4 – 134 (3-2) Coher ence check item s: error conditions Data ty pe Item Error conditions Any centering method w hich allows placement is not set. Centering method The standard VCS and optional VCS are not av ailable for …

4 – 133

Data type Item Error conditions

Placement

data

Placement layer

(for a KE-2030)

When the “Sequential and Mix Mode” is selected at the menu

item “2030 Mode Specification” on the “2000 Option” tab, and

“Use manual station/position arrangements” as the menu

item “Pick Data” of the “Assignments” tab of the

“Optimization” menu, and all component pick-up positions are

specified, an error occurs if the In and OUT stations are not

specified in this order as the layer assignment order of the IN

station and OUT station on Placement data respectively.

* When the component placement head is automatically set,

the machine obtains information on the specified station

from Pick data.

If both of the stations have the specified component

placement heads, those heads pass the layer check.

Maximum PL value on the IN side

≦

Minimum simultaneous

placement PL value

≦

Maximum simultaneous placement PL

value

≦

Minimum PL value on the OUT side

PL: placement layer number

*1: Items applicable to machines other than a KE-2010

4 – 134

(3-2) Coherence check items: error conditions

Data type Item Error conditions

Any centering method which allows placement is not set. Centering method

The standard VCS and optional VCS are not available for

vision centering.

Component package

Although the “Packaging style” is set in Component data

of tray components, the item “Packaging style” cannot be

set to “Tray”.

If the “Parallel Mode” is selected at the menu item “2030

Mode Specification” of the “2000 Option” tab, “Use

permanent nozzle setup from MSL Setup” is selected at the

menu item “Nozzle” of the “Assignments” tab of the

“Optimization” menu, and a nozzle specified on the

Component data screen does not exist on both of the

stations.

If the “Parallel Mode” is selected at the menu item “2030

Mode Specification” of the “2000 Option” tab, “Auto arrange

empty nozzle positions” is selected at the menu item “Nozzle”

of the “Assignments” tab of the “Optimization” menu, a nozzle

specified on the Component data screen does not exist on

both of the stations, and there is no not-occupied ATC

position.

If the “Sequential and Mix Mode” is selected at the menu item

“2030 Mode Specification” of the “2000 Option” tab, “Use

permanent nozzle setup from MSL Setup” is selected at the

menu item “Nozzle” of the “Assignments” tab of the

“Optimization” menu, “AUTO” is selected at the menu item

“SPLY” (supply) of any component on the Pick data screen

that is associated with Component data, and a nozzle

specified on the Component data screen does not exist on

both of the stations.

Nozzle (for a KE-2030)

If the “Sequential and Mix Mode” is selected at the menu item

“2030 Mode Specification” of the “2000 Option” tab, “Auto

arrange empty nozzle positions” is selected at the menu item

“Nozzle” of the “Assignments” tab of the “Optimization” menu,

“AUTO” is selected at the menu item “SPLY” (supply) of any

component on the Pick data screen that is associated with

Component data, and a nozzle specified on the Component

data screen does not exist on both of the stations.

Component

data

Component dimensions

The dimensions set in Component data cannot be handled

with the machine.

Note:

△

means that the indicated component height is

applicable if the component height is set to "20 mm" on the

MS Parameter menu of a chip shooter/mounter.

Component

height

2010 2020 2030 2040

0 ＜ H ≦ 6 mm ○ ○ ○ ○

6 ＜ H ≦ 12 mm △ ○ ○

12 ＜ H ≦ 20 mm △ △ ○

20 ＜ H ≦ 25 mm ○

4 – 135

Data type Item Error conditions

Component dimensions

Note:

△

means that the indicated dimensions are applicable

if an image of a component such as a connector is

divided, then recognized. The maximum dimensions

of a component is 150 mm (150 x 50). When you do

not use he FMLA head of a KE-2020, the maximum

dimensions are 29 mm.

If the machine does not use the KE-2020 MNLA

head, the minimum dimension is 0.45 mm or less.

Note: When the machine does not use the KE-2020 FMLA

head, the maximum length of a diagonal line of a

component is 30.7 mm or less.

Chip rise detecting option

There is not any station that can handle a chip rise detection

unit.

Head (when vision centering)

All of the FMLA heads (R head for a KE-2020, L and R

heads for a KE-2040) are set to “Not used” on the Setup

menu.

Head (when laser centering)

All of the NMLA heads/FMLA heads are set to “Not used” on

the Setup menu, and those heads are set to “Used” on the

Component data editing screen.

Nozzle data (“Grip Position”

and “Nozzle Direction at

Picking”)

- A value other than “0” is set to the X” field of the menu item

“Grip Position.”

- A value other than 0, 90, 180 and 270 degrees is set at the

menu item “Nozzle Direction at Picking.”

Shuttle (Expansion –

MTC/MTS/DTS)

The “Packaging style” is set to “Tray”, “Feeder” is set to

“MTC/MTS”, “Compo Reject to” is set to “Tray Restore”,

“Shuttle” is set to “Mecha”, and there is only an MTC(s) in the

line.

Component

data

Prerotate angle (When

laser-centering)

The prerotate angle (A) is not set to a value within the

regulated range: 0 degree

≦

＜

45 degrees.

*1: Items applicable to machines other than a KE-2010

Component

dimensions

2010 2020 2030 2040

L ＜ 0.45 mm ○

○

Note

○

0.45 ≦ L ≦ 26.5mm ○ ○ ○ ○

26.5 ＜ L ≦ 50 mm

○

Note

○

50 ＜ L ≦ 150 mm △ △

The length of a

diagonal line of a

component to be

centered with laser

2010 2020 2030 2040

30.7 mm or less ○ ○ ○ ○

30.7 mm to 47 mm

○

Note

○
