1.4 Switching Languages
1-9
1.4 Switching Languages
This system allows you to select either English or Japanese as a display language.
Switching Languages is available on:
Main menu, Teaching PCB selection screen, or any screen of the utility
Click the [Language] on the top-right of the screen and a language list appears.
Click a language you want to display.
Chapter 1 Before Getting Started
1-10
1.5 Login and Logout
After the system starts, follow the login procedures from the main menu. Without following the
procedures, no menu can be started. After all the operation is done, follow the logout
procedures.
A user name and a password registered in v-DB Tool are required to log in. This function allows
the user to limit access to the operator of the system.
Refer to "Chapter 2 Using v-DB Tool" in the v-DB Operation Manual for v-DB Tool operation.
1.5.1 Login
Specify a user and log in to the system.
1.
Click [Login] on the main menu.
The login dialog automatically appears when v-TS starts.
2.
The following dialog will appear.
Select a user name from the list box, enter a password and then
click [OK].
・ Clicking [Cancel] will return the system to the main menu without
logging in.
The characters entered will be displayed as "
" in the space for the
password.
