2.10 Drive Lever Arrangement
SERVICE MANUAL
RH5
2.10−1
DA3SEC−82−310−A0
2.10 Drive Lever Arrangement
DA3SEC−82−310−A0
Sentence No.
Upper drive
RH5
2.10 Drive Lever Arrangement
SERVICE MANUAL
2.10−2
DA3SEC−82−310−A0
Lower drive
No. Name Qty
1 For insertion pusher 1
2 For head swivel 1
3 For feeding 1
4 For cutter 1
5 For cutter 1
6 For transfer 1
7 For head up/down 1
8 For head up/down 1
9 For anvil up/down 1
10 For cut & clinch 1
11 For guide pin up/down 1
12 For anvil swivel 1
