Code: 1101D331

Display: Feed pitch is incorrect. The current feed pitch of ** was extrapolated from the

packaging name data.

Cause: The feed pitch is incorrect. The current feed pitch was extrapolated from the

packaging name data.

Remedy: If there is a problem with the extrapolated feed pitch, then specify the correct feed

pitch.

Code: 1101D332

Display: Feed pitch is incorrect. The current feed pitch is 2.

Cause: Feed pitch is incorrect. The current feed pitch is 2.

Remedy: If there is a problem with feed pitch of 2, then specify the correct feed pitch.

Code: 1101D333

Display: When performing the template command for a Vision Type other than 18, specify

Body Length (X) and Body Width (Y).

Cause: When performing the template command for a Vision Type other than 18, specify

Body Length (X) and Body Width (Y).

Remedy: Specify body length (X) and body width (Y), or change the vision type to 18.

Code: 1101D334

Display: The part size, Scan Area X, or Scan Area Y exceeds the vision processing range for

Front Sidelight (20 x 20).

Cause: The part size, Scan Area X, or Scan Area Y exceeds the vision processing range for

Front Sidelight (20 x 20).

Remedy: Specify camera position “0: Auto” or “2: Rear”.

Code: 1101D335

Display: When setting the Scan Area, set both Scan Area X and Scan Area Y at the same

time.

Cause: Only Scan Area X or Scan Area Y is set.

Remedy: When setting the Scan Area, set both Scan Area X and Scan Area Y at the same

time.

Code: 1101D3F0

Display: Compile error.

Cause: Vision processing Data Error

Remedy: Cannot read the part data.

Either the part data format or the part data is incorrect.

Revise the applicable part data.

Also, if the part data is administered over a network, check the network.

Code: 1101D3F1

Display: Compile error.

Cause: Vision processing Data Error

Remedy: Cannot read the part data.

Either the part data format or the part data is incorrect.

Revise the applicable part data.

Also, if the part data is administered over a network, check the network.

Part 8 Chapter 1 Error Code Messages and Corrective Measures

Edition 2.0 8-1-10 XP-142E System Reference

Code: 1101D3F2

Display: Compile error.

Cause: Vision processing Data Error

Remedy: Cannot read the part data.

Either the part data format or the part data is incorrect.

Revise the applicable part data.

Also, if the part data is administered over a network, check the network.

Code: 1101D3F3

Display: Compile error.

Cause: Vision processing Data Error

Remedy: Cannot read the part data.

Either the part data format or the part data is incorrect.

Revise the applicable part data.

Also, if the part data is administered over a network, check the network.

Code: 1101D3F4

Display: Compile error.

Cause: Vision processing Data Error

Remedy: Cannot read the part data.

Either the part data format or the part data is incorrect.

Revise the applicable part data.

Also, if the part data is administered over a network, check the network.

Code: 1101D3F5

Display: Compile error.

Cause: Vision processing Data Error

Remedy: Cannot read the part data.

Either the part data format or the part data is incorrect.

Revise the applicable part data.

Also, if the part data is administered over a network, check the network.

Code: 1101D3F6

Display: Compile error.

Cause: Vision processing Data Error

Remedy: Cannot read the part data.

Either the part data format or the part data is incorrect.

Revise the applicable part data.

Also, if the part data is administered over a network, check the network.

Code: 1101E300

Display: fiducial mark is not defined.

Cause: There is no fiducial mark setting in the production program.

Remedy: Specify a fiducial mark setting at the Edit Mark screen.

Code: 1101E301

Display: Board Skip Mark is not defined.

Cause: A board skip mark reading sequence exists, but there is no board skip mark

setting.

Remedy: Specify a board skip mark setting at the Edit Mark screen.

Part 8 Chapter 1 Error Codes and Corrective Measures

Edition 2.0 8-1-11 XP-142E System Reference

Code: 1101E400

Display: The Program polarity item’s [No] setting is not supported.

Cause: XP-series machines do not support Program Polarity”s “No” setting. (Except for

program data transmitted from MCS-S).

Remedy: Set the Program Polarity setting to “Yes”.

Code: 1101E401

Display: The “No” setting for the “Program Polarity” item is not supported for MCS/2

programs received by XP-1-series machines.

Cause: MCS/2 programs received by XP-1-series machines with the “Program Polarity”

item set to “No” may only be used on XP-1-series machines.

Remedy: Set the “Program Polarity” item to “Yes”.

Code: 1101E402

Display: The “No” setting for the “Program Polarity” item is not supported for MCS/2

programs received by XP-2 / XP-3-series machines.

Cause: MCS/2 programs received by XP-2 / XP-3-series machines with the “Program

Polarity” item set to “No” may only be used on XP-1-series machines.

Remedy: Set the “Program Polarity” item to “Yes”.

Code: 1101F001

Display: The total number of board skip mark read sequences and fiducial mark read

sequences exceeds 255.

Cause: The total number of board skip mark read sequences and fiducial mark read

sequences exceeds 255.

Remedy: Correct the sequence data so that the total number of board skip mark read

sequences (Sequence type:B) and fiducial mark read sequences (Sequence type: F)

is 255 or less.

Code: 1101F003

Display: Mark data does not exist for the specified mark name.

Cause: Either the mark name is input incorrectly in the sequence data, or the mark data

does not exist.

Remedy: Check the mark data. If mark data does exist, then check the mark name in the

sequence data.

Code: 1101F004

Display: The mark name is not specified.

Cause: The mark name field in the mark sequence is blank.

Remedy: Specify the mark name to match the existing mark data.

Code: 1101F005

Display: The global skip mark sequence must be positioned earlier in the program than the

board skip mark sequence.

Cause: The global skip mark sequence must be positioned earlier in the program than the

board skip mark sequence.

Remedy: Input the global skip mark sequence at an earlier sequence no. than the board skip

mark sequence.

Part 8 Chapter 1 Error Code Messages and Corrective Measures

Edition 2.0 8-1-12 XP-142E System Reference
