Code: 120501BB
Display: Unable to retract the shuttle.
A retracted tray already exists.
Confirm the tray pallet position.
Close this error message and input the current tray slot number in the displayed
dialog.
Cause: An attempt was made to retract the shuttle, however, the tray pallet is already
retracted.
Remedy: Confirm the tray pallet position.
Check the tray advance position and tray retract position sensors are functioning
correctly.
Close this error message and input the current tray slot number in the displayed
dialog.
Code: 120501BC
Display: The tray pusher cannot be advanced.
Confirm the tray pusher position.
Cause: An attempt was made to advance the tray pusher, however the tray pusher retract
sensor did not turn off within the required time period.
Remedy: Confirm the tray pusher position.
Check that the tray pusher advance and retract confirmation sensors are
functioning correctly.
Code: 120501BD
Display: The tray pusher cannot be advanced.
Confirm the tray pusher position.
Cause: An attempt was made to retract the tray pusher after it advanced, however the
tray pusher advance confirmation sensor did not turn on within the required time
period.
Remedy: Confirm the tray pusher position.
Check that the tray pusher advance and retract confirmation sensors are
functioning correctly.
Code: 120501BE
Display: The tray pusher cannot be retracted.
Confirm the tray pusher position.
Cause: An attempt was made to retract the tray pusher, however the tray pusher advance
confirmation sensor remained ON for the required time period.
Remedy: Confirm the tray pusher position.
Check that the tray pusher advance and retract confirmation sensors are
functioning correctly.
Code: 120501BF
Display: The tray pusher cannot be retracted.
Confirm the tray pusher position.
Cause: An attempt was made to retract the tray pusher, however, after the tray pusher
advance sensor turned OFF, the tray pusher retract confirmation sensor remained
OFF for the required time period.
Remedy: Confirm the tray pusher position.
Check that the tray pusher retract and advance confirmation sensors are
functioning correctly.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-21 XP-142E System Reference
Code: 120501C0
Display: The tray shutter is open.
Cause: The tray shutter open sensor is OFF.
Remedy: Check that the tray shutter is closed.
Check that the tray shutter position sensor is functioning correctly.
Code: 120501C1
Display: The tray shuttle is not at the origin position.
The elevator cannot be moved.
Confirm the tray shuttle position.
Cause: Because the tray shuttle is not at the origin position the tray cannot be moved on
the elevator.
Remedy: Confirm the tray shuttle position.
Check that the tray shuttle position sensor is functioning correctly.
Code: 120501C2
Display: The tray shuttle position confirmation sensor turned off while the elevator was
moving.
The elevator cannot be moved.
Confirm the tray shuttle position.
Cause: The magazine tray check sensor turned off while the elevator was moving.
Remedy: Confirm the tray shuttle position.
Check that the tray shuttle position sensor is functioning correctly.
Code: 120501C3
Display: The U-axis interlock sensor is blocked.
Cause: The U-axis interlock sensor was blocked while the shuttle was moving.
Remedy: Check that nothing is on top of the tray pallet.
Check that the U-axis interlock sensor is functioning correctly.
Code: 120501C4
Display: Tray parts cannot be picked up from the specified slot. Reduce the number of
trays.
Cause: Tray parts cannot be picked up from the specified slot.
Remedy: Reduce the number of trays.
Code: 120501C5
Display: The head cannot pass over a tray when picking up adjacent tray parts as the tray
height for the specified slot is too high. Reduce the number of trays.
Cause: The head cannot pass over a tray when picking up adjacent tray parts as the tray
height for the specified slot is too high.
Remedy: Reduce the number of trays.
Code: 120501C6
Display: The head cannot pass over a tray when ejecting the specified tray. Reduce the
number of trays.
Cause: The head cannot pass over a tray when ejecting the specified tray.
Remedy: Reduce the number of trays.
Part 8 Chapter 1 Error Code Messages and Corrective Measures
Edition 2.0 8-1-22 XP-142E System Reference
Code: 120501C7
Display: The head cannot pass over a tray when ejecting an adjacent tray as the tray height
for the specified slot is too high. Reduce the number of trays.
Cause: The head cannot pass over a tray when ejecting an adjacent tray as the tray height
for the specified slot is too high.
Remedy: Reduce the number of trays.
Code: 120501C8
Display: The nozzle piston is not lowered.
Cause: The reset cylinder raised confirmation sensor (X012) is on.
Remedy: Check that the reset cylinder raised confirmation sensor (X012) is functioning
correctly.
Push the nozzle piston by hand to check that the up/down action is smooth.
Code: 120501C9
Display: The U-axis interlock sensor is blocked.
Cause: Because the U-axis interlock sensor is blocked, the shuttle cannot move.
Remedy: Check that nothing is on top of the tray pallet.
Check that the U-axis interlock sensor is functioning correctly.
Code: 120501CA
Display: Unable to confirm whether the tray advanced The tray advance confirmation
sensor or the tray retract sensor is broken, or the tray pallet may have been
manually removed.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Cause: The shuttle should be retaining the tray pallet, however the tray advance
confirmation sensor could not detect the tray pallet.
Remedy: Confirm that both the tray advance confirmation sensor and tray retract sensor are
functioning correctly.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Code: 120501CB
Display: Unable to confirm whether the tray advanced. The tray advance confirmation
sensor, or tray retract sensor is broken or the tray pallet may have been manually
removed.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
Cause: The tray retract confirmation sensor detected a tray pallet without a record of tray
pallet retention in memory.
Remedy: Confirm that both the tray advance confirmation sensor and tray retract sensor are
functioning correctly.
Using the screen that displays once this error is closed, select whether the shuttle is
retaining the tray.
