8.3 System Restoration Using the Recovery Disk

(ESR0603b)

If the machine fails to boot up due to a corrupted or damaged hard disk, etc., a floppy

disk can be used to boot up the machine and reinstall the system. If a data backup has

been performed on the XP machine, the recovery will restore all data up the point when

the backup occurred. (This is only possible if a backup has been performed at the

machine.)

The system recovery procedure using the recovery disk is shown below.

The mouse must be used for all screen operations during the recovery.

Disk Configuration

Notes: The number of application disks may vary, depending on the version number.

Version

Recovery boot-up disks

Application disks (Apl)

Application disk (Apl.sym)

Application disk (Data)

System data backup disk

V1.00

2 disks

4 disks

1 disk

2 disks

1 disk

XP2S2401Eb

Boot up the XP using the recovery boot-up disk

HDD format

Copy from application disk

Copy boot parameters

Reboot

Restore user backup data

XP1S6013Eb

Part 2 Chapter 8 System Administration

Edition 2.0 2-8-5 XP-142E System Reference

8.3.1 Booting Up the XP With the Recovery Boot-Up Disk

Procedure

1. Insert the recovery boot-up disk into the floppy drive, then turn the XP power on.

The following dialog box displays when the machine boots up.

2. Press [OK] to display the dialog box shown below, or Press [Cancel] to abort the

recovery operation and shut down the machine. When [OK] is pressed the

following dialog box displays. Insert “recovery boot-up disk 2” into the floppy

drive.

3. When [OK] is pressed, a progress dialog box displays, and the required files are

copied. To abort the recovery operation and shut down the machine, press

[Cancel]. Select whether or not the hard disk is to be formatted.

Part 2 Chapter 8 System Administration

Edition 2.0 2-8-6 XP-142E System Reference

4. If [Yes] is pressed, a dialog box displays, and formatting begins. If [No] is pressed,

the formatting operation is skipped, and the system proceeds to the next step.

When only a section of the data or files in the hard disk are corrupted, it is possible

to restore the application by overwriting it. Therefore, if the status of the corrupt

data in the hard disk can be verified, the formatting step can be skipped.

5. After formatting is completed, the amount of vacant space on the formatted hard

disk is shown. Click [OK] to proceed to the next step.

6. If formatting fails, the following dialog box displays. Click [OK] to shut down the

XP machine.
