Code: 1D005013 Display: Element lead center error Cause: Element lead center error Remedy: Replace the parts for which the error occurred or check the part data is correct. If the part data is correct, check the part pic…
Code: 1D00500F
Display: Element lead pitch error
Cause: Element lead pitch error
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Code: 1D005010
Display: Bump size error
Cause: Bump size error
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check the
vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Code: 1D005011
Display: Element lead length error
Cause: Element lead length error
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Code: 1D005012
Display: Element lead width error
Cause: Element lead width error
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Part 8 Chapter 1 Error Codes and Corrective Measures
Edition 2.0 8-1-45 XP-142E System Reference
Code: 1D005013
Display: Element lead center error
Cause: Element lead center error
Remedy: Replace the parts for which the error occurred or check the part data is correct. If
the part data is correct, check the part pick-up condition is not incorrect. Check
the vision processing light brightness is functioning correctly, the focus is adjusted
correctly and the image is not dirty.
When using multi-window processing check the image comparison. If the images
are different check the actual part height matches that in part data and the nozzle
holder is calibrated correctly.
Code: 1D005014
Display: No parts
Cause: A “No part” error was detected for vision types 10, 20.
Remedy: Re-supply parts.
If parts are still being picked up, check the following possible causes:
• Poor pick-up performance
• Image brightness deterioration
• Poor camera focus
• Presence of dirt or other foreign object
Code: 1D005015
Display: Vision processing System Error
Cause: Vision processing System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Code: 1D005016
Display: Vision processing System Error
Cause: Vision processing System Error
Remedy: Internal error. This error should not occur under normal circumstances. Take a
machine trace and send it to your Fuji representative.
Part 8 Chapter 1 Error Code Messages and Corrective Measures
Edition 2.0 8-1-46 XP-142E System Reference
2. Corrective Measures for Error Messages that
Appear without an Error Code
In some cases, an error message will appear without a code (number). These error messages
are listed in alphabetical order of the first letter in the message.
“A value exists that could not be read correctly. Please set the proper data.”
Conditions: During the start up process, the machine may lock up with this message on the
touch panel. The touch panel will not respond, but clicking the OK button with
the mouse will open the Proper Data Editor.
Cause: Certain Proper data values could not be read properly.
Remedy: Follow the procedure for loading a backup file as explained in the remedy to the
error message, “Proper data doesn’t exist. Please set the Proper data”, or directly
enter the Proper data values using the Proper Data Editor.
“An unsupported machine type is set in the Proper data. Please set the Proper data”
Conditions: During the start up process, the machine may lock up with this message on the
touch panel. The touch panel will not respond, but clicking the OK button with
the mouse will open the Proper Data Editor.
Cause: A machine type that is not supported is specified in the Proper data.
Remedy: Follow the procedure for loading a backup file as explained in the remedy to the
error message, “Proper data doesn’t exist. Please set the Proper data”.
“Could not found language file.”
Conditions: During the start up process, the machine may lock up with this message on the
touch panel. The touch panel will not respond.
Cause: The multiple language message data could not be read, or some of the multiple
language message data has been deleted for an unknown reason.
Remedy: Use the recovery disks to restore the system.
“Illegal Proper data format. Please set the Proper data while referring to the upgrade manual.”
Conditions: During the start up process, the machine may lock up with this message on the
touch panel. The touch panel will not respond, but clicking the OK button with
the mouse will open the Proper Data Editor.
Cause: The Proper data could not be read because it is in the wrong format.
Remedy: Follow the procedure for loading a backup file as explained in the remedy to the
error message, “Proper data doesn’t exist. Please set the Proper data”.
“Illegal Proper data format. The Proper may be unreadable. Please set the Proper data.”
Conditions: During the start up process, the machine may lock up with this message on the
touch panel. The touch panel will not respond, but clicking the OK button with
the mouse will open the Proper Data Editor.
Cause: The machine may not be able to read the Proper data, because certain values are in
the wrong format.
Remedy: Follow the procedure for loading a backup file as explained in the remedy to the
error message, “Proper data doesn’t exist. Please set the Proper data”, or directly
enter the Proper data values using the Proper Data Editor.
Part 8 Chapter 2 Corrective Measures for Error Messages
that Appear without an Error Code
Edition 2.0 8-2-1 XP-142E System Reference
