Code: 12300306 Display: Socket transmission error Cause: Socket transmission error Remedy: Internal error. This error should not occur under normal circumstances. Take a machine trace and send it to your Fuji representat…
Code: 12100084
Display: Element leads are more than the specified value
Cause: Element leads are more than the specified value
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
Code: 12100085
Display: Element leads are less than the specified value
Cause: Element leads are less than the specified value.
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
Code: 12100088
Display: Coplanarity tolerence error
Cause: The coplanarity check result shows the lead bent over the specified limit.
Remedy: Check the part lead is not bent or check the Coplanarity Tolerance specified in part
data is not too small.
Code: 12300301
Display: Socket transmission error
Cause: Unable to obtain a data communication port number at the IJ process or sub-
machine.
Remedy: Check the data communication port numbers for the IJ process and sub-machine
match.
Code: 12300302
Display: Socket transmission error
Cause: Unable to open the port because the designated port is not usable/in use.
Remedy: Check the communication port numbers for the IJ process and intermediate
machines match.
Code: 12300303
Display: Socket transmission error
Cause: The communication port number is invalid.
Remedy: Check that the communication port numbers for the IJ process and intermediate
machines match.
Code: 12300304
Display: Socket transmission error
Cause: Unable to obtain memory for socket communication.
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12300305
Display: Socket transmission error
Cause: The IP address is invalid.
Remedy: Check connecting terminal IP address of (IJ process or machine in the group).
Part 8 Chapter 1 Error Code Messages and Corrective Measures
Edition 2.0 8-1-34 XP-142E System Reference
Code: 12300306
Display: Socket transmission error
Cause: Socket transmission error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12300307
Display: Socket transmission error
Cause: Socket is invalid, or unable to connect or call machine.
Remedy: Check connecting terminal and status of machine.
Check main machine and connecting terminal network cables connections.
Code: 12300308
Display: Socket transmission error
Cause: The machine configurations are different on the IJ process side and machine side.
Remedy: Confirm machine configuration.
Code: 12300309
Display: Socket transmission error
Cause: The communication socket is invalid.
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1230030A
Display: Socket transmission error
Cause: Unable to receive message
Remedy: Check status of connecting terminal and machine.
Check the machine and connecting terminal network cables connections.
Code: 1230030B
Display: Socket transmission error
Cause: Unable to receive message
Remedy: Check status of connecting terminal and machine.
Check the machine and connecting terminal network cables connections.
Code: 1230030C
Display: Socket transmission error
Cause: During automatic changeover, the user name for the FTP server that outputs the
production program is not valid.
Remedy: Check the FTP server user name.
Code: 1230030D
Display: Socket transmission error
Cause: During automatic changeover, the password for the FTP server that outputs the
production program is not valid.
Remedy: Check the FTP server password.
Code: 1230030E
Display: Socket transmission error
Cause: An invalid message was received.
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-35 XP-142E System Reference
Code: 1230030F
Display: Socket transmission error
Cause: A port that is already connected is selected as the communication port.
Remedy: Check the communication port numbers of the IJ process and intermediate
machines.
Code: 12300310
Display: Socket transmission error
Cause: Received an invalid command.
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12300311
Display: Socket transmission error
Cause: Received an invalid command.
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12300312
Display: Socket transmission error
Cause: Job data not specified.
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12300313
Display: Socket transmission error
Cause: Cannot locate connection socket.
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12300314
Display: Socket transmission error
Cause: Panel ID not specified.
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 12300315
Display: Socket transmission error
Cause: The machine number of the sub-machine used for automatic changeover is out of
range.
Remedy: Check the number of automatic changeover machines in the automatic changeover
settings.
Code: 12300316
Display: Socket transmission error
Cause: Unable to secure socket transmission memory.
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Part 8 Chapter 1 Error Code Messages and Corrective Measures
Edition 2.0 8-1-36 XP-142E System Reference
