8.2 List of Software Settings SERVICE MANUAL RH5 8.2−7 DA3SEC−85−470−B0 =REFERENCE= * Machine setting can be done with the following data settings: x Machine not having the recognition unit: Self−correction board connect…
RH5
8.2 List of Software Settings
SERVICE MANUAL
8.2−6
DA3SEC−85−470−B0
Real
ROM
address
Description Default
0FAD36
(003B66)
0FAD37
(003B67)
0FAD38
(003B68)
0FAD39
(003B69)
7AD36
7AD37
7AD38
7AD39
Distance from head to machine origin (X direction)
Current model: 102.000 mm (70H, 8EH, 01H, 00H)
Standard model: 102.000 mm (70H, 8EH, 01H, 00H)
Large model: 102.000 mm (70H, 8EH, 01H, 00H)
RHII: 0.000 mm (00H, 00H, 00H, 00H)
00
00
00
00
0FAD3A
(003B6A)
0FAD3B
(003B6B)
0FAD3C
(003B6C)
0FAD3D
(003B6D)
7AD3A
7AD3B
7AD3C
7AD3D
Distance from head to machine origin (Y direction)
Current model: 390.000 mm (70H, F3H, 05H, 00H)
Standard model: 259.000 mm (B8H, F3H, 03H, 00H)
Large model: 390.000 mm (70H, F3H, 05H, 00H)
RHII: 235.000 mm (F8H, 95H, 03H, 00H)
F8
95
03
00
0FAD3E
(003B6E)
0FAD3F
(003B6F)
0FAD40
(003B70)
0FAD41
(003b71)
7AD3E
7AD3F
7AD40
7AD41
XY table moving coordinate (X direction) when recognizing guide pin
Current model, board transfer: right to left
X = −290.000 mm (30H, 93H, FBH, FFH)
Current model, board transfer: left to right (reverse)
X = − 056.000 mm (40H, 25H, FFH, FFH)
Standard model, board transfer: right to left
X = − 290.000 mm (30H, 93H, FBH, FFH)
Standard model, board transfer: right to left (reverse)
X = − 056.000 mm (30H, 25H, FBH, FFH)
Large model, board transfer: right to left
X = − 29.000 mm (30H, 93H, FBH, FFH)
Large model, board transfer: left to right (reverse)
X = − 056.000 mm (40H, 25H, FFH, FFH)
High speed model, board transfer: right to left
X = − 245.000 mm (F8H, 42H, FCH, FFH)
30
93
FB
FF
0FAD42
(003B72)
0FAD43
(003B73)
0FAD44
(003B74)
0FAD45
(003B75)
7AD42
7AD43
7AD44
7AD45
XY table moving coordinate (Y direction) when recognizing guide pin
Current model, board flow: right to left
Y = −360.000 mm (C0H, 81H, FAH, FFH)
Current model, board flow: left to right (reverse)
Y = −360.000 mm (C0H, 81H, FAH, FFH)
Standard model, board flow: right to left
Y = −230.000 mm (90H, 7DH, FCH, FFH)
Standard model, board flow: left to right (reverse)
Y = −230.000 mm (90H, 7DH, FCH, FFH)
Large model, board flow: right to left
Y = − 360.000 mm (C0H, 81H, FAH, FFH)
Large model, board flow: left to right (reverse)
Y = −360.000 mm (C0H, 81H, FAH, FFH)
90
7D
FC
FF
0FAD46
(003B76)
0FAD47
(003B77)
7AD46
7AD47
Sets the number of times to use compulsory refueling function. 64
00
0FAD46
(003B76)
0FAD47
(003B77)
7AD46
7AD47
Determines the number of compulsory refueling. 01
00
8.2 List of Software Settings
SERVICE MANUAL
RH5
8.2−7
DA3SEC−85−470−B0
=REFERENCE=
* Machine setting can be done with the following data settings:
x Machine not having the recognition unit:
Self−correction board connection option SW: 0
Pulse motor board connection option SW: 0
Number of cameras: 0
Camera installation position: 0
x Machine having the recognition unit with fixed camera:
(1) Camera is fixed at insertion position (single board flow)
Self−correction board connection option SW: 1
Pulse motor board connection option SW: 0
Number of cameras: 1
Camera installation position: 1
(2) Camera is fixed at recognition position (double board flow)
Self−correction board connection option SW: 1
Pulse motor board connection option SW: 0
Number of cameras: 1
Camera installation position: 2
RH5
8.2 List of Software Settings
SERVICE MANUAL
8.2−8
DA3SEC−85−470−B0
= MEMO =
