4 – 149 General-purpose vision component (ball component) for which an optional 37.5-mm VCS is selected in Control data Component whose element pitch is from 0.35mm to 0.8 mm or from 15.0 mm to 22.0 mm if an optional 37.…

100%1 / 1361
4 – 148
Dimension Y of a component is from
31 mm to 34 mm and the number of
divisions Y is 2.
If a VCS other than an optional 27-mm VCS is selected
Dimension Y of a component is from
24 mm to 31 mm and the number of
divisions Y is 2.
If a VCS other than an optional 27-mm or 18-mm VCS is selected
Dimension Y of a component is from
15.5 mm to 31 mm and the number of
divisions Y is 2.
If a VCS other than an optional 18-mm VCS is selected
Dimension Y of a component is from
34 mm to 50 mm and the number of
divisions Y is 1.
If a VCS other than the standard VCS is selected
Dimension Y of a component is from
24 mm to 34 mm and the number of
divisions Y is 1.
If a VCS other than the standard VCS and optional 37.5-mm VCS
is selected
Dimension Y of a component is from
15.5 mm to 24 mm and the number of
divisions Y is 1.
If a VCS other than the standard VCS and optional VCS (37.5-mm
or 27-mm) is selected
(That is, if an optional 18-mm VCS is selected)
Dimension Y of a component is from
2.3 mm to 2.5 mm and the number of
divisions X is 1.
If the standard VCS is selected
Dimension Y of a component is from
2.1 mm to 2.3 mm and the number of
divisions X is 1.
If the standard VCS or optional 37.5-mm VCS is selected
Dimension Y of a component is from
1.9 mm to 2.1 mm and the number of
divisions X is 1.
If a VCS other than an optional 18.0-mm VCS is selected
Dimension Y of a component is
from1.2 mm to 2.0 mm and the
number of divisions Y is 1.
If the component type is a ball component and the standard VCS is
selected
Dimension Y of a component is from
1.0 mm to 1.2 mm and the number of
divisions Y is 1.
If the component type is a ball component and the standard VCS or
optional 37.5-mm VCS is used
Dimension Y of a component is from
0.6 mm to 1.0 mm and the number of
divisions Y is 1.
If the component type is a ball component and a VCS other than an
optional 18.0-mm VCS is selected
General-purpose vision component
(lead component) for which the
standard VCS is selected in Control
data
Component whose element pitch is from 0.2 mm to 0.5 mm if the
standard VCS is set in Control data
General-purpose vision component
(lead component) for which an optional
37.5-mm VCS is selected in Control
data
Component whose element pitch is from 0.2 mm to 0.4 mm or from
15.0 mm to 22.0 mm if an optional 37.5-mm VCS is set in Control
data
General-purpose vision component
(lead component) for which an optional
27-mm VCS is selected in Control data
Component whose element pitch is from 0.2 mm to 0.3 mm or from
11.0 mm to 22.0 mm if an optional 27-mm VCS is set in Control
data
General-purpose vision component
(lead component) for which an optional
18-mm VCS is selected in Control data
Component whose element pitch is from 6.5 mm to 22.0 if an
optional 18-mm VCS is set in Control data
General-purpose vision component
(ball component) for which the
standard VCS is selected in Control
data
Component whose element pitch is from 0.35 mm to 1.0 mm if the
standard VCS is set in Control data
4 – 149
General-purpose vision component (ball
component) for which an optional
37.5-mm VCS is selected in Control
data
Component whose element pitch is from 0.35mm to 0.8 mm or
from 15.0 mm to 22.0 mm if an optional 37.5-mm VCS is set in
Control data
General-purpose vision component (ball
component) for which an optional
27-mm VCS is selected in Control data
Component whose element pitch is from 0.35 mm to 0.5 mm or
from 11.0 mm to 22.0 mm if an optional 27-mm VCS is set in
Control data
General-purpose vision component (ball
component) for which an optional
18-mm VCS is selected in Control data
Component whose element pitch is from 6.5 mm to 22.0 if an
optional 18-mm VCS is set in Control data
General-purpose vision component
(lead component) for which the
standard VCS is selected in Control
data
Component whose element size X is from 0.08 mm to 0.22 mm if
the standard VCS is set in Control data
General-purpose vision component
(lead component) for which an optional
37.5-mm VCS is selected in Control
data
Component whose element size X is from 0.08mm to 0.15 mm or
from 7.7 mm to 11.0 mm if an optional 37.5-mm VCS is set in
Control data
General-purpose vision component
(lead component) for which an optional
27-mm VCS is selected in Control data
Component whose element size X is from 0.08 mm to 0.11 mm or
from 5.5 mm to 11.0 mm if an optional 27-mm VCS is set in Control
data
General-purpose vision component
(lead component) for which an optional
18-mm VCS is selected as Control data
Component whose element size X is from 3.7 mm to 11.0 if an
optional 18-mm VCS is set in Control data
General-purpose vision component
(lead component) for which the
standard VCS is selected in Control
data
Component whose element size Y is from 0.14 mm to 0.4 mm if
the standard VCS is set in Control data
General-purpose vision component
(lead component) for which an optional
37.5-mm VCS is selected in Control
data
Component whose element size Y is from 0.14mm to 0.3 mm or
from 14.0 mm to 20.0 mm if an optional 37.5-mm VCS is set in
Control data
General-purpose vision component
(lead component) for which an optional
27-mm VCS is selected in Control data
Component whose element size Y is from 0.14mm to 0.2 mm or
from 10.0 mm to 20.0 mm if an optional 27-mm VCS is set in
Control data
General-purpose vision component
(lead component) for which an optional
18-mm VCS is selected in Control data
Component whose element size Y is from 7.0 mm to 20.0 mm if an
optional 18-mm VCS is set in Control data
General-purpose vision component (ball
component) for which the standard VCS
is selected in Control data
Component whose element size is from 0.14 mm to 0.4 mm if the
standard VCS is set in Control data
General-purpose vision component (ball
component) for which an optional
37.5-mm VCS is selected in Control
data
Component whose element size is from 0.14mm to 0.3 mm or from
3.5 mm to 5.0 mm if an optional 37.5-mm VCS is set in Control
data
General-purpose vision component (ball
component) for which an optional
27-mm VCS is selected in Control data
Component whose element size is from 0.14 mm to 0.2 mm or
from 2.5 mm to 5.0 mm if an optional 27-mm VCS is set in Control
data
General-purpose vision component (ball
component) for which an optional
18-mm VCS is selected in Control data
Component whose element size is from 1.5 mm to 5.0 mm if an
optional 18-mm VCS is set in Control data
General-purpose vision component
(mark component) for which the
standard VCS is selected in Control
data
Component whose element size X is from 0.7 mm to 2.0 mm if
the standard VCS is set in Control data
General-purpose vision component
(mark component) for which an optional
37.5-mm VCS is selected in Control
data
Component whose element size X is from 0.7mm to 1.4 mm or
from 7.0 mm to 10.0 mm if an optional 37.5-mm VCS is set in
Control data
4 – 150
General-purpose vision component
(mark component) for which an optional
27-mm VCS is selected in Control data
Component whose element size X is from 0.7 mm to 1.0 mm or
from 5.0 mm to 10.0 mm if an optional 27-mm VCS is set in
Control data
General-purpose vision component
(mark component) for which an optional
18-mm VCS is selected in Control data
Component whose element size X is from 3.0 mm to 10.0 mm if an
optional 18-mm VCS is set in Control data
General-purpose vision component
(mark component) for which the
standard VCS is selected in Control
data
Component whose element size Y is from 0.7 mm to 2.0 mm if the
standard VCS is set in Control data
General-purpose vision component
(mark component) for which an optional
37.5-mm VCS is selected in Control
data
Component whose element size Y is from 0.7mm to 1.4 mm or
from 7.0 mm to 10.0 mm if an optional 37.5-mm VCS is set in
Control data
General-purpose vision component
(mark component) for which an optional
27-mm VCS is selected in Control data
Component whose element size Y is from 0.7 mm to 1.0 mm or
from 5.0 mm to 10.0 mm if an optional 27-mm VCS is set in
Control data
General-purpose vision component
(mark component) for which an optional
18-mm VCS is selected in Control data
Component whose element size Y is from 3.0 mm to 10.0 if an
optional 18-mm VCS is set in Control data
Standard VCS is selected, the number
of divisions X is 1, and the light type is
“Bottom Lights” or “Side Lights”.
If a value not in the range from - 50 mm to 50 mm is entered as the
offset coordinate X
Standard VCS is selected and the
number of divisions X is 1, and the light
type is “Back Light”.
If a value not in the range from - 35 mm to 35 mm is entered as the
offset coordinate X
Optional 37.5-mm VCS is selected and
the number of divisions X is 1.
If a value not in the range from - 34 mm to 34 mm is entered as the
offset coordinate X
Optional 27-mm VCS is selected and
the number of divisions X is 1.
If a value not in the range from - 24 mm to 24 mm is entered as the
offset coordinate X
Optional 18-mm VCS is selected and
the number of divisions X is 1.
If a value not in the range from - 15 mm to 15 mm is entered as the
offset coordinate X
Standard VCS is selected, the number
of divisions Y is 2, and the light type is
“Bottom Lights” or “Side Lights”.
If a value not in the range from - 100 mm to 100 mm is entered as
the offset coordinate Y
Standard VCS is selected, the number
of divisions Y is 1, and the light type is
“Bottom Lights” or “Side Lights”.
If a value not in the range from - 50 mm to 50 mm is entered as the
offset coordinate Y
Standard VCS is selected, the number
of divisions Y is 2, and the light type is
“Back Lights”.
If a value not in the range from - 100 mm to 100 mm is entered as
the offset coordinate Y
Standard VCS is selected, the number
of divisions Y is 1, and the light type is
“Back Lights”.
If a value not in the range from - 50 mm to 50 mm is entered as the
offset coordinate Y
Optional 37.5-mm VCS is selected, and
the number of divisions Y is 2.
If a value not in the range from - 68 mm to 68 mm is entered as the
offset coordinate Y
Optional 37.5-mm VCS is selected, and
the number of divisions Y is 1.
If a value not in the range from - 34 mm to 34 mm is entered as the
offset coordinate Y
Optional 27-mm VCS is selected, and
the number of divisions Y is 2.
If a value not in the range from - 48 mm to 48 mm is entered as the
offset coordinate Y
Optional 27-mm VCS is selected, and
the number of divisions Y is 1.
If a value not in the range from - 24 mm to 24 mm is entered as the
offset coordinate Y
Optional 18-mm VCS is selected, and
the number of divisions Y is 2.
If a value not in the range from - 31 mm to 31 mm is entered as the
offset coordinate Y
Optional 18-mm VCS is selected, and
the number of divisions Y is 1.
If a value not in the range from - 15 mm to 15 mm is entered as the
offset coordinate Y
