Code: 1404D000 Display: Mechanical chuck part transportation error. If the mechanical chuck is holding the part, manually remove it from the chuck. Cause: Mechanical chuck part transportation error. Remedy: If the mechan…

100%1 / 344
Code: 12300317
Display: Socket transmission error
Cause: Socket communication time out.
Remedy: Check the machine and connecting terminal network cables connections.
Check the status of connecting terminal and machine.
Code: 14011000
Display: Fiducial mark read error
Cause: Fiducial mark read error
Remedy: Check the correct mark data has been input. Confirm the program coordinates
and actual mark location correspond correctly. Check the mark is not dirty or
obstructed.
Code: 14011001
Display: Area check detected a value outside the permissible range
Cause: Area check detected a value outside the permissible range.
Remedy: Confirm the program coordinates and actual mark location correspond correctly.
The mark may have been read incorrectly.
Code: 14011002
Display: Pitch check detected a value outside the permissible range
Cause: Pitch check detected a value outside the permissible range.
Remedy: Confirm the program coordinates and actual mark location correspond correctly.
The mark may have been read incorrectly.
Code: 14011003
Display: Failed to read reference mark during cycle steal.
Cause: Failed to read reference mark during cycle steal.
Remedy: Check that the reference mark is clean.
Code: 14011004
Display: The reference mark deviation is more than 1mm. Re-measure the reference mark.
Cause: The calibration data value for the reference mark does not match the origin
position.
Remedy: Re-measure the reference mark and, if necessary, the origin position.
Code: 14011005
Display: Failed to acquire image of the reference mark.
Cause: Failed to acquire image of the reference mark.
Remedy: Check that the reference mark is not soiled, and check the reference mark
calibration data settings.
Code: 14011006
Display: A precise tray reference mark could not be found.
Cause: If the tray that was read is a precise tray, then either the mark is dirty or its
position is too far from the reference position.
If the tray is a reference tray, then the precise tray check sensor is out of
adjustment.
Remedy: For precise trays, check that the mark is clean.
Eliminate any play from the shuttle.
For standard trays, adjust the precise tray check sensor (X045).
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-37 XP-142E System Reference
Code: 1404D000
Display: Mechanical chuck part transportation error. If the mechanical chuck is holding the
part, manually remove it from the chuck.
Cause: Mechanical chuck part transportation error.
Remedy: If the mechanical chuck is holding the part, manually remove it from the chuck. If
the mark is dirty remove the mechanical chuck and clean the mark.
Code: 1404D001
Display: Compile error.
Cause: Vision processing Data Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1404D003
Display: Nozzle vision processing failed during cycle steal
Cause: Nozzle vision processing failed during cycle steal.
Check nozzle for scratches or foreign matter.
Check light radiation of strobe light.
Code: 1404D005
Display: A foreign matter was detected on the nozzle surface. Check that all parts have
been placed on the panel.
Cause: A foreign matter was detected on the nozzle surface.
Remedy: Check nozzle surface for foreign matter.
Code: 1404D006
Display: Nozzle center could not be detected.
Cause: Nozzle center could not be detected.
Remedy: Check that the nozzle diameter is correct.
Check that the surface of the nozzle is not scratched or dirty.
Check that the strobe light is emitting light properly.
Code: 1404D007
Display: Nozzle size check error
An error occurred while performing nozzle size check by vision processing.
Check that the machine nozzles match the nozzle settings in the data editor.
Check nozzle for scratches or foreign matter.
Check light radiation of strobe light.
Cause: An error occurred while performing nozzle size check by vision processing.
Remedy: Check that the machine nozzles match the nozzle settings in the data editor.
Check nozzle for scratches or foreign matter.
Check light radiation of strobe light.
Part 8 Chapter 1 Error Code Messages and Corrective Measures
Edition 2.0 8-1-38 XP-142E System Reference
Code: 1404D008
Display: A foreign substance has been detected on the nozzle. Vision processing may not
perform correctly.
Cause: A foreign substance has been detected on the nozzle. Vision processing may not
perform correctly.
Remedy: Check and correct the following conditions.
• Check the nozzle where the error is occurring for foreign substances, blemishes,
or scratches. Clean or replace the nozzle as necessary.
• Check the prism on the side where the error is occurring, and clean as
necessary.
• Check that a nozzle is mounted within the vision processing range. Install a
nozzle if one is not within the correct range. (XP142)
• If the camera image is too dark or light, the brightness setting is not correct.
Adjust brightness as specified in the manual.
• Check the vision processing position. If not correct adjust as specified in the
manual.
• If the strobe light is not working properly there may be a problem with the light
source. Check the wiring and replace the xenon bulb or servo PCB as necessary.
• If the camera image is not reading properly, there may be a problem with the
camera. Check the wiring and replace the camera or vision PCB as necessary.
Code: 14050000
Display: Corner dog vision error
Cause: Corner dog vision error
Remedy: Perform vision processing to confirm the corner dog adjustment.
Code: 14050001
Display: Corner dog limit error
Cause: Corner dog limit error
Remedy: Check a part was not mistakenly read during corner dog processing. Check the
corner dog has not come loose.
Code: 14050002
Display: Corner dog vision processing failed during cycle steal
Cause: Corner dog vision processing failed during cycle steal.
Remedy: Check vision processing at [Maintenance A] - [Corner Dog Adjustment].
If an error occurs, check the corner dog for scratches or foreign matter.
Code: 14050003
Display: Pick-up position measurement failed.
Cause: Failed to acquire an image of the feeder pick-up point when performing pick-up
position measurement.
Remedy: Check that the feeder is set correctly.
Check that the tape leaf position is correct.
Check that the parts tape is set correctly on the feeder.
Code: 14050004
Display: Failed to the read gauge chip during cycle steal.
Cause: Failed to the read gauge chip during cycle steal.
Remedy: Check gauge chip cleanliness and size.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-39 XP-142E System Reference
