Code: 120501F2 Display: Strobe radiation error Cause: The strode did not come on during vision processing. Remedy: Use the JOG screen to check the strobe is functioning correctly. If the strobe does not radiate light, re…

Code: 120501E0

Display: The tape cutter did not arrive at the retract position. (Side *)

Cause: Tape cutter not able to return to retract position.

Remedy: Check hoses and wires, and check for any tape cutter obstacles.

Code: 120501E4

Display: Raised feeder detected. Check the feeder positions.

Cause: The feeder detection sensor was interrupted.

Remedy: Confirm the feeder is set. Check the wiring is correct and that nothing is

interrupting the sensor.

Code: 120501E9

Display: The tape cutter did not arrive at the advanced position. (Side *)

Cause: Tape cutter not able to return to advanced position.

Remedy: Check hoses and wires, and check for any tape cutter obstacles.

Code: 120501EB

Display: The reject parts tray is full.

Cause: The reject parts tray is full.

Remedy: Remove all of the reject parts from the reject parts tray.

Code: 120501ED

Display: Tray ejection failed.

Cause: The tray removal sensor was activated within the set timer limit when the tray was

removed, however the sensor switch remained ON.

Remedy: Check the tray is not stuck in the machine.

Check the tray removal sensor is functioning correctly.

Code: 120501EE

Display: Tray ejection failed.

Cause: The tray removal sensor was not activated within the set timer limit.

Remedy: Manually remove the empty tray from within the machine.

After resuming automatic operation, production will begin with the first part.

Code: 120501EF

Display: The reject parts tray was removed as parts were being rejected.

Cause: The reject parts tray was removed as parts were being rejected.

Remedy: Reset the reject parts tray.

Code: 120501F0

Display: Parts cannot be rejected as the tray is not in position.

Cause: Parts cannot be rejected as the tray is not in position.

Remedy: Reset the reject parts tray.

Code: 120501F1

Display: The reject parts tray has been removed.

Cause: The reject parts tray has been removed.

Remedy: Reset the reject parts tray.

Part 8 Chapter 1 Error Codes and Corrective Measures

Edition 2.0 8-1-25 XP-142E System Reference

Code: 120501F2

Display: Strobe radiation error

Cause: The strode did not come on during vision processing.

Remedy: Use the JOG screen to check the strobe is functioning correctly.

If the strobe does not radiate light, replace the Xenon tube.

Code: 120501F3

Display: Raised tape leaf detected. Check the condition of the tape leaf.

Cause: Raised tape leaf detected.

Remedy: Check the tape leaf.

Check the sensor wires and confirm nothing is obstructing the sensor.

Code: 120501F5

Display: The interlock at the tray removal confirmation position was activated. Locate and

remove the object that is triggering the sensor.

Cause: The interlock at the tray removal confirmation position was activated.

Remedy: Locate and remove the object that is triggering the sensor and check the wires.

Code: 120501F6

Display: The empty tray could not be picked up.

Cause: The tray was not picked-up for removal.

Remedy: Move the tray to the tray replacement position and remove the empty tray.

Check remover vacuum pressure.

Check for irregularities at the tray pick-up sensor.

Code: 120501FA

Display: Unable to determine whether the shuttle is retaining the tray.

Using the screen that displays once this error is closed, select whether the shuttle is

retaining the tray.

Cause: Unable to determine whether the shuttle is retaining the tray.

Remedy: Using the screen that displays once this error is closed, select whether the shuttle is

retaining the tray.

Code: 120501FB

Display: Unable to advance the shuttle.

Check the shuttle position.

Cause: Although the shuttle is advanced the shuttle origin position confirmation sensor is

ON.

Remedy: Check the position of the shuttle.

Check the shuttle origin position confirmation sensor is functioning correctly.

Code: 120501FC

Display: Unable to retract the shuttle.

Check the shuttle position.

Cause: Although the shuttle is retracted the shuttle origin position confirmation sensor is

not active.

Remedy: Check the position of the shuttle.

Check the shuttle origin position confirmation sensor is functioning correctly.

Part 8 Chapter 1 Error Code Messages and Corrective Measures

Edition 2.0 8-1-26 XP-142E System Reference

Code: 120501FD

Display: The tray height exceeds the maximum allowable height (32 mm).

Cause: The tray unit cannot be operated because the tray height exceeds the maximum

stack height (32.0 mm).

Remedy: Reduce the number of trays.

Code: 120501FF

Display: Tray retract confirmation sensor was unable to confirm tray pallet.

Cause: Attempted to advance the tray pallet to the part pick-up position, but the tray

retract confirmation sensor was unable to confirm the tray pallet.

Remedy: Check that there is a tray pallet in the tray unit. Check the tray retract

confirmation sensor.

Code: 12050205

Display: Panel vacuum error (XP)

Cause: Panel vacuum sensor (X021) was not activated. (XP)

Remedy: Check if the panel is clamped, or if vacuum is activated. (XP)

Code: 12050207

Display: Could not pick-up the nozzle.

Cause: Could not pick-up the nozzle

Remedy: Confirm the Z-axis pick-up position and the vacuum.

Code: 12050208

Display: The nozzle was dropped

Cause: The nozzle confirmation sensor is ON.

Remedy: Confirm the sensor’s is functioning properly, and adjustment position are correct.

Code: 12050209

Display: Air-blow did not take place within the required time.

Cause: Air-blow did not take place within the required time.

Remedy: Check the Air-blow confirmation sensor (X013).

Code: 12050440

Display: The large reject parts box is full.

Cause: The large reject parts box is full.

Remedy: Remove all parts from the large reject parts box.

Code: 12050441

Display: The medium reject parts box is full.

Cause: The medium reject parts box is full.

Remedy: Remove all parts from the medium reject parts box.

Code: 12050442

Display: The large reject parts box was removed while parts were being rejected.

Cause: The large reject parts box was removed while parts were being rejected.

Remedy: Set the large reject parts box inside the machine.

Code: 12050443

Display: The part cannot be rejected as the large reject parts box has been removed.

Cause: The part cannot be rejected as the large reject parts box has been removed.

Remedy: Set the large reject parts box inside the machine.

Part 8 Chapter 1 Error Codes and Corrective Measures

Edition 2.0 8-1-27 XP-142E System Reference
