Code: 1404D008

Display: A foreign substance has been detected on the nozzle. Vision processing may not

perform correctly.

Cause: A foreign substance has been detected on the nozzle. Vision processing may not

perform correctly.

Remedy: Check and correct the following conditions.

• Check the nozzle where the error is occurring for foreign substances, blemishes,

or scratches. Clean or replace the nozzle as necessary.

• Check the prism on the side where the error is occurring, and clean as

necessary.

• Check that a nozzle is mounted within the vision processing range. Install a

nozzle if one is not within the correct range. (XP142)

• If the camera image is too dark or light, the brightness setting is not correct.

Adjust brightness as specified in the manual.

• Check the vision processing position. If not correct adjust as specified in the

manual.

• If the strobe light is not working properly there may be a problem with the light

source. Check the wiring and replace the xenon bulb or servo PCB as necessary.

• If the camera image is not reading properly, there may be a problem with the

camera. Check the wiring and replace the camera or vision PCB as necessary.

Code: 14050000

Display: Corner dog vision error

Cause: Corner dog vision error

Remedy: Perform vision processing to confirm the corner dog adjustment.

Code: 14050001

Display: Corner dog limit error

Cause: Corner dog limit error

Remedy: Check a part was not mistakenly read during corner dog processing. Check the

corner dog has not come loose.

Code: 14050002

Display: Corner dog vision processing failed during cycle steal

Cause: Corner dog vision processing failed during cycle steal.

Remedy: Check vision processing at [Maintenance A] - [Corner Dog Adjustment].

If an error occurs, check the corner dog for scratches or foreign matter.

Code: 14050003

Display: Pick-up position measurement failed.

Cause: Failed to acquire an image of the feeder pick-up point when performing pick-up

position measurement.

Remedy: Check that the feeder is set correctly.

Check that the tape leaf position is correct.

Check that the parts tape is set correctly on the feeder.

Code: 14050004

Display: Failed to the read gauge chip during cycle steal.

Cause: Failed to the read gauge chip during cycle steal.

Remedy: Check gauge chip cleanliness and size.

Part 8 Chapter 1 Error Codes and Corrective Measures

Edition 2.0 8-1-39 XP-142E System Reference

Code: 14050005

Display: Failed to the read glass parts during cycle steal.

Cause: Failed to the read glass parts during cycle steal.

Remedy: Check glass parts cleanliness and size.

Code: 15031008

Display: Failed to lift off the in station lifter

Cause: Unable to lift off this in station lifter.

Remedy: If the IN station lifter is down, check the hoses to the lifter are not loose.

If the IN station lifter is up, check the function of the IN lifter sensor.

Code: 15031009

Display: Failed to lift down the in station lifter

Cause: Unable to lower the IN station lifter.

Remedy: Check that the IN lifter sensor is functioning correctly. Check the hoses to the

lifter are not loose.

Code: 1503100A

Display: Failed to lift off the main station lifter

Cause: Unable to raise the main station lifter.

Remedy: If the main station lifter is not raised, check the hoses to the lifter have not come

loose.

If the main station lifter is raised check the sensor is functioning correctly.

Code: 1503100B

Display: Failed to lift down the main station lifter

Cause: Unable to lower the main station lifter.

Remedy: If the main station lifter is not lowered, check the hoses to the lifter have not come

loose.

If the main station lifter is lowered check the sensor is functioning correctly.

Code: 1503100C

Display: Failed to lift off the main station stopper

Cause: Unable to raise the main station stopper.

Remedy: If the main station stopper is not raised, check the hoses to the lifter have not come

loose.

If the main station stopper is raised check the sensor is functioning correctly.

Check the hoses to the lifter have not come loose.

Code: 1503100D

Display: Failed to lower the main station stopper

Cause: Unable to lower the main station stopper.

Remedy: If the main station stopper is not lowered, check the hoses to the lifter have not

come loose.

If the main station stopper is lowered check the sensor is functioning correctly.

Code: 1503100E

Display: Failed to convey a panel to at the main station arrival sensor

Cause: Unable to convey a panel to the main station arrival sensor.

Remedy: Check the panel is not stuck on the conveyor, and the main station arrival sensor is

functioning correctly.

Part 8 Chapter 1 Error Code Messages and Corrective Measures

Edition 2.0 8-1-40 XP-142E System Reference

Code: 1503100F

Display: Failed to check out a panel at the main pass sensor

Cause: Unable to confirm the panel position.

Remedy: Check the panel is not stuck on the conveyor, and check the main pass sensor is

operating correctly.

Code: 15031010

Display: Failed to convey a panel to next machine.

Cause: Unable to convey the panel to the next machine.

Remedy: Check the panel is not stuck inside the machine, and check the signal from the next

machine.

Code: 15031011

Display: Failed to convey a panel to the main station deceleration sensor

Cause: Unable to convey a panel to the main station deceleration sensor.

Remedy: Check the panel is not stuck on the conveyor, and the main station deceleration

sensor is functioning correctly.

Code: 15031012

Display: Failed to convey a panel in the in station interval.

Cause: Failed to convey a panel in the in station interval.

Remedy: Check that the panel available signal from the previous machine

(X018:PcbAvailable) is operating correctly.

Code: 15032010

Display: Production cannot be started. A panel is detected by the Main Station speed

reduction/arrival/pass sensor, but stopper is not up.

Cause: Production cannot be started. A panel is detected by the Main Station speed

reduction/arrival/pass sensor, but stopper is not up.

Remedy: Raise the stopper using the commands at the Conveyor Operation screen, then

start the machine.

If there is no panel and this error still displays, check the Main Station speed

reduction/arrival/pass sensor.

Code: 15032011

Display: Unable to determine the status of the panel at the Out pass sensor.

Cause: The panel has not been detected by the panel pass confirmation sensor.

Remedy: Check the panel is not stuck on the conveyor.

If the panel is not on the conveyor check that the panel pass confirmation sensor is

functioning correctly.

Code: 15032012

Display: Out station panel cannot be ejected because there is no panel request signal.

Cause: Out station panel cannot be ejected because there is no panel request signal.

Remedy: Start the machine while the next machine panel request signal is ON.

Remove the panel from the OUT station, then start the machine.

If there is no panel and this error still displays, check the Main Station speed

reduction/arrival/pass sensor.
