Edition 2.0 x XP-142E System Reference

Safety Guidelines

Fuji machines are designed and produced with safety as

one of our main considerations. However, even a

perfectly designed machine can be damaged, or someone

can still be injured if the user does not follow the safety

rules. It is the responsibility of the user to make sure all

safety rules are followed during operation and

maintenance.

Be sure to read these safety rules before operating the

machine.

(ESG00AEa)

1. About Symbols . . . . . . . . . . . . . . . . . . . . . . . . .1

2. Safety Rules for All Machine Types . . . . . . . . .2

3. Safety Rules for Individual Machine Types

(XP-1-series Machines) . . . . . . . . . . . . . . . . . .8

4. Safety Labels . . . . . . . . . . . . . . . . . . . . . . . . .10

5. The EMERGENCY STOP Buttons . . . . . . . . .16

1. About Symbols

(ESG0101a)

This section provides an explanation of the relevant safety precautions to be adhered to by both

operators and those responsible for maintaining the machine. An explanation of the warning

labels attached to the machine is also provided.

This manual employs the use of descriptive symbols and provides details of the level of danger

involved in certain operations to accompany the explanations of machine warning labels and

safety related items. Be sure you understand the meanings of these symbols before reading the

manual.

Hazard Definitions

Examples of Symbols Used

Hazard

A triangle is used to draw your attention to a hazard. The symbol inside

the triangle indicates the nature of the hazard (in this case, electrical shock).

Prohibition

A circle with a diagonal line is used to draw your attention to an operation

that is prohibited. The symbol inside the circle indicates the nature of the

operation (in this case, "Do not touch").

A circle is used to draw your attention to a mandatory action. In other words,

you are reguired to carefully carry out the given instructions.

Symbol Explanation

Failure to observe this hazard warning will lead to severe

injury or death.

DANGER

Failure to observe this hazard warning could lead to severe

injury or dath.

WARNING

Failure to observe this hazard warning may lead to personal

injury or damage to the machine.

CAUTION

Symbol Definition

Safety Guidelines

Edition 2.0 1 XP-142E System Reference
