Code: 1D00500B Display: Repeated pattern matching of left leads Cause: Lead detection failed. Remedy: Replace the parts for which the error occurred or check the part data is correct. If the part data is correct, check t…
Code: 1D005006
Display: Y-direction size error
Cause: Patter matching was successful, however the Y-side body size is over the
permissible value (Part data Body Length Tolerance).
Remedy: Confirm the part was picked up correctly and the Body Length Tolerance value is
not too small. Either exchange the erroneous part or correct the part data. If the
part data is correct, check the pickup position, the vision processing brightness,
the focus and the cleanliness of the lens.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly. (XP241, XP341)
Code: 1D005007
Display: Inspection seek line error
Cause: Inspection seek line error
Remedy: Replace the parts for which the error occurred or check the part data as well as the
template are correct.
If the part data and template data is correct, check the part pick-up condition is not
incorrect. Check the vision processing light brightness is functioning correctly, the
focus is adjusted correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly. (XP241, XP341)
Code: 1D005008
Display: Vision processing System Error
Cause: Vision processing System Error
Remedy: Internal error.
This error should not occur under normal circumstances.
Take a machine trace and send it to your Fuji representative.
Code: 1D005009
Display: Unable to detect leads.
Cause: The element information does not match the part.
Remedy: Check the part data is correct.
If the part data is correct, check the part pick-up condition is not incorrect.
Check the vision processing light brightness is functioning correctly, the focus is
When using multi-window processing check the image comparison.
If the images are different check the actual part height matches that in part data
and the nozzle holder is calibrated correctly.
Code: 1D00500A
Display: Element lead pattern matching error
Cause: The element information does not match the part.
Remedy: If the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-43 XP-142E System Reference
Code: 1D00500B
Display: Repeated pattern matching of left leads
Cause: Lead detection failed.
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Code: 1D00500C
Display: Repeated pattern matching of right leads
Cause: Lead detection failed.
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Code: 1D00500D
Display: Element leads are less than the specified value
Cause: Element leads are more than the specified value.
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Code: 1D00500E
Display: Element leads are more than the specified value
Cause: Element leads are more than the specified value.
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Part 8 Chapter 1 Error Code Messages and Corrective Measures
Edition 2.0 8-1-44 XP-142E System Reference
Code: 1D00500F
Display: Element lead pitch error
Cause: Element lead pitch error
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Code: 1D005010
Display: Bump size error
Cause: Bump size error
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check the
vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Code: 1D005011
Display: Element lead length error
Cause: Element lead length error
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Code: 1D005012
Display: Element lead width error
Cause: Element lead width error
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-45 XP-142E System Reference
