Code: 120501C0
Display: The tray shutter is open.
Cause: The tray shutter open sensor is OFF.
Remedy: Check that the tray shutter is closed.
Check that the tray shutter position sensor is functioning correctly.
Code: 120501C1
Display: The tray shuttle is not at the origin position.
The elevator cannot be moved.
Confirm the tray shuttle position.
Cause: Because the tray shuttle is not at the origin position the tray cannot be moved on
the elevator.
Remedy: Confirm the tray shuttle position.
Check that the tray shuttle position sensor is functioning correctly.
Code: 120501C2
Display: The tray shuttle position confirmation sensor turned off while the elevator was
moving.
The elevator cannot be moved.
Confirm the tray shuttle position.
Cause: The magazine tray check sensor turned off while the elevator was moving.
Remedy: Confirm the tray shuttle position.
Check that the tray shuttle position sensor is functioning correctly.
Code: 120501C3
Display: The U-axis interlock sensor is blocked.
Cause: The U-axis interlock sensor was blocked while the shuttle was moving.
Remedy: Check that nothing is on top of the tray pallet.
Check that the U-axis interlock sensor is functioning correctly.
Code: 120501C4
Display: Tray parts cannot be picked up from the specified slot. Reduce the number of
trays.
Cause: Tray parts cannot be picked up from the specified slot.
Remedy: Reduce the number of trays.
Code: 120501C5
Display: The head cannot pass over a tray when picking up adjacent tray parts as the tray
height for the specified slot is too high. Reduce the number of trays.
Cause: The head cannot pass over a tray when picking up adjacent tray parts as the tray
height for the specified slot is too high.
Remedy: Reduce the number of trays.
Code: 120501C6
Display: The head cannot pass over a tray when ejecting the specified tray. Reduce the
number of trays.
Cause: The head cannot pass over a tray when ejecting the specified tray.
Remedy: Reduce the number of trays.
Part 8 Chapter 1 Error Code Messages and Corrective Measures
Edition 2.0 8-1-22 XP-142E System Reference
Code: 120501C7
Display: The head cannot pass over a tray when ejecting an adjacent tray as the tray height
for the specified slot is too high. Reduce the number of trays.
Cause: The head cannot pass over a tray when ejecting an adjacent tray as the tray height
for the specified slot is too high.
Remedy: Reduce the number of trays.
Code: 120501C8
Display: The nozzle piston is not lowered.
Cause: The reset cylinder raised confirmation sensor (X012) is on.
Remedy: Check that the reset cylinder raised confirmation sensor (X012) is functioning
correctly.
Push the nozzle piston by hand to check that the up/down action is smooth.
Code: 120501C9
Display: The U-axis interlock sensor is blocked.
Cause: Because the U-axis interlock sensor is blocked, the shuttle cannot move.
Remedy: Check that nothing is on top of the tray pallet.
Check that the U-axis interlock sensor is functioning correctly.
Code: 120501CA
Display: Unable to confirm whether the tray advanced The tray advance confirmation
sensor or the tray retract sensor is broken, or the tray pallet may have been
manually removed.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Cause: The shuttle should be retaining the tray pallet, however the tray advance
confirmation sensor could not detect the tray pallet.
Remedy: Confirm that both the tray advance confirmation sensor and tray retract sensor are
functioning correctly.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Code: 120501CB
Display: Unable to confirm whether the tray advanced. The tray advance confirmation
sensor, or tray retract sensor is broken or the tray pallet may have been manually
removed.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Cause: The tray retract confirmation sensor detected a tray pallet without a record of tray
pallet retention in memory.
Remedy: Confirm that both the tray advance confirmation sensor and tray retract sensor are
functioning correctly.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-23 XP-142E System Reference
Code: 120501CC
Display: Unable to confirm whether the tray retracted.
The tray retraction confirmation sensor is broken, or the tray pallet was manually
removed.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Cause: The shuttle should be retaining the tray pallet, however the tray advance
confirmation sensor could not detect the tray pallet.
Remedy: Check the tray advance confirmation sensor is functioning correctly.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Code: 120501CD
Display: Unable to confirm whether the tray retracted.
The tray retraction confirmation sensor is broken, or the tray pallet was manually
removed.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Cause: The shuttle should be retaining the tray pallet, however the tray retract
confirmation sensor could not detect the tray pallet.
Remedy: Check the tray retract confirmation sensor is functioning correctly.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Code: 120501CE
Display: Unable to confirm the tray pallet with the tray store check sensor.
The tray retract confirmation sensor or tray store sensor is broken, or the tray
pallet has been removed manually.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Cause: The shuttle should be retaining the tray pallet, however the tray store confirmation
sensor could not detect the tray pallet.
Remedy: Check the tray retract confirmation sensor and tray store check sensor are
functioning correctly.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Code: 120501CF
Display: Unable to confirm the tray pallet with the tray store check sensor.
The tray retract confirmation sensor or tray store sensor is broken, or the tray
pallet has been removed manually.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Cause: The shuttle should not be retaining the tray pallet, however the tray store
confirmation sensor detected the tray pallet.
Remedy: Check the tray retract confirmation sensor and tray store check sensor are
functioning correctly.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Part 8 Chapter 1 Error Code Messages and Corrective Measures
Edition 2.0 8-1-24 XP-142E System Reference
