7
Error Messages on Machine Operations (for helping you to edit a program)
Error code Message
E291000 Conveyor already operated, it is not possible to operation
E291001 The origin point return is non-completion. Please operate again after completing the origin
point return
E291002 The axis cannot be moved to escape point. Execution is aborted
E291003 The conveyor cannot be moved. Execution is aborted
E291004 The conveyor became a time-out. Execution is aborted
E291005 The axis cannot be moved. Execution is aborted
E291006 The BOC mark data is not set. Operation is aborted
E291007 The OCC device is set in unused by the setup
E291008 Value is mistake
E291009 Value out of range
E291010 Conveyor margin out of range. It is not possible to operation
E291011 Cannot move conveyor
E291012 The BOC mark recognition error [Circuit : %d / %d point]
E291013 The area sensor was detected. Execution is aborted
E291014 Emergency stopped. Execution is aborted
E291015 PWB exist in the entry side center buffer. Please execute retry after ejection
E291016 PWB exist in the exit side center buffer. Please execute retry after ejection
E291017 There is no completed pickup data
E291018 Input string is mistake
E291019 Range is mistake
E291020 Please check the feeder to trace
E291021 There is no completed placement data
E291022 Because the one PWB is not clamped, cannot execute the BOC alignment
E291023 The automatic conveyor width adjustment is set in unused by the setup
E291024 The BOC mark data send error [ID : &d]
E291025 Servo off, it is not possible to operation
Q291500 The BOC mark recognition error. Please push ‘No’ when discontinuing. ‘Yes’ when
continuing
Q291501 Operation interruption. Please push ‘No’ when discontinuing. ‘Yes’ when continuing
Q291502 The BOC alignment is executed. Please confirm safety. Please push ‘No’ when
discontinuing. ‘Yes’ when continuing
Q291503 The BOC alignment is executed. Please confirm safety. Please push ‘No’ when
discontinuing. ‘Yes’ when continuing
Q291504 The BOC alignment is executed. Please confirm safety. Please push ‘No’ when
discontinuing. ‘Yes’ when continuing
Q291505 Unit is moved to escape point. Please confirm safety. Please push ‘No’ when
discontinuing. ‘Yes’ when continuing
Q291506 Conveyor width is moved. Please remove handknob and PWB from conveyor. Please
push ‘No’ when discontinuing. ‘Yes’ when continuing
Q291507 The origin point return of automatic conveyor width adjustment is non-completion. Continue
anyway? Please push ‘No’ when discontinue. ‘Yes’ when continuing
8
Error Messages on Mark Database
Error code Message
E292000 No registered data
E292001 Please select the mark
E292002 Registration number was exceeded
E292003 The mark of the same registration name exists
E292004 Please input the registration name
E292005 Please select the registered area
Q292501 The selected mark data is deleted. Is it good?
9
Error Messages on the Machine Setup Operations
Error code Message
E301000 Memory allocation error
E301001 There is no input character
E301002 Input character has irregularities
E301003 Input value exceeds predetermined data range. (Data range:%s)
E301012 An error occurred while measuring nozzle height by Laser
E301015 Specify user’s individual nozzle No.
E301016 An error occurred while taking nozzles off
E301017 Selected device can not move to this position. Please reselect other device on HOD
E301018 Selected device is not installed. Please reselect other device on HOD
E301019 Return to home has not yet been completed
E301020 MTC power off
E301021 MTC offline
E301023 There is no installed head
E301024 Selected device is disable. Please reselect other device on HOD
E301025 MTC is disable
E301026 Servo is in the free state
W301027 Teached data is invaled
E301028 Length of the nozzle is too short. Please check the nozzle
E301032 MTC is in the supply state
E301035 MTS is disable
E301036 MTS power off
E301037 MTS offline
E301038 MTS cannot move because of cover opening
E301039 The door of MTS opens
E301040 There is no specified stacker with the tray steps number
E301042 Because MTS is selected, the IC conveyor belt is not assembled to a rear side
E301044 Nozzle length is too long. Please check out the nozzle
E301046 Only nozzle No. has been input. Please specify nozzle types
E301047 An error occurred while taking nozzles off. The process is discontinued
E301048 Vacuum Calibration unit position can not be measured
E301049 An error occurred while installing nozzles. [Error occurs] %d [Error No.] %d [Error info] %d
E301050 In 2030, Vacuum Calibration can be set for only R1 through R4
E301051 Vacuum Calibration can be et only for small-diameter nozzles. (Settable range : 1 - %d)
E301052 Any heads have not been specified
E301053 The Changer table can not be installed on the rear side since MTC/MTS have been selected
E301054 MTC/MTS can not be connected to 2000 series machines at the same time
E301055 An error on axes occurred
E301056 An error on XY axes occurred
E301057 An error on Z axis occurred
E301058 Specified 508 nozzle has not been assigned yet. Please execute nozzle assignment
E301059 It was impossible to learn the height. Please checck out the vacuum value
E301060 DTS/MTS can not be connected to 2000 series machines at the same time
E301061 Feeder float detector can not be set only out position
Q302000 Reset I/O?
Q302001 Exit machine setup. Set value is saved?
Q302002 Error has occurred during automatic measurement of nozzle. Do you interrupt automatic
measurement?
Q302003 Return to home has not yet been completed. Return to home?
