5.37 Using the Digital Sequence Timer
SERVICE MANUAL
RH5
5.37−1
DA3SEC−83−9V0−A0
5.37 Using the Digital Sequence Timer
DA3SEC−83−9V0−A0
Sentence No.
5.37.1 Preparation
1. Turn power ON. (The initial screen will appear.)
2. Press “REQ” − “F6” (MORE) − “F1” (INITIAL DATA SET) − “F2” (MACHINE DATA SET) − “F6”
(MORE) in the order presented.
3. Using the arrow keys, set the digital sequence timer to “EDIT” and press “ENTER”.
4. Press “ENTER” again to complete the setting.
5. Press “ESC” o“F6” (MORE) o “REQ” o “F6” (TIMER).
6. The digital sequence timer screen appear with the function keys “F1” through “F6” at the lower part of
the screen.
ANGLE
CHANNEL
MODE
359
01
OFF
F1
(CH)
F2
(SET)
F3
(ON)
F4
(OFF)
F5
(T)
F6
(CLR)
=REFERENCE=
Turning power OFF and ON automatically sets the digital sequence timer to “ PROHIBIT UPDATE
“.
RH5
5.37 Using the Digital Sequence Timer
SERVICE MANUAL
5.37−2
DA3SEC−83−9V0−A0
5.37.2 Procedure
(1) To clear all data in all channels:
CH
(F1)
9
8
CLR
(F6)
(2) To clear data in a specified channel:
(Ex: Clears CH17 data)
CH
(F1)
1
7
CLR
(F6)
(3) Origin setting
(The stop position of the current rotary encoder will be set as the origin.)
CH
(F1)
0
T
(F5)
SET
(F2)
SET
(F2)
(4) Angle setting
Ex.: To set ON timing to 190q and OFF timing to 280q at CH 15.
CH
(F1)
1
5
SET
(F2)
ON
(F3)
1
9
SET
(F2)
0
OFF
(F4)
2
8
SET
(F2)
0
=REFERENCE=
The ON timing and OFF timing of the selected channel will be set.
Input angle range: 0−359q
