Code: 1101C70D

Display: Duplicate “Ref” (“Sequence Comment”) sequences exist for the same board.

Cause: Duplicate “Ref” (“Sequence Comment”) sequences exist for the same board.

Remedy: Create sequences so that “Ref” (“Sequence Comment”) sequences are not

duplicated for the same board.

Code: 1101C70E

Display: The “Place Before” sequence order is incorrect.

Cause: The “Place Before” sequence order is incorrect.

Remedy: Change the “Place Before” sequence order so that the “Place Before” sequence is

positioned before the “Ref” (“Sequence Comment”) sequence.

Code: 1101C70F

Display: An unavailable stage is set in the sequence data.

Cause: Stage 2 is set in the sequence data for the single side parts supplying machine.

Remedy: Either skip all of the sequence data specified in stage 2, or delete or move them to

stage 1.

Code: 1101D200

Display: If a joint mode is not specified, stage 2 cannot be set in the feeder setup data.

Cause: If joint mode is not specified, stage 2 cannot be set in the feeder setup data.

Remedy: Delete the stage 2 feeder data.

Code: 1101D201

Display: The part data is not found.

Cause: Data corresponding to the part number does not exist.

Remedy: Create the specified part number data, or specify an existing part number.

Code: 1101D202

Display: The Alt. Feeder number must be set to a separate feeder.

Cause: The slot number and next slot number are identical.

Remedy: Specify a “next slot” number which is different from the slot number.

Code: 1101D203

Display: A slot that has not been allocated a part number is set as an alternative slot.

Cause: A vacant slot number (no setting data) is set as the “next slot” number.

Remedy: Specify a slot number with a same part number.

Code: 1101D204

Display: The part number does not match that of the Alt. Feeder.

Cause: A slot number with a different part number setting has been specified as the “next

slot”.

Remedy: Specify a slot number with a same part number setting for use as the “next slot”.

Code: 1101D205

Display: The stage No./slot No. does not match the packaging type in part data.

Cause: A part number with a Packaging Type of “Tray” is set for a Feeder stage number

and slot number, or, a part number with a Packaging Type other than “Tray” is set

for a Tray stage number and slot number.

Remedy: For Feeder stage numbers and slot numbers, specify a part number with a

Packaging Type other than “Tray”. For Tray stage numbers and slot numbers,

specify a part number with Packaging Type of “Tray”.

Part 8 Chapter 1 Error Codes and Corrective Measures

Edition 2.0 8-1-3 XP-142E System Reference

Code: 1101D206

Display: The Alt. Feeder does not form a loop.

Cause: The next slot number does not have a loop structure.

Remedy: Set the next slot number so that a loop structure is created.

Code: 1101D207

Display: An unavailable stage is set in the feeder setup data.

Cause: Stage 2 is set in the feeder setup data for the single side parts supplying machine.

Remedy: Either delete the stage 2 feeder data, or move them to stage 1.

Code: 1101D300

Display: The Polarity Setting item”s [Not Use] setting is not supported.

Cause: XP-series machines do not support Polarity Setting”s “Not Use” setting. (Except

for program data transmitted from MCS/2.)

Remedy: Set the Polarity Setting to another setting.

Code: 1101D301

Display: The “Not Use” setting for the “Polarity Setting” item is not supported for MCS/2

programs received by XP-1-series machines.

Cause: MCS/2 programs received by XP-1-series machines with the “Polarity Setting”

item set to “Not Use” may only be used on XP-1-series machines.

Remedy: Set the “Polarity Setting” item to a setting other than “Not Use”.

Code: 1101D302

Display: The “Not Use” setting for the “Polarity Setting” item is not supported for MCS/2

programs received by XP-2 / XP-3-series machines.

Cause: MCS/2 programs received by XP-2 / XP-3-series machines with the “Polarity

Setting” item set to “Not Use” may only be used on XP-2 / XP-3-series machines.

Remedy: Set the “Polarity Setting” item to a setting other than “Not Use”.

Code: 1101D303

Display: The element data is required when the vision type is other than 10 or 18.

Cause: There is no ElementData although a Vision Type other than 10 or 18 is specified.

Remedy: Set the ElementData.

Code: 1101D305

Display: The settings at Scan Area X and Scan Area Y are outside the range that can be

handled by the Front (Rear) camera (short side: **.***; long side: **.***).

Cause: The settings at “Scan Area X” and “Scan Area Y” are outside the range that can be

handled by the Front (Rear) camera.

Remedy: Compare “Scan Area X” with “Scan Area Y.” The one with the lower value should

be set to be shorter than the short side of the field of view, and the one with the

higher value should be set to be shorter than the long side.

Code: 1101D306

Display: A setting of [128] exists at two consecutive Result lines for the Element item of a

Vision Type 230 or 231 part.

Cause: A setting of “128” exists at two consecutive Result lines for the Element item of a

Vision Type 230 or 231 part.

Remedy: Do not specify a “128” setting at two consecutive Result lines for the Element item

of a Vision Type 230 or 231 part.

Part 8 Chapter 1 Error Code Messages and Corrective Measures

Edition 2.0 8-1-4 XP-142E System Reference

Code: 1101D307

Display: When using Vision Type 230 or 231, set the P Pattern to 1 or 2.

Cause: For Vision Types 230 and 231, vision processing is only possible when the

“P Pattern” is set to 1 or 2.

Remedy: For Vision Types 230 and 231, set the “P Pattern” to 1 or 2.

Code: 1101D308

Display: A setting of [128] exists at the first Result line for the Element item of a Vision

Type 230 or 231 part.

Cause: A setting of “128” exists at the first Result line for the Element item of a Vision

Type 230 or 231 part.

Remedy: Specify a setting other “128” at the first Result line for the Element item of a Vision

Type 230 or 231 part.

Code: 1101D30A

Display: A Lead Length setting of other than 0 is required for vision types 20, 100, 124 and

180.

Cause: A “Lead Length” setting of “0” exists at the ElementData item of the Part Data,

even though a Vision Type of 20, 100, 124 or 180 is specified.

Remedy: Specify a suitable “Lead Length” setting.

Code: 1101D30B

Display: A Lead Quantity setting of other than 0 is required for vision types 20, 100, 124,

130and 180.

Cause: A “Lead Quantity” setting of “0” exists at the ElementData item of the Part Data,

even though a Vision Type of 20, 100, 124, 130 or 180 is specified.

Remedy: Specify a suitable “Lead Quantity” setting.

Code: 1101D30C

Display: A Lead Width setting of other than 0 is required for vision types 20, 100, 124, 130

and 180.

Cause: A “Lead Width” setting of “0” exists at the ElementData item of the Part Data,

even though a Vision Type of 20, 100, 124, 130 or 180 is specified.

Remedy: Specify a suitable “Lead Width” setting.

Code: 1101D30D

Display: Specify Lead Pitch if the Lead Quantity is 2 or greater.

Cause: A “Lead Pitch” setting of “0” existed when the “Lead Quantity” setting was 2 or

more.

Remedy: When the “Lead Quantity” setting is 2 or more, specify a “Lead Pitch” setting.

Code: 1101D30E

Display: Vision Type 230, 231 cannot be used to process BGAs with less than 12 balls.

Cause: Vision Type 230 and 231 vision processing is not possible for BGA parts with

fewer than 12 balls.

Remedy: Set the Element”s “Lead Quantity” so that the total number of balls is 12 or more.

If the total number of balls is fewer than 12, use Vision Type 18.

Part 8 Chapter 1 Error Codes and Corrective Measures
