Appendix 10. Inspection Criteria Setting
a-66
Item
Description
FilletMaxHeightLowerLimit
Lower limit of maximum fillet height
FilletMaxHeightUpperLimit
Upper limit of maximum fillet height
FilletMaxHeightValue
Measured value of maximum fillet height (%)
FilletMaxHeightActualValue
Actual measured value of maximum fillet height
FilletMaxHeightResult
Inspection result of maximum fillet height
FilletLengthLowerLimit
Lower limit of fillet length
FilletLengthValue
Measured value of fillet length (%)
FilletLengthActualValue
Actual measured value of fillet length
FilletLengthResult
Inspection result of fillet length
EndJointWidthLowerLimit
Lower limit of end joint width
EndJointWidthValue
Measured value of end joint width
EndJointWidthResult
Inspection result of end joint width
SideJointLengthLowerLimit
Lower limit of side joint width
SideJointLengthValue
Measured value of side joint width
SideJointLengthResult
Inspection result of side joint width
ExposedBasisMetalUpperLimit
Upper limit of land exposure inspection
ExposedBasisMetalValue
Measured value of land exposure inspection
ExposedBasisMetalResult
Inspection result of land exposure inspection
LandErrorRegion1LowerLimit
Lower limit of land error inspection (region 1)
LandErrorRegion1UpperLimit
Upper limit of land error inspection (region 1)
LandErrorRegion1Value
Measured value of land error inspection (region 1)
LandErrorRegion1Result
Result of land error inspection (region 1)
LandErrorRegion2LowerLimit
Lower limit of land error inspection (region 2)
LandErrorRegion2UpperLimit
Upper limit of land error inspection (region 2)
LandErrorRegion2Value
Measured value of land error inspection (region 2)
LandErrorRegion2Result
Result of land error inspection (region 2)
LandErrorRegion3LowerLimit
Lower limit of land error inspection (region 3)
LandErrorRegion3UpperLimit
Upper limit of land error inspection (region 3)
LandErrorRegion3Value
Measured value of land error inspection (region 3)
LandErrorRegion3Result
Result of land error inspection (region 3)
LandErrorRegion4LowerLimit
Lower limit of land error inspection (region 4)
LandErrorRegion4UpperLimit
Upper limit of land error inspection (region 4)
LandErrorRegion4Value
Measured value of land error inspection (region 4)
LandErrorRegion4Result
Result of land error inspection (region 4)
LandErrorRegion5LowerLimit
Lower limit of land error inspection (region 5)
LandErrorRegion5UpperLimit
Upper limit of land error inspection (region 5)
LandErrorRegion5Value
Measured value of land error inspection (region 5)
LandErrorRegion5Result
Result of land error inspection (region 5)
LandErrorRegion6LowerLimit
Lower limit of land error inspection (region 6)
LandErrorRegion6UpperLimit
Upper limit of land error inspection (region 6)
LandErrorRegion6Value
Measured value of land error inspection (region 6)
LandErrorRegion6Result
Result of land error inspection (region 6)
LandErrorRegion7LowerLimit
Lower limit of land error inspection (region 7)
LandErrorRegion7UpperLimit
Upper limit of land error inspection (region 7)
LandErrorRegion7Value
Measured value of land error inspection (region 7)
LandErrorRegion7Result
Result of land error inspection (region 7)
LandErrorRegion8LowerLimit
Lower limit of land error inspection (region 8)
LandErrorRegion8UpperLimit
Upper limit of land error inspection (region 8)
LandErrorRegion8Value
Measured value of land error inspection (region 8)
LandErrorRegion8Result
Result of land error inspection (region 8)
LandErrorRegion9LowerLimit
Lower limit of land error inspection (region 9)
LandErrorRegion9UpperLimit
Upper limit of land error inspection (region 9)
LandErrorRegion9Value
Measured value of land error inspection (region 9)
LandErrorRegion9Result
Result of land error inspection (region 9)
LandErrorRegion10LowerLimit
Lower limit of land error inspection (region 10)
LandErrorRegion10UpperLimit
Upper limit of land error inspection (region 10)
LandErrorRegion10Value
Measured value of land error inspection (region 10)
LandErrorRegion10Result
Result of land error inspection (region 10)
Appendix 10. Inspection Criteria Setting
a-67
Item
Description
ForeignMaterialOnLandUpperLimit
Upper limit of foreign object (land) inspection
ForeignMaterialOnLandUpperValue
Measured value of foreign object (land) inspection
ForeignMaterialOnLandUpperResult
Result of foreign object (land) inspection
ObliqueExposedBasisMetalUpperLimit
Upper limit of oblique land exposure inspection
ObliqueExposedBasisMetalValue
Measured value of oblique land exposure inspection
ObliqueExposedBasisMetalResult
Result of oblique land exposure inspection
ObliqueLandErrorRegion1LowerLimit
Lower limit of oblique land error inspection (region 1)
ObliqueLandErrorRegion1UpperLimit
Upper limit of oblique land error inspection (region 1)
ObliqueLandErrorRegion1Value
Measured value of oblique land error inspection (region 1)
ObliqueLandErrorRegion1Result
Result of oblique land error inspection (region 1)
ObliqueLandErrorRegion2LowerLimit
Lower limit of oblique land error inspection (region 2)
ObliqueLandErrorRegion2UpperLimit
Upper limit of oblique land error inspection (region 2)
ObliqueLandErrorRegion2Value
Measured value of oblique land error inspection (region 2)
ObliqueLandErrorRegion2Result
Result of oblique land error inspection (region 2)
ObliqueLandErrorRegion3LowerLimit
Lower limit of oblique land error inspection (region 3)
ObliqueLandErrorRegion3UpperLimit
Upper limit of oblique land error inspection (region 3)
ObliqueLandErrorRegion3Value
Measured value of oblique land error inspection (region 3)
ObliqueLandErrorRegion3Result
Result of oblique land error inspection (region 3)
ObliqueLandErrorRegion4LowerLimit
Lower limit of oblique land error inspection (region 4)
ObliqueLandErrorRegion4UpperLimit
Upper limit of oblique land error inspection (region 4)
ObliqueLandErrorRegion4Value
Measured value of oblique land error inspection (region 4)
ObliqueLandErrorRegion4Result
Result of oblique land error inspection (region 4)
ObliqueLandErrorRegion5LowerLimit
Lower limit of oblique land error inspection (region 5)
ObliqueLandErrorRegion5UpperLimit
Upper limit of oblique land error inspection (region 5)
ObliqueLandErrorRegion5Value
Measured value of oblique land error inspection (region 5)
ObliqueLandErrorRegion5Result
Result of oblique land error inspection (region 5)
SideOverhangUpperLimit
Upper limit of electrode side overhang
SideOverhangValue
Measured value of electrode side overhang
SideOverhangResult
Inspection result of electrode side overhang
EndOverhangUpperLimit
Upper limit of electrode end overhang
EndOverhangValue
Measured value of electrode end overhang
EndOverhangResult
Inspection result of electrode end overhang
EndOverlapLowerLimit
Lower limit of electrode end overlap
EndOverlapValue
Measured value of electrode end overlap
EndOverlapResult
Inspection result of electrode end overlap
VerticallyLiftedElectrodeLowerLimit
Lower limit of lifted electrode
VerticallyLiftedElectrodeUpperLimit
Upper limit of lifted electrode
VerticallyLiftedElectrodeValue
Measured value of lifted electrode
VerticallyLiftedElectrodeResult
Inspection result of lifted electrode
CoplanarityUpperLimit
Upper limit of coplanarity
CoplanarityValue
Measured value of coplanarity
CoplanarityResult
Inspection result of coplanarity
ElectrodeLengthLowerLimit
Lower limit of electrode protrusion
ElectrodeLengthUpperLimit
Upper limit of electrode protrusion
ElectrodeLengthValue
Measured value of electrode protrusion
ElectrodeLengthResult
Inspection result of electrode protrusion
ElectrodeAreaUpperLimit
Upper limit of electrode area
ElectrodeAreaValue
Measured value of electrode area
ElectrodeAreaResult
Inspection result of electrode area
ExposedElectrodeToeUpperLimit
Upper limit of electrode tip exposure
ExposedElectrodeToeValue
Measured value of electrode tip exposure
ExposedElectrodeToeResult
Inspection result of electrode tip exposure
ElectrodeColorDispersionUpperLimit
Upper limit of electrode color dispersion
ElectrodeColorDispersionValue
Measured value of electrode color dispersion
ElectrodeColorDispersionResult
Inspection result of electrode color dispersion
ElectrodeSideBendUpperLimit
Upper limit of electrode bend
ElectrodeSideBendValue
Measured value of electrode bend
ElectrodeSideBendResult
Inspection result of electrode bend
Appendix 10. Inspection Criteria Setting
a-68
Item
Description
ElectrodeHeightUpperLimit
Upper limit of electrode height
ElectrodeHeightValue
Measured value of electrode height
ElectrodeHeightResult
Inspection result of electrode height
ElectrodePresenceLowerLimit
Lower limit of electrode presence
ElectrodePresenceValue
Measured value of electrode presence
ElectrodePresenceResult
Inspection result of electrode presence
ElectrodeHeightObliqueUpperLimit
Upper limit of oblique electrode height
ElectrodeHeightObliqueValue
Measured value of oblique electrode height
ElectrodeHeightObliqueResult
Inspection result of oblique electrode height
ExposedElectrodeToeObliqueUpperLimit
Upper limit of oblique electrode tip exposure
ExposedElectrodeToeObliqueValue
Measured value of oblique electrode tip exposure
ExposedElectrodeToeObliqueResult
Inspection result of oblique electrode tip exposure
ElectrodeColorDispersionObliqueUpperLimit
Upper limit of oblique electrode color dispersion
ElectrodeColorDispersionObliqueValue
Measured value of oblique electrode color dispersion
ElectrodeColorDispersionObliqueResult
Inspection result of oblique electrode color dispersion
