Notes: Part 4 Chapter 2 Creating a T emplate From Existing Part Data Edition 2.0 4-2-18 XP-142E System Reference

[Angle] button

When this button is pressed, a seek line which is perpendicular to the edge can be set.

As only single seek lines can be generated by the automatic angle generation function, a

single line will be generated even if "Pair" is selected at the [Type] button.

[Angle] edit box

Specify the seek line angle here within a -360 ~ 360 range. The setting is specified in

"degree" units. If a value outside the -360 ~ 360 range is entered, a "Setting range

violation" error message displays, and the value cannot be changed.

Angle Increase/Decrease buttons ([▲] [▼])

Press these buttons to increase/decrease the seek line angle in 1-degree increments

within the -360 ~ 360 range.

[Length] edit box

A seek line length of 0.01 or more must be entered. The setting is specified in [mm]

units. The setting range is 0 ~ half the edit screen's diagonal line length. If a setting of

"0" is entered, an error message ("0 length line cannot be set") displays, and the value

cannot be changed. If a setting which exceeds the maximum value is entered, a "Line

which exceeds the current scale maximum cannot be set" error message displays, and the

value cannot be changed.

Length Increase/Decrease buttons ([▲] [▼])

Press these buttons to increase/decrease the seek line length in 0.01mm units within the

"0 ~ half the edit screen's diagonal line length" setting range.

Flag

Checks the flag* on/off status.

* Flag descriptions:

Set as Find … Find/Measure setting.

Position (P) … Accuracy calculation of position data at vision processing.

Angle (A) … Accuracy calculation of angle data at vision processing.

Size (S) … Size correction at vision processing.

Required Item (N) … Ensure a pattern match by setting a seek line that does not "Fail"

vision processing.

No Edge (E) … Set a "no edge" seek line that passes vision processing.

The flag settings are as follows:

(1) Inspection lines can only have "No Edge" and "Required Item" settings.

(2) If "No Edge" is selected, the [Set as Find], [Position (P)], [Angle (A)], and [Size (S)]

flag selections are canceled.

(3) If any one of the [Position (P)], [Angle (A)], or [Size (S)] flags is selected while the

[No Edge (E)] flag is selected, the [No Edge (E)] flag selection is canceled.

(4) The [Set as Find] flag cannot be selected while the [No Edge (E)] flag is selected.

The [No Edge (E)] flag selection must first be canceled before selecting the [Set as

Find] flag.

Part 4 Chapter 2 Creating a Template From Existing Part Data

Edition 2.0 4-2-17 XP-142E System Reference

Notes:

Part 4 Chapter 2 Creating a Template From Existing Part Data

Edition 2.0 4-2-18 XP-142E System Reference
