2.15 Modifying an Inspection Program

2-157

The foreign object inspection editing tool is displayed when the template is selected and the

foreign object inspection is selected on foreign object inspection method.

* When the color is selected on the foreign object inspection method, the operation is the same

as <Color Table Editing Tools>.

Editing tool

(1) Acceptable variation

Sets the acceptable variation in the range of 1 to 99. The default value is 30.

(1)

Chapter 2 Inspection Programming

2-158

You can deploy characteristic parameter and inspection criteria of the selected component

number to other component number.

(1)

(2)

(3)

(5)

(6)

(4)

(7)

(8)

(9)

(11)

(12)

(13)

(14)

(15)

(17)

(16)

(10)

2.15 Modifying an Inspection Program

2-159

(1) Deploy Button

Clicking the button displays the component number parameter deployment screen.

(2) Component Number Parameter Deployment Target List

Displays a list of component numbers that have parameters which can be deployed.

(3) Apply Deployment Target Component Number Button

Use the Apply button to specify a component number that has parameters which you want to

deploy. If the selected component number belongs to a component number group, the

parameters are deployed to the component number group.

The Apply buttonis blue and white when it is enabled and

disabled, respectively.

(4) Apply Deployment Target Electrode Group Button

Use the Apply button to specify an electrode group that has the electrode inspection and

land inspection settings which you want to deploy.

(5) Apply Characteristic Parameter Deployment Button

Use the Apply button to specify a characteristic parameter you want to deploy.

(6) Apply Component Inspection Setting Deployment Button

Use the Apply button to specify a component inspection setting you want to deploy.

(7) Apply Inspection Range Setting Deployment Button

Use the Apply button to specify an inspection range setting you want to deploy.

(8) Electrode Group Selection Radio Button

Select an electrode group you want to deploy.

Clicking Copy deploys the parameter of the electrode group being selected upon

clicking. The parameters of electrode groups not being selected are not

deployed.

(9) Apply Electrode Group Characteristic Parameters Deployment Button

Set the characteristic parameters of the electrode group you wish to deploy by the Apply

button.

(10) Apply Electrode Inspection Setting Deployment Button

Use the Apply button to specify an electrode inspection setting you want to deploy.

(11) Apply Land Inspection Setting Deployment Button

Use the Apply button to specify a land inspection setting you want to deploy.

(12) Wettability Inspection Setting Deployment Toggle Button

Use the toggle button if you want to deploy the wettability inspection setting.

You cannot deploy the wettability inspection setting independently for inspection

items. All wetting inspection settings are the deployment targets.

(13) Select All Button

Clicking this button sets ON the characteristic parameters and all the Apply buttons of the

inspection criterion. If there are more than on electrode group, the Apply buttons of the

electrode group which is not being selected are not changed.
