4 – 146
Check that displays the error message “The light type is different” on the screen
Lead component whose dimension X is
from 1.9 mm to 74 mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Lead component whose dimension X is
from 9.0 mm to 35.0 mm
When the light type is not “Back Light”
Lead component whose dimension Y is
from 1.9 mm to 150.0 mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Lead component whose dimension Y is
from 9.0 mm to 120.0 mm
When the light type is not “Back Lights”
Ball component whose dimension X is
from 0.6 mm to 74 mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Ball components When the light type is “Back Lights”
Ball component whose dimension Y is
from 0.6 mm to 150.0 mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Outline-recognition component whose
dimension X is from 1.7 mm to 74 mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Outline-recognition component whose
dimension X is from 9.0 mm to 35.0 mm
When the light type is not “Back Lights”
Outline-recognition component whose
dimension Y is from 1.7 mm to 150.0
mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Outline-recognition component whose
dimension Y is from 9.0 mm to 120.0
mm
When the light type is not “Back Lights”
Check that displays the error message “Different VCS type” on the screen
Dimension X of a component is from
68.0 mm to 74.0 mm and the number of
divisions X is 2.
If a VCS other than the standard VCS is selected
Dimension X of a component is from
50.0 mm to 68.0 mm and the number of
divisions X is 2.
If a VCS other than the standard VCS and optional 37.5-mm VCS
is selected
Dimension X of a component is
from48.0 mm to 50.0 mm and the
number of divisions X is 2.
If a VCS other than an optional 37.5-mm VCS is selected
Dimension X of a component is from
34.0 mm to 48.0 mm and the number of
divisions X is 2.
If a VCS other than an optional 37.5- or 27-mm VCS is selected
Dimensions of a component are from
31.0 mm to 34.0 mm and the number of
divisions X is 2.
If a VCS other than an optional 27-mm VCS is selected
Dimension X of a component is from
24.0 mm to 31.0 mm and the number of
divisions X is 2.
If a VCS other than an optional 27-mm VCS or 18-mm VCS is
selected
Dimensions of a component are from
15.5 mm to 24.0 mm and the number of
divisions X is 2.
If a VCS other than an optional 18-mm VCS is selected
Dimension X of a component is from
34.0 mm to 50.0 mm and the number of
divisions X is 1.
If a VCS other than the standard VCS is selected
4 – 147
Dimension X of a component is from
24.0 mm to 34.0 mm and the number
of divisions X is 1.
If a VCS other than the standard VCS or optional 37.5-mm VCS is
selected
Dimension X of a component is from
15.5 mm to 24.0 mm and the number
of divisions X is 1.
If a VCS other than the standard VCS or optional VCS (37.5-mm or
27-mm) is selected
Dimension X of a component is from
2.3 mm to 2.5 mm and the number of
divisions X is 1.
If the component type is a lead component and the standard VCS
is used
Dimension X of a component is from
2.1 mm to 2.3 mm and the number of
divisions X is 1.
If the component type is a lead component and the standard VCS
or optional 37.5-mm VCS is used
Dimension X of a component is from
1.9 mm to 2.1 mm and the number of
divisions X is 1.
If the component type is a lead component and a VCS other than
an optional 18.0-mm VCS is selected
Component dimension X is from1.2
mm to 2.0 mm and the number of
divisions X is 1.
If the component type is a ball component and the standard VCS is
selected
Dimension X of a component is from
1.0 mm to 1.2 mm and the number of
divisions X is 1.
If the component type is a ball component and the standard VCS or
optional 37.5-mm VCS is selected
Dimension X of a component is from
0.6 mm to 1.0 mm and the number of
divisions X is 1.
If the component type is a ball component and a VCS other than an
optional 18.0-mm VCS is selected
Dimension Y of a component is from
100.5 mm to 150 mm and the number
of divisions Y is 3.
If a VCS other than the standard VCS is selected
Dimension Y of a component is from
100 mm to 100.5 mm and the number
of divisions Y is 3.
If a VCS other than the standard VCS or optional 37.5-mm VCS is
selected
Dimension Y of a component is from
72 mm to 100 mm and the number of
divisions Y is 3.
If a VCS other than an optional 37.5-mm VCS is selected
Dimension Y of a component is from
68 mm to 72 mm and the number of
divisions Y is 3.
If a VCS other than an optional 37.5-mm or 27-mm VCS is selected
Dimension Y of a component is from
48 mm to 68 mm and the number of
divisions Y is 3.
If a VCS other than an optional 27-mm VCS is selected
Dimension Y of a component is from
31.0 mm to 46.5 mm and the number
of divisions Y is 3.
If a VCS other than an optional 18-mm VCS is selected
Dimension Y of a component is from
68 mm to 100 mm and the number of
divisions Y is 2.
If a VCS other than the standard VCS is selected
Dimension Y of a component is from
50 mm to 68 mm and the number of
divisions Y is 2.
If a VCS other than the standard VCS or optional 37.5-mm VCS is
selected
Dimension Y of a component is from
48 mm to50 mm and the number of
divisions Y is 2.
If a VCS other than an optional 37.5-mm VCS is selected
Dimension Y of a component is from
34 mm to 48 mm and the number of
divisions Y is 2.
If a VCS other than an optional 37.5-mm or 27-mm VCS is selected
4 – 148
Dimension Y of a component is from
31 mm to 34 mm and the number of
divisions Y is 2.
If a VCS other than an optional 27-mm VCS is selected
Dimension Y of a component is from
24 mm to 31 mm and the number of
divisions Y is 2.
If a VCS other than an optional 27-mm or 18-mm VCS is selected
Dimension Y of a component is from
15.5 mm to 31 mm and the number of
divisions Y is 2.
If a VCS other than an optional 18-mm VCS is selected
Dimension Y of a component is from
34 mm to 50 mm and the number of
divisions Y is 1.
If a VCS other than the standard VCS is selected
Dimension Y of a component is from
24 mm to 34 mm and the number of
divisions Y is 1.
If a VCS other than the standard VCS and optional 37.5-mm VCS
is selected
Dimension Y of a component is from
15.5 mm to 24 mm and the number of
divisions Y is 1.
If a VCS other than the standard VCS and optional VCS (37.5-mm
or 27-mm) is selected
(That is, if an optional 18-mm VCS is selected)
Dimension Y of a component is from
2.3 mm to 2.5 mm and the number of
divisions X is 1.
If the standard VCS is selected
Dimension Y of a component is from
2.1 mm to 2.3 mm and the number of
divisions X is 1.
If the standard VCS or optional 37.5-mm VCS is selected
Dimension Y of a component is from
1.9 mm to 2.1 mm and the number of
divisions X is 1.
If a VCS other than an optional 18.0-mm VCS is selected
Dimension Y of a component is
from1.2 mm to 2.0 mm and the
number of divisions Y is 1.
If the component type is a ball component and the standard VCS is
selected
Dimension Y of a component is from
1.0 mm to 1.2 mm and the number of
divisions Y is 1.
If the component type is a ball component and the standard VCS or
optional 37.5-mm VCS is used
Dimension Y of a component is from
0.6 mm to 1.0 mm and the number of
divisions Y is 1.
If the component type is a ball component and a VCS other than an
optional 18.0-mm VCS is selected
General-purpose vision component
(lead component) for which the
standard VCS is selected in Control
data
Component whose element pitch is from 0.2 mm to 0.5 mm if the
standard VCS is set in Control data
General-purpose vision component
(lead component) for which an optional
37.5-mm VCS is selected in Control
data
Component whose element pitch is from 0.2 mm to 0.4 mm or from
15.0 mm to 22.0 mm if an optional 37.5-mm VCS is set in Control
data
General-purpose vision component
(lead component) for which an optional
27-mm VCS is selected in Control data
Component whose element pitch is from 0.2 mm to 0.3 mm or from
11.0 mm to 22.0 mm if an optional 27-mm VCS is set in Control
data
General-purpose vision component
(lead component) for which an optional
18-mm VCS is selected in Control data
Component whose element pitch is from 6.5 mm to 22.0 if an
optional 18-mm VCS is set in Control data
General-purpose vision component
(ball component) for which the
standard VCS is selected in Control
data
Component whose element pitch is from 0.35 mm to 1.0 mm if the
standard VCS is set in Control data
