Code: 120501FD
Display: The tray height exceeds the maximum allowable height (32 mm).
Cause: The tray unit cannot be operated because the tray height exceeds the maximum
stack height (32.0 mm).
Remedy: Reduce the number of trays.
Code: 120501FF
Display: Tray retract confirmation sensor was unable to confirm tray pallet.
Cause: Attempted to advance the tray pallet to the part pick-up position, but the tray
retract confirmation sensor was unable to confirm the tray pallet.
Remedy: Check that there is a tray pallet in the tray unit. Check the tray retract
confirmation sensor.
Code: 12050205
Display: Panel vacuum error (XP)
Cause: Panel vacuum sensor (X021) was not activated. (XP)
Remedy: Check if the panel is clamped, or if vacuum is activated. (XP)
Code: 12050207
Display: Could not pick-up the nozzle.
Cause: Could not pick-up the nozzle
Remedy: Confirm the Z-axis pick-up position and the vacuum.
Code: 12050208
Display: The nozzle was dropped
Cause: The nozzle confirmation sensor is ON.
Remedy: Confirm the sensor’s is functioning properly, and adjustment position are correct.
Code: 12050209
Display: Air-blow did not take place within the required time.
Cause: Air-blow did not take place within the required time.
Remedy: Check the Air-blow confirmation sensor (X013).
Code: 12050440
Display: The large reject parts box is full.
Cause: The large reject parts box is full.
Remedy: Remove all parts from the large reject parts box.
Code: 12050441
Display: The medium reject parts box is full.
Cause: The medium reject parts box is full.
Remedy: Remove all parts from the medium reject parts box.
Code: 12050442
Display: The large reject parts box was removed while parts were being rejected.
Cause: The large reject parts box was removed while parts were being rejected.
Remedy: Set the large reject parts box inside the machine.
Code: 12050443
Display: The part cannot be rejected as the large reject parts box has been removed.
Cause: The part cannot be rejected as the large reject parts box has been removed.
Remedy: Set the large reject parts box inside the machine.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-27 XP-142E System Reference
Code: 12050444
Display: The large reject parts box has been removed.
Cause: The large reject parts box has been removed.
Remedy: Set the large reject parts box inside the machine.
Code: 12050445
Display: Unable to read the image.
Cause: Unable to read the image.
Remedy: If this error occurs frequently, a servo or vision processing board may require
replacement.
Code: 12052051
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12052052
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12052053
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12052054
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12052055
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12052056
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12052057
Display: Plus Limit overtravel.
Cause: An axis has passed the plus limit.
Remedy: The software limit may be incorrect. Move the axis to the mechanical stopper and
confirm the software limit position is correct.
Part 8 Chapter 1 Error Code Messages and Corrective Measures
Edition 2.0 8-1-28 XP-142E System Reference
Code: 12052058
Display: Minus Limit overtravel.
Cause: An axis has passed the minus limit.
Remedy: The software limit may be incorrect. Move the axis to the mechanical stopper and
confirm the software limit position is correct.
Code: 12052059
Display: Deviation over.
Cause: It is possible that the axis has collided with something.
Remedy: Check for any obstacles that may have caused an axis collision. If the axis is
against a mechanical stopper, check the calibration data is correct.
Code: 1205205A
Display: Deviation over
Cause: It is possible that the axis has collided with something.
Remedy: Check for any obstacles that may have caused an axis collision. If the axis is
against a mechanical stopper, check the calibration data is correct.
Code: 1205205B
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1205205C
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1205205D
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1205205E
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1205205F
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12052060
Display: Servo System Error
Cause: Servo System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-29 XP-142E System Reference
