2.15 Modifying an Inspection Program
2-171
The logic expression allows a comprehensive evaluation for judgment through combination of the
inspection result judgments for individual fillet and electrode posture inspection items, which can
facilitate the reduction of false calls.
Inspection Items to Use a Boolean Expression
Land Window
Fillet Inspection
Wetting Angle
Land
Wetting
Center
Both Ends
Electrode
Wetting
Center Of Toe
Both Ends Of Toe
Center Of Side
Both Ends Of Side
Fillet Height
Joint Block Height
Maximum Height
Fillet Length
Fillet Joint Width
End Joint Width
Side Joint Length
Exposed Land
Exposed Land (Oblique)
Electrode
Window
Electrode
Inspection
Electrode
Posture
Lifted Electrode
Coplanarity
Electrode Protrusion
Electrode Area
Exposed Electrode Toe
Electrode Dispersion
Electrode Side Bend
Electrode Height (Oblique)
Exposed Electrode Toe (Oblique)
Electrode Dispersion (Oblique)
Chapter 2 Inspection Programming
2-172
Select wettability inspection defined using multiple inspection items.
List of Inspection Names for Fault Image and Wettability Inspection
Fault Image
Inspection Name
Description
Lifted Electrode
Judged faulty if the electrode lifts and its toe
is higher.
Electrode Protrusion
Judged faulty if the electrode bends upward
and its diagonal length is longer.
Electrode Vertical Bend
Judged faulty if the electrode bends upward
or downward.
Electrode Horizontal
Bend
Judged faulty if the electrode bends in a
horizontal direction.
Electrode Wettability
Height
Judged faulty if solder joint with the electrode
is not sufficient.
Electrode Wet
Judged as a fault if the solder wetting height
is low and forms a flat surface around the
electrode.
Electrode Wet Convex
Judged faulty if solder forms a flat line in the
proximity of the electrode.
Solder Convex
Judged faulty if solder forms a convex shape
between the solder tip and the electrode.
Land Wettability Length
Judged faulty if solder does not spread
sufficiently in the land length direction.
2.15 Modifying an Inspection Program
2-173
Exposed Land
Judged faulty if the solder wetting is
insufficient.
Electrode Wettability
Width
Judged faulty if solder joint width with
the electrode is not sufficient.
Electrode Side
Wettability
Judged faulty if solder joint with the
electrode sides is not sufficient.
