inside the sevo pack regardless of
whether IN−A signal is input or not.
5 0 Uses IN−B input. 0
1 Regards IN−B as “0” inside the sevo pack regardless of
whether IN−B signal is input or not.
Abnormal stop 6 0 <DB stop>
Applies the dynamic brake to stop the motor.
0
1 <Free run stop>
Stops the motor in free running mode.
7 0 <DB OFF after applying DB>
Releases the dynamic brake even after the motor has
stopped.
0
1 <DB ON after applying DB>
Applies the dynamic brake even after the motor has
stopped.
8 0 Follow the same procedure as in bit No. 6 for stopping
during overtraveling.
0
1 <Zero speed stop during overtraveling>
Apply the motor to stop with the torque set in the user
constant Cn−06 during overtraveling.
9 0 BB is applied after zero stop during overtraveling 0
1 Performs zero clamp after zero stop during overtraveling.
RH5
7.2 AC Servomotor Adjustment
SERVICE MANUAL
7.2−20
DA3SEC−84−300−A0
Selected
item
Bit No. De−
fault
Description Reference
Mode switch (Only
speed control)
D/C 0/0 <Torque command>
It can be activated when the set torque vale is conformed
to user constant Cn−0C.
0/1 <Speed command>
It can be activated when the set value is conformed to
user constant Cn−0C.
00
1/0 <Acceleration>
It can be activated when the set value is conformed to
user constant Cn−0E.
1/1 Mode switch function not supported
External brake E 0 No brake command function 0
1 Brake command function supported
Overload alarm F 0 No overload alarm function 0
1 Overload alarm function supported
=REFERENCE=
x Bit No. 8: Follow the same procedure as in bit No. 6 for abnormal stopping when controlling the
torque.
x Bit No.09: Selects 0 or 1 after completing zero speed stop is selected.
x Bit No. C/D: Selects the conditions for activating the mode switch.
When the mode switch activates, the speed control will be switched to P control. This
is, however, available only for controlling the speed.
7.2 AC Servomotor Adjustment
SERVICE MANUAL
RH5
7.2−21
DA3SEC−84−300−A0
User Constant Cn−01 (Memory Switch) List
Selected
item
Bit
No.
De−
fault
Description Command input Sequence
signal input
Refer−
ence
Control
mode
B/A 0/0 <Speed control>
x Controls the speed
normally.
x Regards ICN−24 (P−CON
)
as a changeover signal for
P/PI control.
Speed command (IN−A)
Auxiliary command input
(IN−B)
P−CON
OFF: PI control
ON: P control
0/0
0/1 <Speed control with zero
clamp function>
x Stops the motor with zero
speed aside from the
speed command.
x Regards ICN−24 (P−CON
)
as a zero clamp ON/OFF
signal.
P−CON
OFF: Zero
clamp OFF
ON: Zero
clamp ON
1/0 <Torque control 1>
x Controls output torque from
the motor via torque
command (IN−A).
x IN−B cannot be used.
Torque command
(IN−A)
None
1/1 <Torque control 2>
x Use ICN−24 (P−CON
)
as the switching
signal−selectable
between torque control
and speed control.
In torque controlling:
x Controls output torque from
the motor via torque
command (IN−B).
x Speed limit can be
controlled with remote
control. (IN−A)
Speed can be controlled in
both CCW and CW
directions via IN−A voltage
(+).
In torque control:
Torque command (IN−B)
Speed limit (IN−A)
In speed control:
Speed command (IN−A)
=REFERENCE=
x Outside the limit
speed range, the
torque proportional to
the difference with the
limit speed is fed back
negatively to take
back the speed to
within the limit range.
Therefore, the motor
speed limit value
varies according to
the load condition.
x Contact us the motor
speed decreases
continuously by
torque command
P−CON
OFF: Torque
control
ON: Speed
control
