3. Corrective Measures for Problems at the Machine This section describes possible problems at the machine and measures to correct these problems. 1. Star ting the Machine 2. Screen Displays 3. The READ Y ON and ST ART B…

“Nozzle information cannot be read from Nozzle spec file or Nozzle configuration file.”

Conditions: This error message may appear after the following command sequences.

When logging on

[Production] - [Nozzle Editor]

[Program] - [Editor] - [Nozzle]

[Program] - [Editor] - [Part] - [Part Type Edit] - Nozzle Name

Cause: For an unknown reason, some of the nozzle spec data could not be read.

Remedy: Restore the system data that can be backed up to floppy in [Maintenance B]

- [Backup], and then restart the machine.

“Proper data doesn’t exist. Please set the Proper data.”

Conditions: During the start up process, the machine may lock up with this message on the

touch panel. The touch panel will not respond, but clicking the OK button with

the mouse will open the Proper Data Editor.

Cause: For an unknown reason, the Proper data has been deleted.

Remedy: Load a backup Proper data file using procedure A or B below.

If the data was backed up on another machine, then the problem may recur. In

this case, the values must be specified using the machine’s Proper Data Editor.

A) If the Proper has been backed up in [Maintenance B] - [Backup], close the

Proper Data Editor and restore the system data using commands in the

[Backup] screen. Then restart the machine power.

B) If the Proper data has been backed up on a floppy disk using the [Save to

File] command, Load the file using the [Load from File] command in the

Proper Data Editor, and then close the Proper Data Editor. Shut down the

machine for a moment, and then restart the machine.

“Proper data out of range. Please set the Proper data.”

Conditions: During the start up process, the machine may lock up with this message on the

touch panel. The touch panel will not respond, but clicking the OK button with

the mouse will open the Proper Data Editor.

Cause: Certain Proper data values exceed their valid ranges or have contradictory

settings.

Remedy: Follow the procedure for loading a backup file as explained in the remedy to the

error message, “Proper data doesn’t exist. Please set the Proper data”, or directly

enter the Proper data values using the Proper Data Editor.

“Proper data reading error. The data may be corrupt. Please set the Proper data.”

Conditions: During the start up process, the machine may lock up with this message on the

touch panel. The touch panel will not respond, but clicking the OK button with

the mouse will open the Proper Data Editor.

Cause: The Proper data exists but, for an unknown reason, cannot be read. The Proper

data file may be damaged.

Remedy: Follow the procedure for loading a backup file as explained in the remedy to the

error message, “Proper data doesn’t exist. Please set the Proper data”.

Part 8 Chapter 2 Corrective Measures for Error Messages

that Appear without an Error Code

Edition 2.0 8-2-2 XP-142E System Reference

3. Corrective Measures for Problems at the Machine

This section describes possible problems at the machine and measures to correct these

problems.

1. Starting the Machine

2. Screen Displays

3. The READY ON and START Buttons

4. The CYCLE STOP Button

5. Panel Loading and Unloading

6. MFU

7. Tape Cutter

1.1 The Proper Data Editor appears when starting the machine.

2.1 Display of the [Production Data] list is unusually slow.

2.2 Display of production program screens is unusually slow.

3.1 After pushing READY ON, the machine moves even though START has

not been pushed.

3.5 The READY ON button lights up but the START button does not flash.

4.1 During production, the machine does not stop when CYCLE STOP is pushed.

6.1 The machine cannot clamp or unclamp the MFU.

7.1 The tape cutter will not move.

3.2 The START button does not respond even though "Push the START switch"

appears on screen.

3.3 The servo power turns on when the machine is ready, even though the

READY ON button has not been pushed.

3.4 The servo power does not turn on when the machine is ready and READY

ON is pushed.

5.1 Production starts when before a panel arrives at the main station.

5.2 When loading a panel, the panel stops before arrival at the main station.

5.4 Error code 1503100E (Failed to convey panel) is displayed during panel

5.5 Error code 15032011 (Failed to convey panel) is displayed during panel

5.6 When finished producing a panel, the machine unloads the panel prematurely,

before the next machine issues a panel request signal.

5.7 When finished with production, the machine does not unload the panel to the

next machine.

5.8 Error code 15031010 (Failed to convey panel) is displayed during panel

unloading.

5.3 When loading a panel, the panel does not decelerate before arrival at the

main station.

8-3-2

8-3-3

8-3-4

8-3-5

8-3-6

Page

XP1S8001E

Part 8 Chapter 3 Corrective Measures for Problems at the Machine

Edition 2.0 8-3-1 XP-142E System Reference

1. Starting the Machine

1.1 The Proper Data Editor appears when starting the machine

Symptoms: The Proper Data Editor is displayed automatically and no other messages

appear.

Note: The Proper Data Editor can be opened by starting the machine with the

CYCLE STOP button pushed in.

Remedy: If a message appears before the Proper Data Editor opens, then follow the

instructions in the message. The CYCLE STOP button may be

malfunctioning. Contact a Fuji Machine dealer for assistance.

X007: CycleStopBtn: Cycle stop PB

2. Screen Displays

2.1 Display of the [Production Data] list is unusually slow.

Symptoms: Display of the [Production] - [Production Data] list is unusually slow, taking

up to several minutes to complete.

Note: As the size of the production data log file increases, the machine requires

increasingly more time to display the production data screen.

Remedy: Using the commands [Production] - [Production Data] - [Deletion Settings],

reduce the values of the [Days] or [Size] limitations.

Delete unnecessary files using the commands in [Production] - [Production

Data] - [Log File].

2.2 Display of production program screens is unusually slow.

Symptoms: Display of the production program screens that appear upon completion of

any of the following sequences is unusually slow, taking up to several

minutes to complete.

Note: As the number of command data files increases, the machine requires

increasingly more time to display production program screens.

[Production] - [Select Program]

[Program] - [Select Program]

[Program] - [Editor] - [Save] - [Browse]

[Program] - [Editor] - [Close] - [Browse] (Only after editing a program)

[Program] - [Editor] - [Mark] - [Mark File Load]

[Program] - [Editor] - [Part] - [Load Library]

[Program] - [Editor] - [Part] - [Part Type Edit] - [Load Library]

[Program] - [Editor] - [Part] - [Packaging Edit] - [Load Library]

[Program] - [File Manager]

Remedy: Delete unnecessary files at [Program] - [File Manager].

If files exist that are seldom used but still necessary, save them to a remote

location such as a floppy disk, then delete them from the machine.

Part 8 Chapter 3 Corrective Measures for Problems at the Machine

Edition 2.0 8-3-2 XP-142E System Reference
