Code: 12056033 Display: The remover is interfering with the tray positioning plate when ejecting the tray. Change the [Tray Dump Pick Position X] setting in part data so that the remover does not extend beyond the tray. …

Code: 1205501B

Display: A cycle steal compatible nozzle is not present.

Cause: A cycle steal compatible nozzle is not present.

Remedy: Set a cycle steal compatible nozzle.

Code: 12055026

Display: The cycle steal offset tolerance has been exceeded.

Cause: The cycle steal offset tolerance has been exceeded.

Remedy: Execute the Rotate Center command.

Code: 1205602A

Display: Operating System Error

Cause: Operating System Error

Remedy: Internal error. This error should not occur under normal circumstances. Take a

machine trace and send it to your Fuji representative.

Code: 1205602B

Display: Raised nozzle detected. Check nozzle station.

Cause: The raised nozzle detection sensor was interrupted.

Remedy: If this error occurred incorrectly, confirm the sensor’s ON/OFF operation, and

adjustment position are correct.

Code: 1205602C

Display: The remover is not set correctly. Check the remover station.

Cause: The remover station sensor was interrupted.

Remedy: If this error occurred incorrectly, confirm the sensor’s ON/OFF operation, and

adjustment position are correct.

Code: 12056030

Display: The slot number for the tray on the shuttle is unknown.

Unable to retract the tray.

Close this error message and select the current tray slot number in the displayed

dialog.

Cause: The slot number for the tray on the shuttle is unknown.

Remedy: Close this error message and input the current tray slot number in the displayed

dialog.

Code: 12056031

Display: The remover is interfering with the tray positioning plate when ejecting the tray.

Cause: The remover is interfering with the tray positioning plate. Trays whose Tray

Length (X-direction) is shorter than the remover cannot be ejected using the

standard XP tray holder.

Remedy: Either change the [Tray Type] setting in part data to a type that does not

automatically eject trays (4), or use a precise tray.

Code: 12056032

Display: The remover is interfering with the tray positioning plate when ejecting the tray.

Cause: The remover is interfering with the tray positioning plate.

Trays whose Tray Width (Y-direction) is shorter than the remover cannot be

ejected using the standard XP tray holder.

Remedy: Either change the [Tray Type] in part data to a type that does not automatically

eject trays (4), or use a precise tray.

Part 8 Chapter 1 Error Codes and Corrective Measures

Edition 2.0 8-1-31 XP-142E System Reference

Code: 12056033

Display: The remover is interfering with the tray positioning plate when ejecting the tray.

Change the [Tray Dump Pick Position X] setting in part data so that the remover

does not extend beyond the tray.

Cause: The remover interferes with the tray positioning plate when picking up the empty

tray.

Remedy: Change the [Tray Dump Pick Position X] setting in part data so that the remover

does not extend beyond the tray.

Code: 12056034

Display: The remover is interfering with the tray positioning plate when ejecting the tray.

Change the [Tray Dump Pick Position Y] setting in part data so that the remover

does not extend beyond the tray.

Cause: The remover interferes with the tray positioning plate when picking up the empty

tray.

Remedy: Change the [Tray Dump Pick Position Y] setting in part data so that the remover

does not extend beyond the tray.

Code: 12056035

Display: The nozzle interferes with the tray positioning plate when picking up parts.

(At the front side of the tray as seen from the front of the machine.)

Cause: The nozzle interferes with the tray positioning plate when picking up parts.

(At the front side of the tray as seen from the front of the machine.)

Remedy: Change the [Tray First Pickup Position Y] setting in the part data, or change one of

the following settings (as applicable) so that nozzles do not interfere with the tray

positioning plate.

*If [Direction] is set to 1 or 3, change the [Pick-up Point Offset X] setting.

*If [Direction] is set to 0 or 2, change the [Pick-up Point Offset Y] setting.

Code: 12056036

Display: The nozzle interferes with the tray positioning plate when picking up parts.

(The right side of the tray as seen from the front of the machine.)

Cause: The nozzle interferes with the tray positioning plate when picking up parts.

(The right side of the tray as seen from the front of the machine.)

Remedy: Change the [Tray First Pickup Position X] setting in the part data, or change one of

the following settings (as applicable) so that nozzles do not interfere with the tray

positioning plate.

*If [Direction] is set to 1 or 3, change the [Pick-up Point Offset Y] setting.

Code: 12056037

Display: The nozzle interferes with the tray positioning plate when picking up parts.

(The left side of the tray as seen from the front of the machine.)

Cause: The nozzle interferes with the tray positioning plate when picking up parts.

(The left side of the tray as seen from the front of the machine.)

Remedy: Change the [Tray First Pickup Position X] setting in the part data, or change one of

the following settings (as applicable) so that nozzles do not interfere with the tray

positioning plate.

*If [Direction] is set to 0 or 2, change the [Pick-up Point Offset X] setting.

*If [Direction] is set to 1 or 4, change the [Pick-up Point Offset Y] setting.

Part 8 Chapter 1 Error Code Messages and Corrective Measures

Edition 2.0 8-1-32 XP-142E System Reference

Code: 12056038

Display: Nozzle size check error

An error occurred when performing nozzle size check by sensor.

Check that the machine nozzles match the nozzle settings in the data editor.

Check the operation of the nozzle size check sensor.

Cause: An error occurred when performing nozzle size check by sensor.

Remedy: Check that the machine nozzles match the nozzle settings in the data editor.

Check the operation of the nozzle size check sensor.

Code: 12056150

Display: Tray pallet is not retracted.

The elevator cannot be moved.

Confirm the tray pallet position.

Cause: The tray cannot be moved on the elevator because the tray retract confirmation

sensor is OFF.

Remedy: Correct the tray shuttle and tray pallet positions.

Check that the tray retract confirmation sensor is functioning correctly.

Code: 12056151

Display: The magazine tray check sensor turned off while the elevator was moving.

The elevator cannot be moved.

Confirm the tray pallet position.

Cause: The magazine tray check sensor turned off while the elevator was moving.

Remedy: Correct tray shuttle and tray pallet positions.

Check that the magazine tray check sensor is functioning correctly.

Code: 12100081

Display: Vision processing System Error

Cause: Vision processing System Error

Remedy: Internal error. This error should not occur under normal circumstances. Take a

machine trace and send it to your Fuji representative.

Code: 12100082

Display: Vision processing System Error

Cause: Vision processing System Error

Remedy: Internal error. This error should not occur under normal circumstances. Take a

machine trace and send it to your Fuji representative.

Code: 12100083

Display: Unable to detect leads.

Cause: Standard template error

Remedy: Check that the part data is correct; in particular, check the element data and the

“Stand Off” setting.

If the part data is correct, check the following possible causes:

*Poor pick-up performance

*Image brightness deterioration

*Poor camera focus

*Presence of dirt or other foreign object
