2. System Output Signals
(ESR0502f)
Address Display Description
Y000 StartLamp START PB lamp
Y001 ReadyOnLamp READY ON lamp
Y002 Buzzer Buzzer
Y003 TimeCounter Time counter
Y004 Side1YellowLight Signal tower (Side 1 yellow)
Y005 Side1WhiteLight Signal tower (Side 1 white)
Y006 Side2YellowLight Signal tower (Side 1 yellow)
Y007 Side2WhiteLight Signal tower (Side 2 white)
Y008 RedLight Signal tower (red)
Y009 YellowLight Signal tower (yellow)
Y00A Green/BlueLight Signal tower (green/blue)
Y00B
Y00C WatchDogTmrClr Watchdog timer clear
Y00D StrobeLampA Strobe selection A
Y00E StrobeLampB Strobe selection B
Y00F StrobeCharge Strobe charge
Y010 FiducialLamp Fiducial lamp
Y011 MasterRelay Master relay
Y012 PowerOff Power off
Y013 Side2Enable Side 2 operation enabled
Y014 Side1Enable Side 1 operation enabled
Y015
Y016 VacuumPump Vacuum pump
Y017
Y018
Y019
Y01A
Y01B
Y01C PartsLamp Parts lamp
Y01D PartsPickUpDes Parts pick-up vacuum break
Y01E AirBlow Air blow
Y01F ResetCylinder Reset cylinder UP
Part 7 Chapter 2 System Output Signals
Edition 2.0 7-2-1 XP-142E System Reference
Address Display Description
Y020
Y021
Y022 GaugeChipVacuum Gauge chip vacuum
Y023
Y024 PcbRequest Panel request to previous machine
Y025 PcbAvailable Panel unloading enabled signal to next machine
Y026 FollowPermit Follow permit output
Y027
Y028 MainStLifterUp MAIN station UP
Y029 MainStLifterDown MAIN station DOWN
Y02A MainStationStp MAIN station stopper on
Y02B
Y02C
Y02D InStLifterUp IN station lifter UP
Y02E ConvMtrDec Conveyor motor deceleration command
Y02F Conv/WidthMtr Conveyor/Width change motor
Y030
Y031
Y032
Y033
Y034 Fluores.LampOn Fluorescent lamp on
Y035 ChgConv/Width Conveyor width change
Y036 ChgCw/Ccw Change motor direction
Y037 PcbVacuum Panel pick-up vacuum
Y038 Side1MfuDown MFU DOWN (Side 1)
Y039 Side1MfuUp MFU UP (Side 1)
Y03A Side1TapeCutFwd Tape cut forward (Side 1)
Y03B Side1TapeCutBwd Tape cut backward (Side 1)
Y03C Side2MfuDown MFU DOWN (Side 2)
Y03D Side2MfuUp MFU UP (Side 2)
Y03E Side2TapeCutFwd Tape cut forward (Side 2)
Y03F Side2TapeCutBwd Tape cut backward (Side 2)
Part 7 Chapter 2 System Output Signals
Edition 2.0 7-2-2 XP-142E System Reference
