Code: 1503100F Display: Failed to check out a panel at the main pass sensor Cause: Unable to confirm the panel position. Remedy: Check the panel is not stuck on the conveyor, and check the main pass sensor is operating c…

Code: 14050005

Display: Failed to the read glass parts during cycle steal.

Cause: Failed to the read glass parts during cycle steal.

Remedy: Check glass parts cleanliness and size.

Code: 15031008

Display: Failed to lift off the in station lifter

Cause: Unable to lift off this in station lifter.

Remedy: If the IN station lifter is down, check the hoses to the lifter are not loose.

If the IN station lifter is up, check the function of the IN lifter sensor.

Code: 15031009

Display: Failed to lift down the in station lifter

Cause: Unable to lower the IN station lifter.

Remedy: Check that the IN lifter sensor is functioning correctly. Check the hoses to the

lifter are not loose.

Code: 1503100A

Display: Failed to lift off the main station lifter

Cause: Unable to raise the main station lifter.

Remedy: If the main station lifter is not raised, check the hoses to the lifter have not come

loose.

If the main station lifter is raised check the sensor is functioning correctly.

Code: 1503100B

Display: Failed to lift down the main station lifter

Cause: Unable to lower the main station lifter.

Remedy: If the main station lifter is not lowered, check the hoses to the lifter have not come

loose.

If the main station lifter is lowered check the sensor is functioning correctly.

Code: 1503100C

Display: Failed to lift off the main station stopper

Cause: Unable to raise the main station stopper.

Remedy: If the main station stopper is not raised, check the hoses to the lifter have not come

loose.

If the main station stopper is raised check the sensor is functioning correctly.

Check the hoses to the lifter have not come loose.

Code: 1503100D

Display: Failed to lower the main station stopper

Cause: Unable to lower the main station stopper.

Remedy: If the main station stopper is not lowered, check the hoses to the lifter have not

come loose.

If the main station stopper is lowered check the sensor is functioning correctly.

Code: 1503100E

Display: Failed to convey a panel to at the main station arrival sensor

Cause: Unable to convey a panel to the main station arrival sensor.

Remedy: Check the panel is not stuck on the conveyor, and the main station arrival sensor is

functioning correctly.

Part 8 Chapter 1 Error Code Messages and Corrective Measures

Edition 2.0 8-1-40 XP-142E System Reference

Code: 1503100F

Display: Failed to check out a panel at the main pass sensor

Cause: Unable to confirm the panel position.

Remedy: Check the panel is not stuck on the conveyor, and check the main pass sensor is

operating correctly.

Code: 15031010

Display: Failed to convey a panel to next machine.

Cause: Unable to convey the panel to the next machine.

Remedy: Check the panel is not stuck inside the machine, and check the signal from the next

machine.

Code: 15031011

Display: Failed to convey a panel to the main station deceleration sensor

Cause: Unable to convey a panel to the main station deceleration sensor.

Remedy: Check the panel is not stuck on the conveyor, and the main station deceleration

sensor is functioning correctly.

Code: 15031012

Display: Failed to convey a panel in the in station interval.

Cause: Failed to convey a panel in the in station interval.

Remedy: Check that the panel available signal from the previous machine

(X018:PcbAvailable) is operating correctly.

Code: 15032010

Display: Production cannot be started. A panel is detected by the Main Station speed

reduction/arrival/pass sensor, but stopper is not up.

Cause: Production cannot be started. A panel is detected by the Main Station speed

reduction/arrival/pass sensor, but stopper is not up.

Remedy: Raise the stopper using the commands at the Conveyor Operation screen, then

start the machine.

If there is no panel and this error still displays, check the Main Station speed

reduction/arrival/pass sensor.

Code: 15032011

Display: Unable to determine the status of the panel at the Out pass sensor.

Cause: The panel has not been detected by the panel pass confirmation sensor.

Remedy: Check the panel is not stuck on the conveyor.

If the panel is not on the conveyor check that the panel pass confirmation sensor is

functioning correctly.

Code: 15032012

Display: Out station panel cannot be ejected because there is no panel request signal.

Cause: Out station panel cannot be ejected because there is no panel request signal.

Remedy: Start the machine while the next machine panel request signal is ON.

Remove the panel from the OUT station, then start the machine.

If there is no panel and this error still displays, check the Main Station speed

reduction/arrival/pass sensor.

Part 8 Chapter 1 Error Codes and Corrective Measures

Edition 2.0 8-1-41 XP-142E System Reference

Code: 1D005001

Display: Vision processing System Error

Cause: Vision processing System Error

Remedy: Internal error. This error should not occur under normal circumstances. Take a

machine trace and send it to your Fuji representative.

Code: 1D005002

Display: Vision processing System Error

Cause: Vision processing System Error

Remedy: Internal error. This error should not occur under normal circumstances. Take a

machine trace and send it to your Fuji representative.

Code: 1D005003

Display: Vision processing System Error

Cause: Vision processing System Error

Remedy: Internal error. This error should not occur under normal circumstances. Take a

machine trace and send it to your Fuji representative.

Code: 1D005004

Display: Pattern matching error

Cause: Unable to perform pattern matching.

Remedy: Replace the parts for which the error occurred or check the part data and the

template are correct.

If the part data and template data is correct, check the part pick-up condition is not

incorrect, the vision processing light brightness is functioning correctly, the focus

is adjusted correctly and the image is not dirty.

When using multi-window processing check the image comparison. If the images

are different check the actual part height matches that in part data and the nozzle

holder is calibrated correctly. (XP241, XP341)

Code: 1D005005

Display: X-direction size error

Cause: Patter matching was successful, however the X-side body size is over the

permissible value (Part data Body Length Tolerance).

Remedy: Confirm the part was picked up correctly, and the Body Length Tolerance value is

not too small. Either exchange the erroneous part or correct the part data. If the

part data is correct, check the pickup position, the vision processing brightness,

the focus and the cleanliness of the lens.

When using multi-window processing check the image comparison. If the images

are different check the actual part height matches that in part data and the nozzle

holder is calibrated correctly. (XP241, XP341)

Part 8 Chapter 1 Error Code Messages and Corrective Measures

Edition 2.0 8-1-42 XP-142E System Reference
