Code: 1101D311

Display: [Packaging Type] - [Feed Count] must be set to 3 or less when [Packaging Type]

- [Type] is set to 4 or 9.

Cause: The stick feeder “FeedCount” is set to 4 or more.

Remedy: When using the Stick Feeder and Grooved Stick Feeder packaging types, specify a

“FeedCount” setting of 3 or less.

Code: 1101D312

Display: The pick up point for the last tray parts exceeds the tray size in the X-direction.

Cause: The pick up point for the last tray parts exceeds the tray size in the X-direction.

Remedy: Specify a setting value which satisfies the following equation.

[Tray Length] ≥ { [Tray First Pickup Position X] x (-1) } + { [Tray Column Pitch] x

( [Tray Column Quantity] - 1) }

Code: 1101D313

Display: The pick up point for the last tray parts exceeds the tray size in the Y-direction.

Cause: The final pickup position for tray parts exceeds the tray”s Y-direction size.

Remedy: Specify a setting value which satisfies the following equation.

[Tray Width] ≥ [Tray First Pickup Position Y] + [Tray Row Pitch] x ( [Tray Row

Quantity] - 1 )

Code: 1101D314

Display: Tray Length is incorrect. Tray is not able to be ejected.

Cause: The length of the tray to be unloaded (Tray Type 0 or 2) is set as smaller than the

remover.

Remedy: Specify a “Tray Length” setting of 72 or higher.

Code: 1101D315

Display: Tray Width is incorrect. Tray is not able to be eject.

Cause: The width of the tray to be unloaded (Tray Type 0 or 2) is set as smaller than the

remover.

Remedy: Specify a “Tray Width” setting of 83 or higher.

Code: 1101D316

Display: Tray Dump Pick Position X is incorrect. Tray is not able to be eject.

Cause: The remover (nozzle used to unload trays) protrudes beyond the tray in the X-

direction when picking up a tray.

Remedy: Specify the “Tray Dump Pick Position X” setting so that the remover does not

protrude beyond the tray in the X-direction when picking up trays.

Code: 1101D317

Display: Tray Dump Pick Position Y is incorrect. Tray is not able to be eject.

Cause: The remover (nozzle used to unload trays) protrudes beyond the tray in the Y-

direction when picking up trays.

Remedy: Specify the “Tray Dump Pick Position Y” setting so that the remover does not

protrude beyond the tray in the Y-direction when picking up trays.

Code: 1101D318

Display: No template file.

Cause: Cannot locate a template file that matches the part type name of the part data for

Vision type 18.

Remedy: Prepare a template file that has a file name that matches the part type name.

Part 8 Chapter 1 Error Code Messages and Corrective Measures

Edition 2.0 8-1-6 XP-142E System Reference

Code: 1101D319

Display: No matching nozzle.

Cause: The nozzle data contains neither the nozzle specified by the NozzleName item (in

Part Type data), or a nozzle which satisfies the NozzleSizeMin to NozzleSizeMax

range setting.

Remedy: Specify the appropriate nozzle in the nozzle data.

Code: 1101D31A

Display: When using Vision Type 100 or 130, the Lead Quantity must be 5 or greater for the

first element.

Cause: When using Vision Type 100 or 130, the “Element” first line “Lead Quantity” was

less than 5.

Remedy: When using Vision Types 100 and 130, specify the “Element” first line “Lead

Quantity” as 5 or more.

Code: 1101D31B

Display: Tray cannot be removed. Input the tray thickness (4.00 mm - 25.40 mm).

Cause: The tray dimensions are outside the permissible XP tray specifications

(4.00 mm - 25.40 mm).

Remedy: Input a permissible tray thickness (4.00 mm - 25.40 mm).

Code: 1101D31C

Display: The nozzle interferes with the tray positioning plate when picking up parts.

(At the front side of the tray as seen from the front of the machine.)

Cause: The nozzle interferes with the tray positioning plate when picking up parts.

(At the front side of the tray as seen from the front of the machine.)

Remedy: Change the [Tray First Pickup Position Y] setting in the part data, or change one of

the following settings (as applicable) so that nozzles do not interfere with the tray

positioning plate.

*If [Direction] is set to 1 or 3, change the [Pick-up Point Offset X] setting.

*If [Direction] is set to 0 or 2, change the [Pick-up Point Offset Y] setting.

Code: 1101D31D

Display: The nozzle interferes with the tray positioning plate when picking up parts.

(The right side of the tray as seen from the front of the machine.)

Cause: The nozzle interferes with the tray positioning plate when picking up parts.

(The right side of the tray as seen from the front of the machine.)

Remedy: Change the [Tray First Pickup Position X] setting in the part data, or change one of

the following settings (as applicable) so that nozzles do not interfere with the tray

positioning plate.

*If [Direction] is set to 0 or 2, change the [Pick-up Point Offset X] setting.

*If [Direction] is set to 1 or 3, change the [Pick-up Point Offset Y] setting.

Code: 1101D31E

Display: The nozzle interferes with the tray positioning plate when picking up parts.

(The left side of the tray as seen from the front of the machine.)

Cause: The nozzle interferes with the tray positioning plate when picking up parts.

(The left side of the tray as seen from the front of the machine.)

Remedy: Change the [Tray First Pickup Position X] setting in the part data, or change one of

the following settings (as applicable) so that nozzles do not interfere with the tray

positioning plate.

*If [Direction] is set to 0 or 2, change the [Pick-up Point Offset X] setting.

*If [Direction] is set to 1 or 3, change the [Pick-up Point Offset Y] setting.

Part 8 Chapter 1 Error Codes and Corrective Measures

Edition 2.0 8-1-7 XP-142E System Reference

Code: 1101D31F

Display: The value set for Stand Off height is higher than or equal to the Part Height.

Cause: The value set for Stand Off height is higher than or equal to the Part Height.

Remedy: Enter a value lower than the Part Height.

Code: 1101D320

Display: The Z-axis target value exceeds the servo limit.

Placing Offset Z = *** (Min.: ***)

Cause: Operation with this part data causes the Z-axis to pass the minus limit.

Remedy: In Part Type Data, revise the Placing Offset Z value.

If there is no problem with the Placing Offset Z value, confirm the Part Height

value.

Code: 1101D321

Display: Parts using vision type 230 or 231 require at least one element with lead quantity

of two or more. (Excluding the second row of data in the matrix display.)

Cause: The element data for parts using vision type 230 or 231 does not have an element

with two or more leads.

Remedy: When using vision type 230 or 231, create at least one element with lead quantity

of two or more.

Code: 1101D322

Display: 2 or more Element lines are required for Vision Type 20.

Cause: For Vision Type 20, vision processing is only possible when the “Element” setting

occupies 2 or more lines.

Remedy: Specify 2 or more lines for the “Element” setting.

Code: 1101D323

Display: For Vision Type 124, the [Element] setting must occupy either 2 or 4 lines.

Cause: For Vision Type 124, vision processing is only possible when the “Element” setting

occupies either 2 or 4 lines.

Remedy: Specify either 2 or 4 lines for the “Element” setting.

Code: 1101D324

Display: For Vision Type 180, the total number of leads in [Lead Quantity] for the entire

element must be 2, 3, or 4.

Cause: For Vision Type 180, the total number of leads in “Lead Quantity” for the entire

element must be 2, 3, or 4.

Remedy: When using Vision Type 180, set the values for “Lead Quantity” so that the sum of

all leads for the element equals 2, 3, or 4.

Code: 1101D329

Display: The specified part size exceeds the scanning range (body length (X): 5 mm or less,

body width (Y): 4 mm or less) that can be handled by the camera for vision type

10.

Cause: The maximum part dimensions that may be specified when using vision type 10

are 5 mm for the body length (X) and 4 mm for the body width (Y). If the specified

part size exceeds these dimensions, the part may not be found or accuracy may be

negatively affected.

Remedy: When using vision type 10, only use parts with maximum dimensions of 5 mm for

the body length (X), and 4 mm for the body width (Y). For larger parts, create the

part data using vision type 18.
