7.1 Adding Comments 142 While the virtual keyboard is displayed, clicking [T erm List] displays preregis- tered words. Also, clicking [History List] displays words en tered in the past. 1. Move the flash ing cursor to th…
7.1 Adding Comments
141
6
Chapter 7 Utility Functions
7
Move the flashing cursor to the setting item for which to make the input, and choose the content with
the mouse.
1. Move the flashing cursor to the field for entering text with the mouse, and then
click [Enter Char].
A virtual keyboard appears.
2. Select a character from the virtual keyboard to enter it.
3. Select [Confirm] to accept the entry.
Click [ESC] to cancel the input.
(Clicking [ESC] again closes the virtual keyboard)
7.1.3 Alphanumeric Input
Entering Text
RESET: Deletes all entered characters.
SPACE: Inserts a space.
OVWR/INS: Toggles between Overwrite (OVWR) and Insert (INS) mode.
<<: Move the character input position left.
>>: Move the character input position right.
Character input position
Move with << >> or the mouse wheel.
Character selection cursor
ESC
Entering units and symbols
Characters entered at the unit may be saved differently.
Save (saving of numerical calculation results or text format information)
2
^2,
3
^3, ~u, ~o, ~e, °~c ,
±
~+, (display only)uE, °C (display only)C
Characters not allowed in the file name have been detected. (Please use only
uppercase letters.)
7.1 Adding Comments
142
While the virtual keyboard is displayed, clicking [Term List] displays preregis-
tered words.
Also, clicking [History List] displays words entered in the past.
1. Move the flashing cursor to the comment field and select [Enter Char].
The virtual keyboard appears.
2. (To select from preset terms)
Click [Term List ].
A list of preset terms appears.
(To select from past input)
Click [History List].
A History list appears.
Click [ESC] to cancel selection from the history list.
3. Select the word to enter from the list. You can also select the word to enter by
double-clicking it.
4. Select [Confirm] to accept the entry. The virtual keyboard disappears.
To return the edited field to the original condition, select [Undo].
Entering Text From a Term List Or History List
7.1 Adding Comments
143
6
Chapter 7 Utility Functions
7
1. Move the flashing cursor to the numeric input field and select [Up-Down].
A virtual keyboard for digit input appears.
2. • Click △▽ in the displayed up-down input window.
This allows you to change the value of the corresponding digit.
• Click a digit that can be changed.
The selection cursor moves to that location.
• Rotate the mouse wheel.
This allows you to increase or decrease the value of the digit where the selection cursor is
located.
If the value is changed in the △ (up) direction, the current numeral itself
increases.
(If there is a minus sign at the beginning, the numerical value of the digit
decreases [the set value increases].)
3. Click [Confirm].
The currently set value is entered.
Click [ESC] to cancel the input.
Entering Numerals By Up/Down Action
