1. System Input Signals

(ESR0501h)

Address Display Description Option Logic

X000 StartButton Start PB NO

X001 ReadyOnButton READY ON PB NO

X002 Side1Enable Side 1 operation enabled NO

X003 Side1Lock Side 1 operation lock NO

X004 Side2Enable Side 2 operation enabled NO

X005 Side2Lock Side 2 operation lock NO

X006 EmergencyBtn Emergency stop PB NC

X007 CycleStopBtn Cycle stop PB NC

X008 Maint.ModeOn Maintenance mode on NC

X009 Side1SftyCovChk Safety cover check (Side 1) NC

X00A Side2SftyCovChk Safety cover check (Side 2) NC

X00B

X00C SafetyRelayLock Safety relay OK NC

X00D ThermalOk Thermal relay OK NC

X00E

X00F PressureSwOk Air pressure OK NC

X010 TimePassed2000h 2000h elapsed NO

X011 TimePassed6000h 6000h elapsed NO

X012 ResetCylUpChk Reset cylinder upper limit check NO

X013 ZAxisMtrFanChk Z-axis motor fan check NC

X014

X015

X016

X017 Side1XYAxisInter XY-Axis Interlock (Side 1) NC

X018 PcbAvailable Panel unloading enabled” signal from previous machine NO

X019 PcbRequest Panel request” signal from next machine NO

X01A Side2XYAxisInter XY-Axis Interlock (Side 2) NC

X01B InStArriveChk IN station panel arrival check NO

X01C MainStDecelPnt MAIN station panel deceleration start point NO

X01D MainStArriveChk MAIN station panel arrival check NO

X01E MainStStpOnChk MAIN station stopper on check NO

X01F MainStStpOffChk MAIN station stopper off check NO

Part 7 Chapter 1 System Input Signals

Edition 2.0 7-1-1 XP-142E System Reference

Address Display Description Option Logic

X020 OutStPassChk OUT station panel pass check NO

X021 PcbVacuumChk Panel pick-up vacuum check NO

X022 MainStPassChk MAIN station panel pass check NO

X023 Side1MfuCovChk MFU cover check (Side 1) Option NC

X024 MainStLftUpChk MAIN station lifter UP limit check NO

X025 MainStLftDwnChk MAIN station lifter DOWN limit check NO

X026

X027 BackUpPinChk Back Up Pin interreference check Option NC

X028 InStLftUpChk IN station lifter UP limit check NO

X029 Side1TpSetDetect2 Raised tape leaf detection 2 (Side 1) NC

X02A Side2MfuCovChk MFU cover check (Side 2) Option NC

X02B Side2TpSetDetect2 Raised tape leaf detection 2 (Side 2) NC

X02C Side1TpSetDetect1 Raised tape leaf detection 1 (Side 1) NC

X02D

X02E Side1MfuUpChk MFU UP limit check (Side 1) NO

X02F Side1MfuDwnChk MFU DOWN limit check (Side 1) NO

X030 Side1TpCutFwdEnd Tape cutter forward end check (Side 1) NO

X031 Side1TpCutBwdEnd Tape cutter backward end check (Side 1) NO

X032 Side2TpCutFwdEnd Tape cutter forward end check (Side 2) NO

X033 Side2TpCutBwdEnd Tape cutter backward end check (Side 2) NO

X034

X035

X036

X037

X038 Side1DustBoxChk Dust box check (Side 1) NO

X039 Side2DustBoxChk Dust box check (Side 2) NO

X03A Side1MfuChk MFU existance check (Side 1) NO

X03B Side2MfuChk MFU existance check (Side 2) NO

X03C Side2TpSetDetect1 Raised tape leaf detection 1 (Side 2) NC

X03D

X03E Side2MfuUpChk MFU UP limit check (Side 2) NO

X03F Side2MfuDwnChk MFU DOWN limit check (Side 2) NO

Part 7 Chapter 1 System Input Signals

Edition 2.0 7-1-2 XP-142E System Reference

2. System Output Signals

(ESR0502f)

Address Display Description

Y000 StartLamp START PB lamp

Y001 ReadyOnLamp READY ON lamp

Y002 Buzzer Buzzer

Y003 TimeCounter Time counter

Y004 Side1YellowLight Signal tower (Side 1 yellow)

Y005 Side1WhiteLight Signal tower (Side 1 white)

Y006 Side2YellowLight Signal tower (Side 1 yellow)

Y007 Side2WhiteLight Signal tower (Side 2 white)

Y008 RedLight Signal tower (red)

Y009 YellowLight Signal tower (yellow)

Y00A Green/BlueLight Signal tower (green/blue)

Y00B

Y00C WatchDogTmrClr Watchdog timer clear

Y00D StrobeLampA Strobe selection A

Y00E StrobeLampB Strobe selection B

Y00F StrobeCharge Strobe charge

Y010 FiducialLamp Fiducial lamp

Y011 MasterRelay Master relay

Y012 PowerOff Power off

Y013 Side2Enable Side 2 operation enabled

Y014 Side1Enable Side 1 operation enabled

Y015

Y016 VacuumPump Vacuum pump

Y017

Y018

Y019

Y01A

Y01B

Y01C PartsLamp Parts lamp

Y01D PartsPickUpDes Parts pick-up vacuum break

Y01E AirBlow Air blow

Y01F ResetCylinder Reset cylinder UP

Part 7 Chapter 2 System Output Signals
