3 − 7
3.3.2 Selecting a menu
There are two possible ways to select a pull-down menu from among those contained
in the menu bar.
(1) Using the cursor keys
①
Press the Alt key to activate the menu bar.
The [File] menu is highlighted.
②
Press the cursor keys.
Press → or ← to go among the menu items in the menu bar.
Press ↑ or ↓ to drop down a pull-down menu. Then, press ↑ or
↓ to move among the commands displayed in the pull-down menu.
To activate the command you want to select, press the ENTER key.
During these operations, the message line shows the summary of the
highlighted command. Press the ESC key to close the menu.
(2) Using the short-cut keys
①
Press the Alt key to activate the menu bar.
The [File] menu is highlighted.
3 − 8
②
Press the key corresponding to the starting character of the desired menu
item.
③
When you press the starting character of the desired command, it
immediately executes the command.
3.3.3 Dialog
If additional information is necessary for the machine to execute a command, a dialog
box appears as soon as the command is selected.
A dialog box may contain the following elements:
(1) Push button
When a push button is selected, it immediately executes the command. Most
dialog boxes contain the OK and Cancel buttons.
(2) Check box
Used to let you choose options or toggle an option on or off. You can select as
many check boxes as you want. When the option is turned on, a check mark (√)
appears in the check box.
To change on or off of the option, highlight the option with the cursor, and press
one of the space keys.
3 − 9
(3) Radio button
Unlike check boxes, radio buttons are mutually exclusive of one another and you
can select only one at a time.
The small circle z moves with the highlighted cursor. Go to the desired option
to exit from the box.
(4) List box
Gives a list of options to choose from, mainly used for selecting a file name.
The selected option is highlighted. If a list contains too many options to show at
a time, it can be scrolled.
