4 – 144
To check a general-purpose vision component, the system assigns priorities to its data as
shown below, then performs the data coherence check in the order of the priorities.
If an error is detected when the system checks data whose priority is relatively higher, the
system finishes checking data on the component at that point.
The detailed error message appears below the item at which an error is detected.
1. Component data
1.1 Component type (lead components, ball components, outline-recognition
components and other components whose vision is used for centering)
1.2 Dimensions
2 Element data
2.1 Element group
2.2 Element
3 Control data
3.1 Light type
3.2 Number of divisions
3.3 Applied VCS
Check that displays the error message “Wrong element group setting” on the screen
Component dimension X
The offset coordinate X is the absolute value of the component
dimension or larger value.
Component dimension Y
The offset coordinate Y is the absolute value of the component
dimension or larger value.
Check that displays the error message “Wrong element setting” on the screen
Component dimension X
The offset coordinate X is the absolute value of the component
dimension or larger value.
Component dimension Y
The offset coordinate Y is the absolute value of the component
dimension or larger value.
Lead component whose dimension X is
from 2.5 mm to 74.0 mm
Component whose pitch X is not within the range between 0.5 mm
and 22 mm
Lead component whose dimension X is
from 2.3 mm to 68.0 mm
Component whose pitch X is not within the range between 0.4 mm
and 15.0 mm
Lead component whose dimension X is
from 2.1 mm to 48.0 mm
Component whose pitch X is not within the range between 0.3mm
and 11.0 mm
Lead component whose dimension X is
from 1.9 mm to 31.0 mm
Component whose pitch X is not within the range between 0.2 mm
and 6.5 mm
Ball component whose dimension X is
from 2.0 mm to 74.0 mm
Component whose pitch X is not within the range between 1.0 mm
and 22.0 mm
Ball component whose dimension X is
from 1.2 mm to 68.0 mm
Component whose pitch X is not within the range between 0.8 mm
and 15.0 mm
Ball component whose dimension X is
from 1.0 mm to 48.0 mm
Component whose pitch X is not within the range between 0.5 mm
and 11.0 mm
Ball component whose dimension X is
from 0.6 mm to 31.0 mm
Component whose pitch X is not within the range between 0.35 mm
and 6.5 mm
Ball component whose dimension Y is
from 2.0 mm to 150.0 mm
Component whose pitch Y is not within the range between 1.0 mm
and 22.0 mm
Ball component whose dimension Y is
from 1.2 mm to 100.5 mm
Component whose pitch Y is not within the range between 0.8 mm
and 15.0 mm
Ball component whose dimension Y is
from 1.0 mm to 72.0 mm
Component whose pitch Y is not within the range between 0.5 mm
and 11.0 mm
4 – 145
Ball component whose dimension Y is
from 0.6 mm to 46.5 mm
Component whose pitch Y is not within the range between 0.35 mm
and 6.5 mm
Lead component whose dimension X is
from 2.5 mm to 74.0 mm
Element dimension X is not within the range between 0.22 mm and
11.0 mm
Lead component whose dimension X is
from 2.3 mm to 68.0 mm
Element dimension X is not within the range between 0.15 mm and
7.7 mm
Lead component whose dimension X is
from 2.1 mm to 48.0 mm
Element dimension X is not within the range between 0.11 mm and
5.5mm
Lead component whose dimension X is
from1.9 mm to 31.0 mm
Element dimension X is not within the range between 0.08 mm and
3.7 mm
Lead component whose dimension Y is
from 2.5 mm to 150.0 mm
Element dimension Y is not within the range between 0.4 mm and
20.0 mm
Lead component whose dimension Y is
from 2.3 mm to 100.5 mm
Element dimension Y is not within the range between 0.3 mm and
14.0 mm
Lead component whose dimension Y is
from 2.1 mm to 72.0 mm
Element dimension Y is not within the range between 0.2 mm and
10.0 mm
Lead component whose dimension Y is
from 1.9 mm to 46.5 mm
Element dimension Y is not within the range between 0.14 mm and
7.0 mm
Ball component whose dimension X is
from 2.0 mm to 74.0 mm
Element dimension X is not within the range between 0.4 mm and
5.0 mm
Ball component whose dimension X is
from 1.2 mm to 68.0 mm
Element dimension X is not within the range between 0.28 mm and
3.5 mm
Ball component whose dimension X is
from 1.0 mm to 48.0 mm
Element dimension X is not within the range between 0.2 mm and
2.5 mm
Ball component whose dimension X is
from 0.6 mm to 31.0 mm
Element dimension X is not within the range between 0.14 mm and
1.5 mm
Mark component whose dimension X is
from 5.0 mm to 74.0 mm
Element dimension X is not within the range between 2.0 mm and
10.0 mm
Mark component whose dimension X is
from 3.5 mm to 68.0 mm
Element dimension X is not within the range between 1.4 mm and
7.0 mm
Mark component whose dimension X is
from 2.5 mm to 48.0 mm
Element dimension X is not within the range between 1.0 mm and
5.0 mm
Mark component whose dimension X is
from 1.7 mm to 31.0 mm
Element dimension X is not within the range between 0.7 mm and
3.0 mm
Mark component whose dimension Y is
from 5.0 mm to 150.0 mm
Element dimension Y is not within the range between 2.0 mm and
10.0 mm
Mark component whose dimension Y is
from 3.5 mm to 100.5 mm
Element dimension Y is not within the range between 1.4 mm and
7.0 mm
Mark component whose dimension Y is
from2.5 mm to 72.0 mm
Element dimension Y is not within the range between 1.0 mm and
5.0 mm
Mark component whose dimension Y is
from 1.7 mm to 46.5 mm
Element dimension Y is not within the range between 0.7 mm and
3.0 mm
Check that displays the error message “Wrong number of divisions” on the screen
Component whose dimension X is
50.0 mm or more
When “2” is not selected as the number of divisions
Component whose dimension Y is
50.0 mm or more
When “1” is selected as the number of divisions
Component whose dimension Y
is120.0 mm or more
When “3” is not selected as the number of divisions
Component whose dimension Y is
from 46.5 mm to 48 mm
When “3” is selected as the number of divisions
4 – 146
Check that displays the error message “The light type is different” on the screen
Lead component whose dimension X is
from 1.9 mm to 74 mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Lead component whose dimension X is
from 9.0 mm to 35.0 mm
When the light type is not “Back Light”
Lead component whose dimension Y is
from 1.9 mm to 150.0 mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Lead component whose dimension Y is
from 9.0 mm to 120.0 mm
When the light type is not “Back Lights”
Ball component whose dimension X is
from 0.6 mm to 74 mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Ball components When the light type is “Back Lights”
Ball component whose dimension Y is
from 0.6 mm to 150.0 mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Outline-recognition component whose
dimension X is from 1.7 mm to 74 mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Outline-recognition component whose
dimension X is from 9.0 mm to 35.0 mm
When the light type is not “Back Lights”
Outline-recognition component whose
dimension Y is from 1.7 mm to 150.0
mm
When the light type is neither “Bottom Lights” nor “Side Lights”
Outline-recognition component whose
dimension Y is from 9.0 mm to 120.0
mm
When the light type is not “Back Lights”
Check that displays the error message “Different VCS type” on the screen
Dimension X of a component is from
68.0 mm to 74.0 mm and the number of
divisions X is 2.
If a VCS other than the standard VCS is selected
Dimension X of a component is from
50.0 mm to 68.0 mm and the number of
divisions X is 2.
If a VCS other than the standard VCS and optional 37.5-mm VCS
is selected
Dimension X of a component is
from48.0 mm to 50.0 mm and the
number of divisions X is 2.
If a VCS other than an optional 37.5-mm VCS is selected
Dimension X of a component is from
34.0 mm to 48.0 mm and the number of
divisions X is 2.
If a VCS other than an optional 37.5- or 27-mm VCS is selected
Dimensions of a component are from
31.0 mm to 34.0 mm and the number of
divisions X is 2.
If a VCS other than an optional 27-mm VCS is selected
Dimension X of a component is from
24.0 mm to 31.0 mm and the number of
divisions X is 2.
If a VCS other than an optional 27-mm VCS or 18-mm VCS is
selected
Dimensions of a component are from
15.5 mm to 24.0 mm and the number of
divisions X is 2.
If a VCS other than an optional 18-mm VCS is selected
Dimension X of a component is from
34.0 mm to 50.0 mm and the number of
divisions X is 1.
If a VCS other than the standard VCS is selected
