6 − 49 Value Error conten ts Value Error contents 235 IPC Object Close Error (DTS-1) 302 Retry over 236 IPC Object Close Error (DTS-2) 303 No component 241 IPC Send Error (MTC -1) 304 Offline 242 IPC Receive Error (MT C-…
6 − 48
Value Error contents Value Error contents
10 Request at offline 123 Driver Alarm(Y)
13 Stacker Lock 126 Escape Error(Y)
18 Could not detect tray 128 Tray Error
20 Main Cover open 133 Detect Compo Floating
26 MTS is Supply 138 Clamping Stacker Error
28 No Stacker 141 Impossible servo driver on(Z)
29 Door open 151 Servo alarm
30 Not Receiving Parts Taking Completion
already
161 Test Mode Moving Time Out
40 Receive pick finish during tray
transporting
171 Request cancell
49 MS parameter not entered 182 Switch Off-line
52 Request Changing Stacker when
Normal Mode
183 Switch Supply
61 Home position error(Z) 184 Press MTC EMG Sw
63 Home position error(Y) 185 Retry Out
68 Shutter close error 186 Empty Parts
69 Shutter open error 187 Supply
70 Emergency stop 203 MTS COMM ERR (Data Error)
71 Over run error(Z + limit) 204 MTS COMM ERR (Communication
Error)
73 Over run error(Y + limit) 205 MTS COMM ERR (Procedure Error)
78 Y Holder Error 206 MTS COMM ERR (Synchronous Error)
79 Not finish initialize 207 MTS COMM ERR (Power Off)
80 Mounter emergency stop 208 Step Number of Tray is Wrong
81 Over run eror(Z - limit) 209 MTS is not Available in Setup Data
83 Over run eror(Y - limit) 210 Not Finding STX ETX
88 Interlock error 211 Undefined Command Code is Specified
91 Z error 212 Parts Request Send Multiplexy (WAIT)
93 Y error 213 Parts Request Send Multiplexy (KICK)
98 Opening Y Holder when Z Axis Moving 214 Parts Request is Abnormal
99 Door, Cover SW 215 Response Time Out
100 Overrun error 218, MTS Initialize Incompletely
101 Z axis sensor error 219, Unmovable by Off-line
103 Y axis sensor error 220, Unmovable by Air-Down
106 Clamping Stacker Error 221, IPC Object Open Error (MTC-1)
107 RAM error 222 IPC Object Open Error (MTC-2)
108 Illegal break current 223 IPC Object Open Error (MTS-1)
109 Holder Sensor error 224 IPC Object Open Error (MTS-2)
111 Sensor error(Z + limit) 225 IPC Object Open Error (DTS-1)
113 Sensor error(Y + limit) 226 IPC Object Open Error (DTS-2)
116 Changing Stacker Error 231 IPC Object Close Error (MTC-1)
117 NV-RAM error 232 IPC Object Close Error (MTC-2)
118 Close/open sensor error 233 IPC Object Close Error (MTS-1)
121 Drive Time Out(Z) 234 IPC Object Close Error (MTS-2)
6 − 49
Value Error contents Value Error contents
235 IPC Object Close Error (DTS-1) 302 Retry over
236 IPC Object Close Error (DTS-2) 303 No component
241 IPC Send Error (MTC-1) 304 Offline
242 IPC Receive Error (MTC-1) 305 Supply
243 IPC Send Error (MTC-2) 402 Time Out (Ready Waiting Observation
10sec)
244 IPC Receive Error (MTC-2) 403 Time Out (Sync Character Observation
4sec)
245 IPC Send Error (MTS-1) 404 Time Out (ETX Observation 3sec)
246 IPC Receive Error (MTS-1) 405 MTS Power Off
247 IPC Send Error (MTS-2) 406 Time Out (Responseless Observation 60sec)
248 IPC Receive Error (MTS-2) 407 Receive Data Validity Error
249 IPC Send Error (DTS-1) 408 Ring Buffer Access Error
250 IPC Receive Error (DTS-1) 409 Time Out (Data Link Release 1)
251 IPC Send Error (DTS-2) 410 Time Out (Data Link Release 2)
252 IPC Receive Error (DTS-2) 411 MTS Communication Initialize Failed
301 Move error
⑧ ＣＯＰＬＡ
Value Error contents Value Error contents
33 A coplanarity judgemennt error. 51 The motor revolution is abnormal.
34 A coplanarity centering position error 52 A memory of sencer is abnormal.
35 A lead count error. 53 A initialize error of coplanarity unit.
36 A colinearity judgemennt error. 54 An axis error of coplanarity measurement.
43 A coplanarity unit error. 62 The component type can not be measured.
44 ,A illegal data or illegal operation. 63 The component size is too large.
45 A time-out or other error. 64 The component size is out of range.
46 A coplanarity adjust error. 65 The component height is too high.
47 A hardware error of coplanarity controler. 66 The meas. mode isn't corr. or the compo.
cann't be measured.
48 A measurement software error. 67 The electrode can not be measured.
49 A lasor diode is abnormal. 68 A coplanarity sensor is unused.
50 A cable connection error.
(2) Feeder unit information
No. Displayed items Contents
1 Sply (Supply) Feeder unit of the component pickup failed
2 L Lane No. for feeding by stick feeder
3 Pkg. (Package) Package of the component pickup failed
4 Component name Component name of the component pickup failed
5 Error Reason of component pickup failed
6 − 50
Error contents
No. Display (Cause of the error)
1 No components
2 Different component type
3 LA retry over
4 Retry over
5 Off line
6 Supply
7 Operation error
8 Laser recognition error
9 Chip rise
10 Transfer mistake
11 Feeder bank invalid
12 Stacker invalid
