32 Error M essages on PW B T ransport Con veyor/A uto matic PWB Transport /Idle PWB T ransport Error code Message W 650009 Conveying dev ice error: | Since a PW B w hich interferences the check cylinder, | the cylinder c…
31
E630207 Vision System: It is unprescribed ERR code. ERR7 code
E630208 Vision System: It is unprescribed ERR code. ERR8 code
E630209 Vision System: It is unprescribed ERR code. ERR9 code
E630210 Vision System: Video Synch. Time out error occurred. Hardware abnormality
E630211 Vision System: A time-out error of the serial communication occurred
E630212 Vision System: An error in capturing an image occurred. Hardware abnormality
E630213 Vision System: An error occurred in the internal driver
E630214 Vision System: The running command got a time-out
E630215 Vision System: It is unprescribed ERR code. ERR15 code
E630216 Vision System: It is unprescribed ERR code. ERR16 code”
E630217 Vision System: It is unprescribed ERR code. ERR17 code
E630218 Vision System: It is unprescribed ERR code. ERR18 code
E630219 Vision System: It is unprescribed ERR code. ERR19 code
E630300 ViLib Thread: Other illogical matter occurred
E630301 ViLib Thread: Turnaround time-out occurred
E631010 ViRecog Error: No mark can be found. Please examine the PWB
E631011 ViRecog Error: The mark is touching the frame. Please examine Mark data
E631012 ViRecog Error: The consistency of the marks is too low. Please examine the PWB
E631013 ViRecog Error: Other mark recognition error occurred. Please examine the mark data
E631020 ViRecog Error: The lead is bent. Please examine the component
E631021 ViRecog Error: The position of the lead tip is illegal. Please examine the component
E631022 ViRecog Error: Lead pitch is wrong. Please examine Vision data
E631023 ViRecog Error: Some leads are missing. Please examine Vision data
E631024 ViRecog Error: The number of leads is too large. Please examine Vision data”
E631025 ViRecog Error: Failed to detect leads. Please examine the picking posture
E631026 ViRecog Error: The number of leads is too small. Please examine Vision data
E631027 ViRecog Error: Failed to find lead(s). Please examine Pick position
E631028 ViRecog Error:Mis-recognized the fine pitch lead. Please examine Light conditions
Q631180 There is a similar pattern in the upper part of the template. Would you like to take the
teaching results in?
Q631181 There is a similar pattern in the lower part of the template. Would you like to take the
teaching results in?
Q631182 There is a similar pattern on the left side of the template. Would you like to take the teaching
results in?
Q631183 There is a similar pattern on the right side of the template. Would you like to take the
teaching results in?
Q631184 “The template does not have enough contrast. Would you like to take the teaching results
in
Q631185 The template has no features. Would you like to take the teaching results in?
E631186 The contrast for the entire image is too low. Please modify the conditions and teach again”
Q631200 The light is getting darker. Please clean the light
E631201 The light is too dark. Please clean the light
E631202 The light is not ON. Please examine it
32
Error Messages on PWB Transport Conveyor/Automatic PWB Transport /Idle PWB Transport
Error code Message
W650009 Conveying device error: | Since a PWB which interferences the check cylinder, | the cylinder
can not come up. | Please remove the PWB
E650010 Conveying device error: | Due to the abnormality of the check cylinder sensor, | cylinder can
not come up. | Please re-start the machine and check again
E650100 Conveying error : An asynchronous, abnormal event occurred while PWB conveying. The
process is forcibly terminated
W650203 PWB Conveying Error: There is no PWB objective to be conveyed
W650204 PWB Clamp Error : There is no PWB objective to be unlocked
W650205 Conveying Error : Please carry out the PWB on the Exit side station prior to the one on the
Entrance side station
W650209 PWB Conveying Error : A PWB has been detected on the conveying route. Please remove it
W650211 PWB Conveying Error : A PWB has been detected on the center station. Please remove it
W650212 PWB Conveying Error : A PWB has been detected on the center station on the Entrance
side. Please remove it
W650213 PWB Conveying Error : A PWB has been detected on the center station on the Exit side.
Please remove it
W650214 PWB Conveying Error : A PWB has been detected on the OUT buffer. Please remove it
W650219 PWB Conveying Error : In operation of PWB conveying
E650221 PWB Conveying Error : Illegal input buffer motor movement. The process is forcibly
terminated. Please remove on the conveying route
E650222 PWB Conveying Error : PWB conveying error of Input buffer. The process is forcibly
terminated. Please remove on the conveying route
E650223 PWB Conveying Error: PWB conveying error of Input buffer. The process is forcibly
terminated. Please remove on the conveying route”
E650224 PWB Conveying Error : PWB conveying time out error of Input buffer. The process is
forcibly terminated. Please remove on the conveying route
E650234 PWB Conveying Error : PWB conveying time out error of the center station. The process is
forcibly terminated. Please remove on the conveying route
E650242 PWB Conveying Error : PWB conveying error of the center station on the Entrance side.
The process is forcibly terminated. Please remove on the conveying route
E650243 PWB Conveying Error : PWB conveying error of the center station on the Entrance side.
The process is forcibly terminated. Please remove on the conveying route
E650244 PWB Conveying Error : PWB conveying time out error of the center station on the Entrance
side. The process is forcibly terminated. Please remove on the conveying route
E650252 PWB conveying error of the center station on the Exit side. The process is forcibly
terminated. Please remove on the conveying route
E650253 PWB Conveying Error : PWB conveying error of the center station on the Exit side. The
process is forcibly terminated. Please remove on the conveying route
E650254 PWB Conveying Error : PWB conveying time out error of the center station on the Exit side.
The process is forcibly terminated. Please remove on the conveying route
E650262 PWB Conveying Error : PWB conveying error of Output buffer. The process is forcibly
terminated. Please remove on the conveying route
E650264 PWB Conveying Error : PWB conveying time out error of Output buffer. The process is
forcibly terminated. Please remove on the conveying route
E650265 PWB Conveying Error : PWB conveying time out error of Output buffer. The process is
forcibly terminated. Please remove on the conveying route
E650271 Clamp error : Backup plate of the center station went up illegally. The process is forcibly
terminated. Please remove on the conveying route
E650272 Clamp error : Time-out occurred while backup plate of the center station went up. The
process is forcibly terminated. Please remove on the conveying route
E650273 Clamp error : Backup plate of the center station went down illegally. The process is forcibly
terminated. Please remove on the conveying route
E650274 Clamp error : Time-out occurred while backup plate of the center station went down. The
process is forcibly terminated. Please remove on the conveying route
33
E650275 Clamp error : Something is wrong with the backup motor movement of the center station.
The process is forcibly terminated. Please remove on the conveying route
E650276 Clamp error : Hole reference process at the center station finished illegally. The process is
forcibly terminated. Please remove on the conveying route
E650281 Clamp error : Backup plate of the center station on the Entrance side went up illegally. The
process is forcibly terminated. Please remove on the conveying route
E650282 Clamp error : Time-out occurred while backup plate of the center station on the Entrance
side went up. The process is forcibly terminated. Please remove on the conveying route
E650283 Clamp error : Time-out occurred while backup plate of the center station on the Entrance
side went down illegally. The process is forcibly terminated. Please remove on the
conveying route
E650284 Clamp error : Time-out occurred while backup plate of the center station on the Entrance
side went down. The process is forcibly terminated. Please remove on the conveying route
E650285 Clamp error : Something is wrong with the backup motor movement of the center station on
the Entrance side. The process is forcibly terminated. Please remove on the conveying
route
E650286 Clamp error : Hole reference process at the center station on the Entrance side finished
illegally. The process is forcibly terminated. Please remove on the conveying route
E650291 Clamp error : Backup plate of the center station on the Exit side went up illegally. The
process is forcibly terminated. Please remove on the conveying route
E650292 Clamp error : Time-out occurred while backup plate of the center station on the Exit side
went up. The process is forcibly terminated. Please remove on the conveying route
E650293 Clam error : Backup plate of the center station on the Exit side went down illegally. The
process is forcibly terminated. Please remove on the conveying route
E650294 Clamp error : Time-out occurred while backup plate on the center station on the Exit side
went down. The process is forcibly terminated. Please remove on the conveying route
E650295 Clamp error : Something is wrong with the backup motor movement on the center station on
the Exit side. The process is forcibly terminated. Please remove on the conveying route
E650296 Clamp error : Hole reference process at the center station on the Exit side finished illegally.
The process is forcibly terminated. Please remove on the conveying route
W650309 Idle PWB Conveying Error : PWB is detected on the conveying route. Please remove it
W650311 Idle PWB Conveying Error : A PWB is detected on the center station. Please remove it
W650312 Idle PWB Conveying Error : A PWB is detected on the center station on the Entrance side.
Please remove it
W650313 Idle PWB Conveying Error : A PWB is detected on the center station on the Exit side.
Please remove it
W650314 Idle PWB Conveying Error : A PWB is detected on the OUT buffer. Please remove it
W650319 Idle PWB Conveying Error : In operation of Idle PWB conveying
E650321 Idle PWB Conveying Error : Illegal input buffer motor movement. The process is forcibly
terminated. Please remove on the conveying route
E650322 Idle PWB Conveying Error : PWB conveying error of Input buffer. The process is forcibly
terminated. Please remove on the conveying route
E650323 Idle PWB Conveying Error : PWB conveying error of Input buffer. The process is forcibly
terminated. Please remove on the conveying route”
E650324 Idle PWB Conveying Error : PWB conveying time out error of Input buffer. Please remove
on the conveying route
E650334 Idle PWB Conveying Error : PWB conveying time out error of the center station. The
process is forcibly terminated. Please remove on the conveying route
E650342 Idle PWB Conveying Error : PWB conveying error of the center station on the Entrance side.
The process is forcibly terminated. Please remove on the conveying route
E650343 Idle PWB Conveying Error : PWB conveying error of the center station on the Entrance side.
The process is forcibly terminated. Please remove on the conveying route
E650344 Idle PWB Conveying Error : PWB conveying time out error of the center station on the
Entrance side. The process is forcibly terminated. Please remove on the conveying route
E650352 Idle PWB Conveying error : PWB conveying error of the center station on the Exit side. The
process is forcibly terminated. Please remove on the conveying route
E650353 Idle PWB Conveying Error : PWB conveying error of the center station on the Exit side. The
process is forcibly terminated. Please remove on the conveying route
