28 E610239 LT4 Driver alarm occurred E610240 RT1 Dr iver alarm occurred E610241 RT2 Dr iver alarm occurred” E610242 RT3 Driver alarm occurred E610243 RT4 Dr iver alarm occurred E610300 An error occurred when ComR es comm…
27
E610048 No head type is defined.
E610049 The laser sensor may be soiled. Clean the sensor.
E610050 An error occurred when the machine detected the posture of the nozzle.
E610051 Since the posture of the nozzle is abnormal, the nozzle cannot be returned.
E610052 ATC X coordinate is abnormal
E610083 Measured width of the nozzle does not coincide with the assigned width. Machine does not
return the nozzle because of possible damage to the nozzle. Check how the nozzle is
attached. Press <No> to allow the machine to return the nozzle.
E610084 Measured width of the nozzle does not coincide with the assigned width. Machine does not
return the nozzle because of possible damage to the nozzle. Remove and return the nozzle
manually.
E610100 The Vacuum calibration has not been installed
E610200 Emergency Stop SW occurred
E610201 Area sensorF ON occurred
E610202 Area sensorR ON occurred
E610203 Cover open sensor ON occurred
E610204 Feeder floatation sensor ON occurred”
E610205 +X limit occurred
E610206 -X limit occurred
E610207 +XR limit occurred
E610208 -XR limit occurred
E610209 +Y limit occurred
E610210 -Y limit occurred
E610211 +YCNV limit occurred
E610212 -YCNV limit occurred
E610213 The error not forecast occurred
E610214 X Driver alarm occurred
E610215 XR Driver alarm occurred
E610216 Y Driver alarm occurred
E610217 YR Driver alarm occurred
E610218 YCNV Driver alarm occurred
E610219 X SLOW occurred
E610220 X STOP occurred
E610221 X Linear scale alarm occurred
E610222 XR Linear scale alarm occurred
E610223 Y Linear scale alarm occurred
E610224 YR Linear scale alarm occurred
E610225 Fan stop error occurred
E610226 The air pressure decrease error occurred
E610227 The error not forecast occurred
E610228 LZ1 Driver alarm occurred
E610229 LZ2 Driver alarm occurred
E610230 LZ3 Driver alarm occurred
E610231 LZ4 Driver alarm occurred
E610232 RZ1 Driver alarm occurred
E610233 RZ2 Driver alarm occurred
E610234 RZ3 Driver alarm occurred
E610235 RZ4 Driver alarm occurred
E610236 LT1 Driver alarm occurred
E610237 LT2 Driver alarm occurred
E610238 LT3 Driver alarm occurred
28
E610239 LT4 Driver alarm occurred
E610240 RT1 Driver alarm occurred
E610241 RT2 Driver alarm occurred”
E610242 RT3 Driver alarm occurred
E610243 RT4 Driver alarm occurred
E610300 An error occurred when ComRes command send
E610301 An error occurred when ComRes response receive
E610400 Vacuum of L1 head has been on
E610401 Vacuum of L2 head has been on
E610402 Vacuum of L3 head has been on
E610403 Vacuum of L4 head has been on
E610404 Vacuum of R1 head has been on
E610405 Vacuum of R2 head has been on
E610406 Vacuum of R3 head has been on
E610407 Vacuum of R4 head has been on
E610408 The specified nozzle has been installed
29
Error Messages on Asynchronous Events
Error code Message
E620009 X axis driver alarm
E620010 Y axis driver alarm
E620011 Yc axis driver alarm
E620014 Z axis driver alarm
E620015 Theta axis driver alarm
E620058 The power failure was detected. Re-starting of a system is required. Please re-switch on a
power supply after a shutdown.
