iv
为了安全使用
RX-6/RX-6B/RX-6R
的注意事项
注意
1.
为防止人身受伤，请勿在拆下安全盖（安全罩）、安全装置等状态下运行。
2. 为防止人身受伤，请务必小心，以免头发、衣服等被卷入传送带链。
此外，请勿戴手套。
3. 为防止人身受伤，维护时（注油、调整、日常检修），请切断电源。
4. 为防止人身受伤，请在电源线上使用漏电断路器。
<
安全盖（安全罩）
>
1. 开关安全盖（安全罩）时请注意下列事项。
・打开安全盖（安全罩）时要把盖（罩）向上开足直到面向左侧的锁定臂处于“上锁
”
状态后，再放开手。
没有上锁就放开手时，盖（罩）有落下来的危险。
・关闭盖（罩）子时先解开锁，再关闭盖（罩）子。
（请注意，解开锁时不要使盖（罩）子落下来导致受伤。）
・不要过渡增加盖（罩）子、手把等的负荷。
・如果 Head 单元位于主机装置后面，开关后侧安全盖（安全罩）时，可能会接触到
X 轴单元。这时，请将 Head 单元移动到主机装置前面，再进行后侧安全盖（安全
罩）的开关。
注意
1.
本装置的操作系统采用
Windows 7
（包括以太网通信功能）。
除安装提供的用于本装置的软件之外，加装其他软件，不保证正常运行。
对 SSD 内装入的文件进行转移、重命名、文件或文件夹的压缩、复制，也同样不
保证正常运行，敬请谅解。
●万一出现此种情况，可能需要更换新的
SSD
、丢失数据，务请格外注意。
注意
为保护操作系统，使用了
Enhanced Write Filter(EWF)
组件，进行了
C
盘
ROM
化。
1. 请勿在 C 盘保存文件。
把文件保存在 ROM 化后的 C 盘，会仿真占用主存储器。
因而，把文件存在 C 盘里时，会增加主存储器的使用量，压迫系统。
反复保存后可能造成内存不足，显示系统错误，可能需要重启本设备。
2. 需要修改操作系统的信息时，必须进行 C 盘的更新操作。
操作方法请参见使用说明书「1-10 更新 C 盘的操作」。
需要修改操作系统信息的操作是指下列事项：
・RX-6/RX-6B/RX-6R 系统软件的版本升级
・添加打印机
・设置网络（IP 地址、工作组等）
・添加用户
・变更资源管理器的设置
●要变更操作系统信息时，在执行 C 盘的更新操作后，需要重启一次本装置。
注意
本装置的
D
盘可用于安装软件或保存数据，但容量有限。
1：请确保 D 盘的可用空间。
D 盘的可用空间请确保 500MB 以上。
可用空间不足 500MB 时，请删除无用的文件(旧版本的主机软件、Log 文件、无
用的生产程序等），以确保可用空间。
●在可用空间不足的状态下使用时，可能发生应用软件错误或文件 I/O 错误，导致软
件运行不稳定，无法进行正常的动作。
v
注意
1.
本装置在
ATX
电源中使用了电池，以保护停电时的生产程序等。
为防止 ATX 内置电池老化，请勿在非通电状态下将本装置放置 6 个月以上。
●本装置以主断路器及总开关
ON
的状态为通电状态。
注意
1. X
轴、
Y
框架轴上使用线性马达及磁力线性编码器（磁性尺）。
请勿使金属类接近磁石面，因可能被磁石吸住，金属类取不下来。
进行保养时，请摘下身上的手表等精密机器。
使用心脏起搏器等精密医疗器具者，不能从事保养作业。
请勿将带有磁石或磁力的螺丝刀等工具接近磁性尺。
因为支撑销使用磁石，所以请勿将其接近磁性尺。
由于磁力，可能损坏磁性尺。
为了安全使用机器
目
录
第
1
部
基本篇
第 1 章 装置概要 ············································································································· 1-1
1-1 本装置概要 ············································································································ 1-1
1-1-1 前言 ················································································································1-1
1-1-2 特长 ················································································································1-2
1-1-3 特性 ················································································································1-4
1-1-4 系统构成 ··········································································································1-7
1-1-5 简称说明 ··········································································································1-9
1-1-6 本装置的构成 ·································································································· 1-10
1-2 本装置的构造 ······································································································· 1-12
1-2-1 基板传送部分的构造 ························································································ 1-12
1-2-2 元件供给部分的构成 ························································································ 1-14
1-2-3 Head 单元的构成 ····························································································· 1-17
1-2-4 ATC 单元（Auto Tool Changer）的构成 ································································ 1-21
1-2-5 图像识别装置（VCS）的构造 ············································································ 1-24
1-3 机械规格 ············································································································· 1-25
1-3-1 机械尺寸与重量······························································································· 1-25
1-3-2 贴片精度 ········································································································ 1-26
1-3-3 其他
·············································································································· 1-32
1-3-4 X,Y,Z,θ 轴的说明 ······························································································ 1-33
1-4 电气规格 ············································································································· 1-34
1-4-1 与外部装置的接口···························································································· 1-35
1-5 对象元件及元件包装方式 ························································································ 1-38
1-6 印刷基板规格 ······································································································· 1-51
1-7 定心系统 ············································································································· 1-56
1-8 基本操作 ············································································································· 1-61
1-8-1 画面构成示例 ·································································································· 1-61
1-8-2 显示装置及输入装置 ························································································ 1-62
1-8-3 操作方法 ········································································································ 1-64
1-8-4 菜单、功能按钮······························································································· 1-69
1-8-5 简易事项显示画面···························································································· 1-78
1-9 文件的操作 ·········································································································· 1-80
1-9-1 新建 ·············································································································· 1-80
1-9-2 打开（读入文件）···························································································· 1-80
1-9-3 保存 ·············································································································· 1-81
1-9-4 另存为 ··········································································································· 1-82
1-9-5 文本文件输出 ·································································································· 1-84
1-9-6 设备信息的取得和保存 ····················································································· 1-87
1-9-7 保存图像数据 ·································································································· 1-93
1-9-8 生产程序初始文件夹 ························································································ 1-94
1-9-9 文件管理 ········································································································ 1-95
1-9-10 硬件安全拆卸 ································································································ 1-96
1-10 C 盘的更新操作 ··································································································· 1-97
第 2 章 生产 ··················································································································· 2-1
2-1 流程图 ·················································································································· 2-1
2-2 概要 ····················································································································· 2-2
