7.4 File Management (for the System Administrator) At the [Maintenance B] screen, select [File Administrator] to display the [File Administrator] screen. Drive Selection Combo Box Select the drive here. /fd0: Floppy disk…

6. Select the file to be copied from the list in the right pane (more than one file may

be selected).

7. Press the [←] key to copy the selected file to the floppy disk. After verifying that

copying is completed, remove the floppy disk and press [Close].

6. Select the file to be copied from the list in the left pane (more than one file may be

selected).

7. Press the [→] key to copy the floppy disk to the machine file. After verifying that

copying is completed, remove the floppy disk and press [Close].

Part 2 Chapter 7 Data Administration

Edition 2.0 2-7-12 XP-142E System Reference

7.4 File Management (for the System Administrator)

At the [Maintenance B] screen, select [File Administrator] to display the [File

Administrator] screen.

Drive Selection Combo Box

Select the drive here.

/fd0: Floppy disk drive

/sd0: Machine hard disk drive

Drive/Directory File List

Double click any of the directory names to open that directory.

Double click this item to return to the upper directory.

Single click a file name to select a file. (Multiple selections are possible)

Drive/directory

file list

Drive selection

combo box

XP1S2175E

Part 2 Chapter 7 Data Administration

Edition 2.0 2-7-13 XP-142E System Reference

Operation Button Explanations

Click these buttons to copy files in the direction of the arrow.

Note: A file cannot be copied to the directory it is already in.

Select all displayed files.

Reverse all file selections/deselections.

Delete all selected files. A confirmation message appears before

deleting the file.

Note: When deleting files from the machine’s disk drive (/sd0), be certain

not to delete any files required by the system. If system files are

deleted the machine will not start.

Close this screen.
