Code: 1101D319

Display: No matching nozzle.

Cause: The nozzle data contains neither the nozzle specified by the NozzleName item (in

Part Type data), or a nozzle which satisfies the NozzleSizeMin to NozzleSizeMax

range setting.

Remedy: Specify the appropriate nozzle in the nozzle data.

Code: 1101D31A

Display: When using Vision Type 100 or 130, the Lead Quantity must be 5 or greater for the

first element.

Cause: When using Vision Type 100 or 130, the “Element” first line “Lead Quantity” was

less than 5.

Remedy: When using Vision Types 100 and 130, specify the “Element” first line “Lead

Quantity” as 5 or more.

Code: 1101D31B

Display: Tray cannot be removed. Input the tray thickness (4.00 mm - 25.40 mm).

Cause: The tray dimensions are outside the permissible XP tray specifications

(4.00 mm - 25.40 mm).

Remedy: Input a permissible tray thickness (4.00 mm - 25.40 mm).

Code: 1101D31C

Display: The nozzle interferes with the tray positioning plate when picking up parts.

(At the front side of the tray as seen from the front of the machine.)

Cause: The nozzle interferes with the tray positioning plate when picking up parts.

(At the front side of the tray as seen from the front of the machine.)

Remedy: Change the [Tray First Pickup Position Y] setting in the part data, or change one of

the following settings (as applicable) so that nozzles do not interfere with the tray

positioning plate.

*If [Direction] is set to 1 or 3, change the [Pick-up Point Offset X] setting.

*If [Direction] is set to 0 or 2, change the [Pick-up Point Offset Y] setting.

Code: 1101D31D

Display: The nozzle interferes with the tray positioning plate when picking up parts.

(The right side of the tray as seen from the front of the machine.)

Cause: The nozzle interferes with the tray positioning plate when picking up parts.

(The right side of the tray as seen from the front of the machine.)

Remedy: Change the [Tray First Pickup Position X] setting in the part data, or change one of

the following settings (as applicable) so that nozzles do not interfere with the tray

positioning plate.

*If [Direction] is set to 0 or 2, change the [Pick-up Point Offset X] setting.

*If [Direction] is set to 1 or 3, change the [Pick-up Point Offset Y] setting.

Code: 1101D31E

Display: The nozzle interferes with the tray positioning plate when picking up parts.

(The left side of the tray as seen from the front of the machine.)

Cause: The nozzle interferes with the tray positioning plate when picking up parts.

(The left side of the tray as seen from the front of the machine.)

Remedy: Change the [Tray First Pickup Position X] setting in the part data, or change one of

the following settings (as applicable) so that nozzles do not interfere with the tray

positioning plate.

*If [Direction] is set to 0 or 2, change the [Pick-up Point Offset X] setting.

*If [Direction] is set to 1 or 3, change the [Pick-up Point Offset Y] setting.

Part 8 Chapter 1 Error Codes and Corrective Measures

Edition 2.0 8-1-7 XP-142E System Reference

Code: 1101D31F

Display: The value set for Stand Off height is higher than or equal to the Part Height.

Cause: The value set for Stand Off height is higher than or equal to the Part Height.

Remedy: Enter a value lower than the Part Height.

Code: 1101D320

Display: The Z-axis target value exceeds the servo limit.

Placing Offset Z = *** (Min.: ***)

Cause: Operation with this part data causes the Z-axis to pass the minus limit.

Remedy: In Part Type Data, revise the Placing Offset Z value.

If there is no problem with the Placing Offset Z value, confirm the Part Height

value.

Code: 1101D321

Display: Parts using vision type 230 or 231 require at least one element with lead quantity

of two or more. (Excluding the second row of data in the matrix display.)

Cause: The element data for parts using vision type 230 or 231 does not have an element

with two or more leads.

Remedy: When using vision type 230 or 231, create at least one element with lead quantity

of two or more.

Code: 1101D322

Display: 2 or more Element lines are required for Vision Type 20.

Cause: For Vision Type 20, vision processing is only possible when the “Element” setting

occupies 2 or more lines.

Remedy: Specify 2 or more lines for the “Element” setting.

Code: 1101D323

Display: For Vision Type 124, the [Element] setting must occupy either 2 or 4 lines.

Cause: For Vision Type 124, vision processing is only possible when the “Element” setting

occupies either 2 or 4 lines.

Remedy: Specify either 2 or 4 lines for the “Element” setting.

Code: 1101D324

Display: For Vision Type 180, the total number of leads in [Lead Quantity] for the entire

element must be 2, 3, or 4.

Cause: For Vision Type 180, the total number of leads in “Lead Quantity” for the entire

element must be 2, 3, or 4.

Remedy: When using Vision Type 180, set the values for “Lead Quantity” so that the sum of

all leads for the element equals 2, 3, or 4.

Code: 1101D329

Display: The specified part size exceeds the scanning range (body length (X): 5 mm or less,

body width (Y): 4 mm or less) that can be handled by the camera for vision type

10.

Cause: The maximum part dimensions that may be specified when using vision type 10

are 5 mm for the body length (X) and 4 mm for the body width (Y). If the specified

part size exceeds these dimensions, the part may not be found or accuracy may be

negatively affected.

Remedy: When using vision type 10, only use parts with maximum dimensions of 5 mm for

the body length (X), and 4 mm for the body width (Y). For larger parts, create the

part data using vision type 18.

Part 8 Chapter 1 Error Code Messages and Corrective Measures

Edition 2.0 8-1-8 XP-142E System Reference

Code: 1101D32A

Display: The part size or Scan Area X, Scan Area Y setting exceeds the scanning range that

can be handled by the camera.

Cause: The part size or Scan Area X, Scan Area Y setting exceeds the scanning range that

can be handled by the camera.

Remedy: Specify a part size or Scan Area X, Scan Area Y setting value that is within the

scanning range that can be handled by the camera.

With the Pick-up Point Offset X and Pick-up Point Offset Y settings taken into

account, the maximum part size that may be specified is 20 mm x 20 mm, and the

maximum scan area is 25 mm x 24 mm,

Code: 1101D32B

Display: A nozzle that matches nozzle no. ** cannot be found.

Cause: A nozzle that matches nozzle no. ** cannot be found.

Remedy: Specify a matching nozzle in the nozzle data.

Code: 1101D32C

Display: The part cannot be picked up because it interferes with an adjacent nozzle.

Cause: The part cannot be picked up because it interferes with an adjacent nozzle.

Remedy: Change the nozzle configuration.

Code: 1101D32D

Display: The part will not be picked up at its center so as to prevent part interference (Y-

offset amount: *.* mm).

Cause: The part will not be picked up at its center, as the offset function is in use for

automatic interference prevention.

Remedy: To specify pick-up at the part center, set Pick-up Point Offset Y to 0.1, or set Scan

Area Y to 23 or less.

Code: 1101D32E

Display: There is a possibility of interference with nozzle no. **.

Cause: A corner of the part may interfere with nozzle no. **.

Remedy: Check the part shape, and if there is a possibility of interference, change either the

nozzle size or nozzle position.

Code: 1101D32F

Display: 5 or more leads do not exist, or the part exceeds the scan range that can be handled

by the camera.

Cause: 5 or more leads are required. Where 5 or more leads exist, and the part is picked

up at the revolver center, the part exceeds the scan range that can be handled by

the camera.

Remedy: Create the part data using vision type 18 or 20.

Code: 1101D330

Display: No template data exists.

Cause: Template data is required for Vision Type 18 in part data.

Remedy: If the error occurred even though template file reading using

_CCIMFTemplateMode in Proper data is specified, then create template data.

When using an existing template file, specify that the template file is read.

Part 8 Chapter 1 Error Codes and Corrective Measures

Edition 2.0 8-1-9 XP-142E System Reference
