Appendix 2 Reference
A6
The maximum available recording time depends on the selected timebase.
The maximum recording time can be obtained by the following formula.
Refer to the following tables for the information about recordable time.
(d: days/ h: hours/ min: minutes/ s: seconds)
Appendix 2.3 Timebase and Maximum Recordable
Time
Recordable time can be verified on the Status
screen - [Status] sheet. ([Recording period])
Recordable Time = Timebase x Recording Length
Setting a slow timebase may result in a very long recording time (over a year)
which may exceed the guarantee period or product life, in which case we cannot
guarantee operation.
Memory Function
Timebase
(Time/div)
Sampling Rate
Maximum Recording
Length
160,000 div
5 s
50 ns 0.8 s
10 s 100 ns 1.6 s
20 s 200 ns 3.2 s
50 s 500 ns 8 s
100 s1 s16 s
200 s2 s32 s
500 s5 s1 min 20 s
1 ms 10 s2 min 40 s
2 ms 20 s5 min 20 s
5 ms 50 s 13 min 20 s
10 ms 100 s 26 min 40 s
20 ms 200 s 53 min 20 s
50 ms 500 s 2h 13 min 20 s
100 ms 1 ms 4 h 26 min 40 s
200 ms 2 ms 8 h 53 min 20 s
500 ms 5 ms 22 h 13 min 20 s
1 s 10 ms 1 d 20 h 26 min 40 s
2 s 20 ms 3 d 16 h 53 min 20 s
5 s 50 ms 9 d 6 h 13 min 20 s
10 s 100 ms 18 d 12 h 26 min 40 s
30 s 300 ms 55 d 13 h 20 min 0 s
50 s 500 ms 92 d 14 h 13 min 20 s
1 min 600 ms 111 d 2 h 40 min 0 s
100 s 1 s 185 d 4 h 26 min 40 s
2 min 1.2 s 222 d 5 h 20 min 0 s
5 min 3 s
Appendix 2 Reference
A7
Appendix
(d: days/ h: hours/ min: minutes/ s: seconds)
*: Also when recording length is set to [Cont.], the the maximum recording length is 80,000div.
The maximum record length is automatically determined by settings for the number of channels
used and the number of divisions.
Recorder Function
Timebase/div Maximum Recording Length : 80,000 div
*
10 ms 13 min 20 s
20 ms 26 min 40 s
50 ms 1 h 6 min 40 s
100 ms 2 h 13 min 20 s
200 ms 4 h 26 min 40 s
500 ms 11 h 6 min 40 s
1 s 22 h 13 min 20 s
2 s 1 d 20 h 26 min 40 s
5 s 4 d 15 h 6 min 40 s
10 s 9 d 6 h 13 min 20 s
30 s 27 d 18 h 40 min 0 s
50 s 46 d 7 h 6 min 40 s
1 min 55 d 13 h 20 min 0 s
100 s 92 d 14 h 13 min 20 s
2 min 111 d 2 h 40 min 0 s
5 min 277 d 18 h 40 min 0 s
10 min
30 min
1 h
Appendix 2.4 Maximum record length and number of
divisions (Memory division function)
Desired record length
The number of
divisions
(blocks)
Maximum record
length (div)
2 80,000
4 40,000
8 20,000
16 10,000
32 5,000
64 2,500
128 1,200
256 600
512 300
1024 150
Appendix 2 Reference
A8
*: If the data update rate specified at NPLC is longer than the sampling rate indicated in the table above, one
of data is measured repeatedly during the data update rate period.
See:"7.9.8 Setting Model MR8990 Digital Voltmeter Unit" ( p.171)
*: If the time axis range is set to one faster than 100 ms/div, one of data is measured repeatedly during the
data update rate period specified at NPLC.
See:"7.9.8 Setting Model MR8990 Digital Voltmeter Unit" ( p.171)
Fixed record length
The number of
divisions
(blocks)
Maximum record
length (div)
250,000
420,000
820,000
16 10,000
32 5,000
64 2,000
128 1,000
256 500
512 200
1024 100
Appendix 2.5 Time Axis Range and Sampling Rate of
MR8990 Digital Voltmeter Unit
Timebase/div Sampling Rate
100 ms 2 ms
200 ms 4 ms
500 ms 10 ms
1 s 20 ms
2 s 40 ms
5 s 100 ms
10 s 200 ms
30 s 600 ms
50 s 1 s
1 min 1.2 s
10 s 2 s
2 min 2.4 s
5 min 6 s
