Code: 1101F006
Display: When referencing fiducial marks for global / board skip mark sequences, the
board no. for the fiducial mark sequence must be 0.
Cause: When referencing fiducial marks for global / board skip mark sequences, the
board no. for the fiducial mark sequence must be 0.
Remedy: Set the board no. for a fiducial mark sequence to 0 when referencing fiducial
marks for global / board skip mark sequences.
Code: 1101F007
Display: The fiducial mark sequence must be positioned earlier in the program than the
global / board skip mark sequence.
Cause: The fiducial mark sequence must be positioned earlier in the program than the
global / board skip mark sequence.
Remedy: Input the fiducial mark sequence at an earlier sequence no. than the global / board
skip mark sequence.
Code: 1101F008
Display: A board skip mark sequence for a particular board no. must be positioned earlier
in the program than any placement sequences for that board.
Cause: A board skip mark sequence for a particular board no. must be positioned earlier
in the program than any placement sequences for that board.
Remedy: Input the board skip mark sequence for a particular board no. at an earlier
sequence no. than any placement sequences for that board.
Code: 1101F009
Display: The mark name is not specified. The No. 1 mark from the mark edit screen is
being used.
Cause: A mark name has not been specified in the sequence editor screen. The No. 1, type
F mark from the mark editor screen is being used.
Remedy: If there is a problem with the mark being used, then specify a different mark name
in the sequence edit screen.
Code: 11022B00
Display: As the proper data saved at the last shutdown could not be loaded, the data from
the previous shutdown was loaded.
Check the proper data, and re-measure or re-specify the data as necessary.
Cause: As the proper data saved at the last shutdown could not be loaded, the data from
the previous shutdown was loaded.
Remedy: Check the proper data, and re-measure or re-specify the data as necessary.
Code: 1110020B
Display: Production program reading Error
Cause: Production program reading Error.
Remedy: Read a different production program.
Code: 1110020C
Display: No response from MCS.
Cause: No response from MCS.
Remedy: Check MCS machine connections. Check MCS/2 power ON.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-13 XP-142E System Reference
Code: 1110020D
Display: An unsupported command was received from MCS/2
Cause: An unsupported command was received from MCS/2
Remedy: Take a machine trace and send it to your Fuji representative.
Code: 1110020E
Display: Unable to download program.
Cause: A production program for another machine was downloaded.
Remedy: Check production program machine type. Check the production program for slot
numbers that do not exist on the machine.
Code: 12040114
Display: Parts shortage.
Cause: The recovery limit has been reached.
Remedy: If the machine has stopped due to a lack of parts, supply the parts and continue
production.
If parts have not run out check the pick-up conditions and the condition of the
feeder.
Code: 12050001
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12050002
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12050003
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12050004
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12050005
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Part 8 Chapter 1 Error Code Messages and Corrective Measures
Edition 2.0 8-1-14 XP-142E System Reference
Code: 12050006
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12050007
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12050008
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12050009
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1205000A
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1205000B
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1205000C
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1205000D
Display: Operating System Error
Cause: Operating System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-15 XP-142E System Reference
